pace-node

A compile worker. It takes translation units that missed the cache and compiles them, so a build is not limited to the cores of the machine running it.

It is the fleet's one binary, and it wears several hats. Compiling is the only one it always wears; the rest are surfaces you switch on, and every section below is about one of them:

Role	What switches it on	Default
A cache tier of its own	--cache-memory, --cache-dir	on, 25% of RAM in memory, uncompressed
Fleet scheduler	the node's mode, and consensus	on — a first start is a cluster of one, and serves it
Consensus member	--listen-raft, and the mode	on (6680) — an empty --listen-raft= runs none, on a cache-only node (--slots=0)
The fleet's shared cache	--cluster-set=shared-cache=<id>, once, for the whole cluster	off — no machine is named
Peer discovery	--discovery, and consensus	on (6681) beside consensus — UDP, unlike every other surface; an empty --discovery= turns it off
Metrics, and the fleet dashboard	--admin-listen, --dashboard	off

That is the list of roles, and it is not a firewall list — a role's default here is not the address it binds for a given command line. For the ports, see Every port it opens below, or generate the list from the binary with --print-surfaces.

What it never does is write to the shared cache. A worker is given no credentials for it: the object it produces goes back to the client that asked for it, and the client stores it, so a rogue worker can poison only its own key space.

This page is the reference. For why a node is shaped this way — who leads, what a joining node does in order, and what decides whether a worker matches a client at all — read How it works.

How the pieces fit

A node is up to four surfaces in one process: a compile worker always, and optionally a scheduler, a cache tier and a consensus member. A client misses its cache, asks the scheduler for a worker, sends that worker preprocessed text, and stores the object it gets back.

Cluster communication draws the whole fleet and follows one compile across it, including the parts below the surface — what the scheduler decides and on what evidence, and what the nodes say to each other.

Every refusal ends in a local compile. No matching toolchain, no free slot, another client already compiling this key, an unreachable worker — all of them fall back. Distribution cannot fail a build; that is what makes it safe to leave switched on in a fleet where machines come and go.

Every port it opens

Ask the binary, not this page. --print-surfaces lists every port a given configuration would bind, with its protocol, and exits without opening anything:

$ pace-node --print-surfaces --listen-node 6675 \
      --node-id n1 --listen-raft 6680 \
      --discovery 192.168.1.255:6681
mode: solitary (no cluster minted yet; the first start mints one)

node              0.0.0.0:6675  TCP
admin             -             not served; set --admin-listen
raft              0.0.0.0:6680  TCP
discovery beacon  0.0.0.0:6681  UDP
discovery reply   0.0.0.0:*     UDP, port chosen by the kernel at bind

dialled at:
  consensus endpoint  AT STARTUP  -- the address this machine routes from on the raft port, or its fully qualified name until a route is known; derived when the node starts; give --raft-self to state it now

state directory:
  <state directory> (per-user: this process is not privileged, so it keeps its identity apart from the machine's service)

fleet:
  cluster    none minted yet
  pinned to  none (--fleet-id unset: discovery is trust-on-first-use)

notes:
  node: a systemd .socket unit is served on this surface: the unit owns the address, …
  …
  discovery: UDP, and the only surface that is. … Without --discovery-reply-port the reply socket takes a kernel-chosen port, new at every start, and peers send their challenges and proofs TO it: a restrictive firewall has to let it in, INBOUND, by program, since no port rule can name it. …

That is a real run, with two kinds of substitution: <state directory> stands for the path this machine printed (a per-user one here, since the run was not privileged; a service's is the machine-wide one), and each … stands for text left out of a note. The worksheet exits 0 only for a configuration the node would start with: given one it would refuse, it prints the same worksheet and then the refusal, with exit status 2.

The first line is the node's mode, read from the formation record in its state directory: solitary, pending, learner or voter. The mode, not a flag, decides whether consensus runs, whether the raft row is served and whether the scheduler is. Before the first start has minted a record it reads solitary (no cluster minted yet; the first start mints one), which is what that start will be. A learner's raft row reads not served (learner: dials the leader): it opens no consensus port, and dials every voter instead.

The dialled at: block is not a port to open. It is the address peers dial for consensus -- routinely not the raft row, because a bare --listen-raft binds the wildcard -- and it is the one to compare against --cluster-admit's receipt (see Membership at runtime). This invocation names none, so the block says when it will be known: AT STARTUP. A started node takes the address this machine routes from (--raft-self defaults to auto), and this machine's fully qualified name — the name the line prints — only until a route is known. With --raft-self 10.0.0.7 added it reads 10.0.0.7:6680.

The notes: block is part of the output, not an afterthought: it carries the facts a column cannot, including the one that says this list can be wrong for the compile port. Do not clip it when pasting the worksheet to somebody.

Pass the flags you would actually run with. It prints what that configuration serves rather than the defaults, so a widened --listen-node 0.0.0.0:6674 shows as the wildcard and a surface you never turned on says so and names the flag that would. The node opens its ports from the same table this prints, so the list and the sockets cannot disagree — which is the whole reason to generate a firewall worksheet from the binary rather than transcribe one from documentation.

The surfaces, and what each is for:

Surface	Flags	Default	Protocol
Node port — cache verbs, compile jobs, and the scheduler's where the mode serves them	--listen-node	6674 — always on; a bare port takes the wildcard	TCP
Admin / metrics	--admin-listen	off; a bare port takes loopback	TCP
Consensus peer	--listen-raft	6680; the mode opens it (every mode but a learner's), an empty --listen-raft= closes it, and a bare port takes the wildcard	TCP
Discovery	--discovery + --discovery-reply-port	6681, on beside consensus, plus a kernel-chosen reply port; an empty --discovery= turns it off; always binds the wildcard	UDP

Several things on that table are easy to get wrong and expensive to get wrong:

• Discovery is UDP. Three TCP rules and one wrong one leaves a beacon that reaches nobody, and that presents as a fleet that never forms rather than as a firewall mistake.
• --discovery's address is where beacons are sent, not where they are heard. Both of its sockets bind the wildcard whatever you write, so --discovery=192.168.1.255:6681 opens 0.0.0.0:6681 — do not put the broadcast address in a firewall rule.
• The reply socket's port is kernel-chosen unless --discovery-reply-port names it. Discovery takes a second port, the one peers unicast their challenges and proofs to: they ARRIVE there, not at the beacon port. Unnamed, the kernel picks it at every start, so a restrictive host firewall has to let it in — inbound, by program rather than by port — and a node that can hear beacons but not answer challenges completes no handshake. --print-surfaces prints it as discovery reply 0.0.0.0:*.
• Unless you name --discovery, the node beacons its summary on every eligible subnet — its cluster id, node id and consensus endpoint, to each up interface's directed broadcast on port 6681 (a /24 at 192.168.86.24 sends to 192.168.86.255). VPN-type adapters are included: one that carries a real subnet is beaconed on like a LAN, so the summary reaches whatever that VPN's subnet reaches. The set is re-read on an interval, so a link that comes up later is beaconed on too. Never to 255.255.255.255: the limited broadcast leaves by one interface the stack guesses, which on a machine with a VPN-type adapter is the adapter rather than the LAN. Loopback, down, link-local (169.254/16) and /31-/32 interfaces are passed over, and so, on Linux and macOS, is a point-to-point or non-broadcast link such as a WireGuard wg0 or a tun, whatever its prefix. A node with none left says so in its log with each interface and why, and names --fleet-seed and DNS SRV for a machine with no broadcast link.
• Naming --discovery restricts beaconing to that ONE address. It is used exactly, and no other interface is beaconed on. Name a directed broadcast (--discovery=192.168.1.255:6681), never 255.255.255.255: named, the limited broadcast is exactly what you get, one guessed interface included.
• A bare port does not mean the same thing on every flag. --listen-node 6674 and --listen-raft 6680 bind the wildcard, because every node is a fleet participant and a port no peer can dial does nothing; the cache verbs on that port still answer this machine alone, whatever it is bound to. --admin-listen 6677 binds loopback, and that is the sharpest of the three: it is what the dashboard's credential rule turns on, so widening that address is what makes a token required.

One caveat --print-surfaces states and cannot compute. Under systemd socket activation the .socket unit owns the address and port, and --listen-node is read by nothing: the node asks the socket it is handed where it is bound and advertises that — a wildcard ListenStream= as the address this machine routes from, on the socket's port, and one bound to an address as that address. --advertise still overrides both. The command is run by hand, never under the supervisor, so it cannot detect this; it prints the note instead of guessing.

--advertise is deliberately not a surface. It is what this node tells other machines to dial, not a socket it opens.

Quick start

Three processes. A cache:

pace-kv --listen=0.0.0.0:6674

A scheduler, which is a compile node rather than the cache — handing out capacity is a decision only one node may make at a time, and the cache cannot establish which node that is:

pace-node \
    --listen-node=0.0.0.0:6675 \
    --raft-self=scheduler.internal \
    --fleet-open \
    --advertise=scheduler.internal:6675 \
    --toolchain=/usr/bin/g++

No flag makes it a scheduler. Its first start mints a formation record into its state directory: a cluster of one, which it leads, and whose mode serves the fleet's scheduler. That is consensus even on one machine — a scheduler signs every lease with its own identity key, which its workers check against the voters their own consensus applied (#178) — so consensus is on by default (--listen-raft defaults to 6680), and --raft-self says where another member would dial it; without one, it is dialled at the address this machine routes from, which follows the machine when its network changes. Its own worker registers with the scheduler it serves, on this machine. The same line with --print-identity added prints its identity:

pace-node --print-identity --raft-self=scheduler.internal

Give --fleet-open too: a scheduler that admits no other machine refuses every caller but its own machine, which is the right default and not a working configuration.

A worker, on each machine that should take work:

pace-node \
    --fleet-seed=build-cache.internal:6675 \
    --listen-node=0.0.0.0:6674 \
    --advertise=worker-01.internal:6674 \
    --fleet-open \
    --cluster-dir=/var/lib/pace-node \
    --toolchain=/usr/bin/g++

A worker joins the scheduler's fleet ONE way: as a learner. Its first start mints its identity key into --cluster-dir and founds a cluster of one there; it then finds the fleet -- by the LAN beacon, or at --fleet-seed where no beacon reaches -- and asks to be admitted under that key. An operator on a voter compares the key and approves it:

pace-node --enroll-list
pace-node --enroll-approve=<id>@<key>

Approved, it applies the fleet's replicated state and its worker registers with the fleet's scheduler, which its formation record names: there is no --scheduler on a node that serves, which is refused one. It proves which machine it is on every connection to that scheduler, with its identity key, and checks the lease a client presents against the voters of the state it has applied -- so no key is typed anywhere. That check is what makes --fleet-open over a bind that faces the network safe: the node compiles only for a client holding a lease its fleet's voters issued. See A node proves which machine it is.

--listen-node and --advertise have to agree. A dialable --advertise over a --listen-node bound to loopback tells peers to dial an address this node never accepts on, and an advertised wildcard resolves to the caller's machine — which is why auto replaces a wildcard bind with the address this machine routes from, or with its name until a route is known. Both are refused at startup by name; so, since #463, is naming neither while the worker registers with a scheduler on another machine. Whichever you got wrong, the refusal names the flag and a working value.

All three refusals are scoped to a node that admits other machines, because that is what says peers are meant to dial this worker at all. One that admits nobody but its own machine refuses every dispatched compile — a different problem, which the startup line reports rather than this table.

A worker admits other machines by their keys, and that is the half most easily missed: the policy that gates a scheduler gates this node's compile port too (#235). A client on another machine presents a machine ticket its own node mints, and this worker checks it against the roster it holds — so a worker with a roster admits every machine the cluster admitted, whatever address it dials from, and one with no roster admits its own machine alone. See who may use it.

And the client, which is the launcher you already use:

export PACE_ADDR=build-cache.internal:6674
export PACE_SCHEDULER=build-cache.internal:6675
cmake -DCMAKE_CXX_COMPILER_LAUNCHER=pace-cc ...

Unset PACE_SCHEDULER and every miss compiles locally again, which is the behaviour without this feature.

--advertise is the flag to get right

The scheduler hands your string to clients verbatim. A worker that advertises 127.0.0.1 is leased and then never answers, and the symptom is a build that mysteriously falls back to local compiles on every machine but one.

It defaults to auto. While --listen-node binds the wildcard — the default — that is the address this machine routes from, on the --listen-node port, re-derived whenever an interface or address changes (and at the latest every 30 seconds), with this machine's fully qualified name standing in until a route is known. A --listen-node bound to one address is advertised as bound.

Value	Advertises	Follows the network	Dial hints
unset, or auto	the routed address, on the bound port	yes	not needed: the registration itself moves
auto:<port>	the routed address, on that port (for a port mapped in front of this one)	yes	not needed
<name>:<port>	that name; each client resolves it when it dials	no	yes: a client tries the address the scheduler last saw first
<ip>:<port>	exactly that address	no — said once in the log	none

So a name is an opt-in pin, worth it where a DNS name is what clients should dial (a NAT, or an address the scheduler cannot see). An IP literal turns roaming off entirely: keep one only for an address that never changes.

Why a fleet worker still has to widen --listen-node by hand

Serving the scheduler moved a bare port to the wildcard; registering with a scheduler elsewhere and --fleet-open did not, and #463 asked whether they should. They did not, for the three reasons below — and the zero-config defaults have since moved the default to the wildcard on every node (see the table above), on the strength of admission rather than of the socket:

• It would save one flag, and only after three others. Widening the bind is what makes the compile verbs face the network, so a roster to check leases against becomes required; and the widened bind becomes the advertised endpoint, so --advertise becomes required too. A fleet worker still names four flags either way.
• It would silence the message that teaches. The refusal you get today for naming --advertise and leaving the bind alone is the fix, spelled out, while you are watching.
• A listening socket that widened itself on a predicate over three flags is a security decision nobody typed. The cache verbs would stay closed — CacheResponder admits this machine alone whatever the bind is — but that is a property of today's responder set, not a promise about what is served there next.

What the ticket did find is that a worker naming neither flag — and naming a membership flag, registering with a scheduler on another machine — was refused by nothing at a hand start, while --install-service refused the same command line. That is now a startup refusal as well.

When this node's address moves

Series	What a rise means
pace_node_endpoint_changes_total	The endpoint this node advertises moved: the address it routes from changed (a DHCP renewal, Wi-Fi to wired, another network), or a reload re-pinned --advertise. Each move is logged at Info with the old and the new endpoint; a worker's heartbeat is woken to re-register under the new one at once, and a lease granted for the old one is honoured until it has. Zero on a node whose --advertise stays pinned to one value; a reload that re-pins it to another counts one move.
pace_node_raft_endpoint_changes_total	The Raft endpoint this node advertises moved, for the same two reasons. Read it beside the row above: the two move together unless --raft-self is pinned apart from --advertise. It stays at zero on a node that dials in (a learner) or runs no consensus: nobody dials such a node's Raft port, so none is derived.

Anything the fleet reads has to be text

A value that leaves this machine has to be valid UTF-8, because every other member reads it back: /fleet.json is JSON, the fleet page is HTML, /fleet.txt is tab-separated text, and a chart is SVG. The flags that carry one are --advertise, --node-id, --fleet-seed, --cluster-admit, --cluster-set, and the <fingerprint> half of --toolchain=<fingerprint>=<compiler>. A worker refuses to start rather than registering a value the scheduler would then reject on every heartbeat.

Valid UTF-8 is not the same as safe in every one of those formats, and this gate deliberately does not try to be. A tab is valid UTF-8 and is legal XML Char besides, so it passes here — and unescaped in a tab-separated row it would shift every later column, while a newline would invent a row outright. Each encoder owes its own format that much, exactly as the JSON encoder owes JSON its quotes, so /fleet.txt spells out \t, \n, \r and \\. Narrowing the gate instead would let a rendering concern decide what a machine may call itself.

Non-ASCII is fine — the rule is about the encoding, not about the alphabet. What is refused is a byte sequence that is not UTF-8 at all, and on Windows that used to be what a non-ASCII argument became on the way into the process. Every binary here now declares UTF-8 as its code page, which Windows honours from Windows 10 1903 and Windows Server 2022 onwards.

On an older Windows the declaration is ignored, and chcp does not help: that sets the console's code page, while arguments are transcoded through the system's ANSI one. A refused start says which code page this host is on. Either keep those values ASCII, or turn on the system-wide Beta: Use Unicode UTF-8 for worldwide language support setting, which is what makes GetACP() answer 65001 on such a host.

Paths are deliberately not covered by the rule — --cache-dir and the compiler half of --toolchain name files on this machine and nowhere else, so whatever this host calls a filename is accepted.

Toolchains

A worker surveys this machine at startup and serves what it finds. Nothing has to be typed:

pace-node --advertise=...

[INFO] found /usr/bin/g++ (usr)
[INFO] found /usr/bin/clang++ (usr)
[INFO] serving /usr/bin/g++ as 4f2c...
[INFO] discovered 2 toolchain(s) on this machine; pass --toolchain to serve a narrower set

When a compiler is upgraded under a running node

The node notices, and re-registers under the new fingerprint. A worker fingerprints its machine at startup and then runs for weeks, while pace-cc recomputes per invocation — so without this, a compiler patched in place would leave the node advertising the pre-upgrade digest while spawning the post-upgrade compiler. Clients would receive objects built by a compiler they did not key against and store them in the shared cache under the old key, where the whole fleet then reads them (#238).

Each heartbeat re-checks the evidence the fingerprint was derived from — the compiler binary's size and modification time, and the modification time of each include search root. That is a handful of stat calls and no compiler is spawned, so it costs a heartbeat essentially nothing. Only when something has moved does the node pay for the full re-survey.

That pair of checks covers the two upgrades that happen in practice: a distribution replacing gcc in place moves the binary, and a Windows SDK update that never touches cl.exe moves an include root. A header edited in place under an unchanged directory is deliberately not covered — a system toolchain's headers are installed rather than edited, and catching it would mean the multi-second walk of the whole include tree on every heartbeat.

When something did move:

[INFO] the toolchain behind 4f2c… changed on this machine; re-deriving what this worker serves
[INFO] no longer serving 4f2c… (/usr/bin/g++)
[INFO] now serving 9b71… (/usr/bin/g++)

The old fingerprint stops being served immediately, before the new registration is announced. A client still holding a lease for it is refused unknown-fingerprint and compiles locally — the ordinary fallback, counted by pace_worker_jobs_refused_unknown_fingerprint_total.

A witness-driven check can only ever notice what it is already watching, so once every fifteen minutes the node surveys the machine unconditionally. That is the way back from serving less than the machine has: a toolchain dropped by a transient probe failure, or removed and later reinstalled, rejoins on that sweep rather than waiting for a restart. A sweep that finds nothing changed is not reported as a change, so it costs the fleet no re-registration.

Two consequences worth knowing. An operator's pinned <fingerprint>=<compiler> is never re-derived: it is not probed in the first place, and pinning a digest by hand is how you force a fleet to agree while a machine is being repaired. And a machine whose only compiler an upgrade removed or broke keeps running while serving nothing, rather than exiting — the compiler may come back with the next package, and a routine upgrade must not be able to take a machine out of the fleet permanently. It says so, it retires its registry entries at once so the scheduler stops picking it rather than dispatching for up to 90 seconds to a worker that would refuse every job, and the next sweep is what brings it back:

[WARN] this machine now has no usable toolchain; serving nothing until one returns

--toolchain is an override that narrows that set:

--toolchain=/usr/bin/g++                 # this node computes the fingerprint
--toolchain=<fingerprint>=/usr/bin/g++   # or pin it explicitly
--no-toolchain-discovery                 # do not survey the machine at all

Naming any --toolchain pins the worker to exactly those; naming none means "serve what this machine has". The two are never merged, because a merged set would quietly re-add a compiler you had deliberately narrowed away.

A job names a fingerprint, never a program. The worker maps that fingerprint to a compiler it serves and refuses one it does not have — which is the difference between a build accelerator and a remote shell, and is why there is still no default compiler. "No default" and "no discovery" are different claims: a default is how a job ends up running against something nobody chose, while which compilers a machine holds is a fact the worker can establish.

A compiler that is found but cannot be executed is dropped at startup, named, with the layout that found it — rather than registering and failing every job it is sent. So is one whose fingerprint would say nothing about which compiler it is: a driver this build cannot ask for a version and whose fingerprint folds no include tree — none could be located, or it is cl, which folds none — digests to its own basename, which every install of that compiler on earth would also produce. Pin such a toolchain with --toolchain=<fingerprint>=<compiler> if you want it served anyway. A worker that ends up with nothing to serve refuses to start and prints where it looked.

Where it looks

Layout	Where
visual-studio	vswhere, then every toolset under VC\Tools\MSVC
visual-studio-llvm	the same installation's bundled clang-cl, under VC\Tools\Llvm
llvm-registry, llvm-program-files	HKLM\SOFTWARE\LLVM\LLVM, %ProgramFiles%\LLVM
msys2, mingw-w64	C:\msys64\{ucrt64,mingw64,clang64}, C:\mingw64
usr-local, usr	/usr/local/bin, /usr/bin — version suffixes included (g++-13)
macports, homebrew	/opt/local/bin, /opt/homebrew/bin
xcode	xcrun --find

Visual Studio is two rows, not one. It ships clang-cl itself, under VC\Tools\Llvm rather than beside cl, and the three LLVM rows all describe a standalone install. A machine whose only clang-cl came with Visual Studio would otherwise advertise no clang-cl toolchain at all — its clang-cl builds would still be cached, since a launcher needs no worker for that, and could never be dispatched, since nothing advertised the fingerprint. vswhere is still run once: the two rows share its answer.

Only the bindir matching this machine's own architecture is offered, from either row. The other holds a compiler built for a different host, which this machine cannot run.

The fingerprint is a digest of the compiler's version banner, its argument grammar and the include tree the compiler owns, so two machines with the same compiler at different install prefixes match, while two machines whose own headers differ do not. A tree the compiler merely borrows — the VC toolset and the Windows SDK, under cl and under any clang targeting MSVC — is left out: a worker compiles text the client already preprocessed and opens none of it, and folding it in split machines on nothing but an installed Visual Studio language pack, whose IntelliSense XML lands in the toolset's include directory (#1656). So two Windows machines need the same compiler version, not the same SDK or the same Visual Studio languages. The banner names the target as well as the version — ... Version 19.51.36252 for x64 — which is what tells the x86 and x64 cl.exe of one toolset apart. Matching is byte-identical and cannot be loosened: an over-strict match costs a local compile, an over-loose one produces a silently wrong object that is then stored under a key other machines fetch.

Computing it walks that tree, which takes a few seconds the first time a machine sees a toolchain and is cached afterwards.

Which tree, per driver. GCC and Clang are asked directly (-E -v) and fold every directory they list — libstdc++, an Xcode SDK. A Clang whose target is *-windows-msvc* folds only its own resource directory, as clang-cl does (-print-resource-dir): <prefix>\lib\clang\<version>\include. cl folds no tree: its banner names its toolset version and target, and everything its layout leads to — the VC\Tools\MSVC\<version> toolset it lives inside, the newest Windows SDK the registry names — is borrowed in the sense above. (Its version it does state — on every invocation, which is why it is asked for it with no options at all.) The layout is still read, for the cache's validity stamp and so a node notices an SDK or toolset update and re-surveys.

Neither takes its answer from INCLUDE, which a developer command prompt sets and a Windows service never inherits — that is why a service-run worker and a developer-prompt launcher agree. cl still falls back to it for a driver outside any VC\Tools\MSVC layout, for the stamp and the re-survey above — never for the fingerprint, which folds no tree under cl; clang-cl never does, since it owns a resource directory it can be asked for.

When no worker matches

The launcher reports not dispatched (rejected (no-worker): ...). Ask both ends what they think the fingerprint is:

pace-cc --print-toolchain-fingerprint /usr/bin/g++   # on the client
journalctl -u pace-node | grep 'serving'     # on the worker

They must be identical. If they are not, the two machines really do have different toolchains — different patch releases, a different Xcode SDK or sysroot, a vendored header that differs. --print-toolchain-fingerprint recomputes rather than reading the cache, so it also repairs a stale entry on its way past.

A node that never appears in the fleet at all

A pinned fingerprint is yours to choose, and it has to be text — specifically, valid UTF-8. So do --advertise and the version the node reports about itself. A scheduler refuses a registration that is not, with malformed-registration naming the offending field, and the node says so at warn when it starts, then at info every ten minutes while it lasts (every heartbeat in between is debug):

scheduler scheduler.internal:6675 did not register a1b2c3:
  rejected (malformed-registration): fingerprint is not valid UTF-8

It is refused rather than cleaned up because a fingerprint is matched byte for byte: a worker admitted under a repaired name would match no client's toolchain and would sit in the fleet registered and never picked. The leader counts it as pace_dispatch_worker_registrations_malformed_total, which is the only trace a peer that never says anything else leaves behind.

The commonest way to produce one is a --toolchain=<fingerprint>=... label typed in a shell whose encoding is not UTF-8. A computed fingerprint is hex and cannot hit this.

After an election, a node re-points itself

The scheduler a node registers with -- its formation record's answer, the fleet's voters it remembers -- is a member of the fleet, not the current leader. A scheduler that is not leading refuses every verb — registration included — and says where the leader is, so a node follows that and announces itself there instead:

scheduler scheduler.internal:6675 is not the leader; announcing to 10.0.0.7:6675 instead

At info, and once — the endpoint that answered is remembered, so a fleet in steady state does not pay a redirect on every heartbeat. Nothing has to be re-pointed by hand, and the record can keep naming a machine that has not led for months.

Two things follow that are worth knowing when reading logs:

• A remembered leader that stops answering is dropped immediately and the recorded scheduler endpoints are tried again in the same heartbeat, not the next one. That is the scheduler 10.0.0.7:6675 unreachable; trying scheduler.internal:6675 line, and it means the node was out of the fleet for a connect timeout rather than for a whole interval. The same line names the next endpoint when one of several does not answer; with none left to try it ends at unreachable.
• That line, and every refusal line in this section, is said at warn once, when it starts -- not once per heartbeat. While it lasts the node says so again at info every ten minutes (scheduler … unreachable -- still, after 600s), and when it ends it says so at the level of the loudest line said about it (scheduler … reachable again after 1260s unreachable). Every heartbeat in between is debug. One scheduler gets at most one warn LOSS (and its recovery) every ten minutes, so a link that keeps dropping, or a scheduler that changes from refusing to unreachable and back, says the rest at info or debug. The worker's heartbeat and the machine's presence announcement share that record, so a machine running both says each change once. While any scheduler does not answer, pacectl node also shows the scheduler-unreachable condition.
• The chain is bounded at two hops. Two schedulers that disagree about who leads — a partition healing — produce gave up following leader redirects and the node simply tries again next heartbeat. Seeing that line repeatedly is worth investigating; seeing it once around an election is not.

A node whose own registration is refused for any other reason still reports it on its own transitions, as above — a redirect is the one refusal that is not a problem.

A change the leader will not record

The flags above are refused by the binary an operator typed them into. The scheduler refuses the same values again when they arrive as a request, whoever sent them — a client built before that check existed, or a peer — because a cluster change is committed through consensus and an entry is applied after it commits, with nobody left to refuse it:

$ pace-node --scheduler=scheduler.internal:6675 --cluster-admit='...'
a member id is not valid UTF-8

--cluster-forget is deliberately exempt, at both ends. Its operand is the offending id, so a check covering it would make a member that reached replicated state through an older peer impossible to remove — and it would count towards quorum forever.

A machine is admitted and forgotten by its key

An address is not an identity, so the cluster records no host for anybody: a machine is admitted by the identity key it proves and forgotten by revoking that key. So a member is never admitted without one -- --cluster-admit=<id>=<host>:<port>@<key>, or a re-admission of a member whose key is already recorded -- and a forget that would revoke nothing is refused by name before it is proposed:

$ pace-node --scheduler=scheduler.internal:6675 --cluster-admit=pc-9=10.0.0.9:6680
pc-9 would be admitted with no identity key; a machine is admitted and forgotten by its key, so give --cluster-admit=pc-9@<key>

A forgotten machine is refused at every door, from any address, once its connection proves the revoked key or presents a ticket signed by it; the refusal is counted as pace_node_requests_refused_key_revoked_total, apart from a stranger's, because a machine you removed and a machine nobody admitted are opposite diagnoses. Only a connection that PROVED the key is told why. One that showed it in a ticket is answered in a stranger's words: a ticket is bytes anybody may have captured, and revoked would tell its holder that the machine was forgotten. On a node that is not --fleet-open, the counter is the only place the two differ. On a --fleet-open node the holder does learn it: an unknown ticket or no ticket at all is served there and a revoked one is not, and the self form of explain-admission answers the revoked ticket refused where a stranger is told admitted, by fleet-open -- the forget biting where it must, and the one place it is visible. The address it used is nothing to anybody afterwards: another machine there is judged on its own key.

Because admission is a fold over several routes -- this machine, --fleet-open, the key a caller proved and the ticket it presented -- the question why is this machine still served rarely has one answer. Ask the node that is behaving oddly:

$ pacectl explain-admission pc-07 --addr=worker-07.internal:6677
subject     pc-07
standing    learner
verdict     admitted
decided-by  proven-key, ticket

It names every route that decided, not only the winning one, and where the machine stands in that node's roster. And because the answer is that node's own fold, two nodes disagreeing about one machine is the finding -- invisible from any single one of them. With no operand it answers about the connection asking, which a machine the node refuses can ask too.

A cache of its own

A node can hold a cache tier in front of the shared pace-kv, and point the launcher at itself:

pace-node \
    --listen-node=6677 --cache-memory=8g \
    --upstream=build-cache.internal:6674 \
    --advertise=worker-01.internal:6677 \
    --cluster-dir=/var/lib/pace-node \
    --toolchain=/usr/bin/g++

export PACE_ADDR=127.0.0.1:6677   # the node, not the shared cache

Why a second copy is not redundant

The shared cache already holds every object, so caching them again on the node looks like waste. What the tier saves is not the compile — it is the round trip. A developer who rebuilds the same tree twenty times a day pays that trip twenty times for objects that never left their machine, and on a slow or lossy link that is the difference between a cache that helps and one that hurts.

Four rules, and none of them is the obvious choice:

• A local hit does not consult the upstream at all. Revalidating would move the round trip rather than remove it. It is safe by construction: an object key is a digest over the preprocessed text, the arguments, the compiler identity and the dependency set, so a key that matches names the same object.
• A local miss populates the tier from the upstream. Without that the tier is a proxy and the second build is exactly as slow as the first.
• A store writes local first, then offers upstream. The local write must not fail for a reason the network chose. Offering it to the fleet is best-effort: a shared cache that cannot be reached costs the fleet one entry and costs this machine nothing.
• An unreachable shared cache is a miss, not an error. Every caller compiles either way, so a build never fails because a cache was down.

scripts/dist-compile-e2e.sh asserts the first of those by stopping the shared cache and requiring the next compile to still hit, with a byte-correct object.

Two halves, each named separately

The tier is an in-memory store, an on-disk store, or both — the same LayeredStorage the daemon's --storage builds, an LRU mirror over a canonical B+tree:

Configuration	What you get
--cache-memory=8g (the default is 25% of RAM, within 512m–8g)	Memory only. Fast, and gone at restart.
--cache-dir=/var/cache/pace-node	Both halves: the memory tier in front of a store that survives a restart.
--cache-memory=0 --cache-dir=…	Disk only.
--cache-memory=0 and no --cache-dir	No tier at all, which is what a node that only compiles for others wants.

A release that changes the on-disk record layout refuses an older --cache-dir store at startup rather than mis-reading it. Convert it with pace-node --migrate-cache --cache-dir=…, with the worker stopped; see Upgrading a store.

--cache-memory takes bytes (k/m/g = KiB/MiB/GiB, or a bare count with an optional B) or a share of host RAM (N%) — the vocabulary its own default is stated in, so "a quarter, but half of that" is --cache-memory=12% rather than arithmetic you do per machine. Zero turns the tier off; it does not mean "unbounded", which is what zero means to the store underneath.

Whatever the node logs at startup can be typed straight back to pin it, and pinning it that way survives --install-service: the flag is written into the unit because you stated it, not because it differs from the default — otherwise typing the machine's current quarter would look identical to saying nothing, and the service would go back to re-deriving from RAM at every start.

The tier's memory is subtracted from what a compile can have. A node budgets one job per gigabyte of RAM, and its own cache is resident memory that is not going to yield — so a 64-thread host with 32 GiB used to offer 32 slots and hold 8 GiB of cache, which is forty gigabytes of promises on a thirty-two gigabyte machine. It now offers 24. The figure travels with the registration, so a node that asks the scheduler to size it (by naming no --slots) gets the same answer at the other end, and a peer too old to report it is sized exactly as it always was.

What is subtracted is what the tier actually holds, not what you asked for. A node that ends up with no tier subtracts nothing and offers the whole machine. Two ways of ending up there leave --cache-memory reading as though it still meant something: --cache-memory=0 with no --cache-dir leaves nowhere to keep objects and so builds no tier, and an emptied --listen-node= opens no port for a tier to answer on. Both used to reserve the configured budget regardless, so on a 32 GiB machine such a node held back the default 8 GiB it was not using and offered 24 slots where it could serve 32. A disk-only cache (--cache-memory=0 --cache-dir=…) is resident nowhere and so subtracts nothing either, which is the one case that was always right.

The default follows the machine because the machines this runs on vary by more than an order of magnitude, and one object file is routinely megabytes: a cache sized for a laptop is close to useless on a 96 GB workstation, and a flat number misses on exactly the rebuild the tier exists to serve. The clamp is what makes a fraction safe at both ends — a small laptop still gets a cache worth having, and a 512 GB build server does not silently take 128 GB resident for one.

--cache-disk caps the on-disk half, which is otherwise allowed to grow as needed — the same default --storage-max-disk has on the daemon. On a build server that is usually right; on somebody's workstation it usually is not.

One node per --cache-dir, and the store enforces it

The store claims its file exclusively for the life of the process, so a second node pointed at one directory refuses to start and says so:

--cache-dir cannot open /var/cache/pace-node/objects.cow: another process
already has this cache open. A --cache-dir belongs to one node; give this one a
path of its own.

If a machine runs several nodes — one per toolchain is a common shape — give each its own path. Nothing is written to the file to do this, so a store is readable by any build either way.

Some filesystems cannot enforce this — network mounts and user-mode filesystems that either refuse to lock or accept a share mode and ignore it. The node checks rather than assumes, starts anyway, and warns that nothing is stopping a second one. That is the only case where the rule is still yours to keep.

Its reads and writes happen on the reactor thread the node's framed surfaces share, so a large store can briefly delay other connections on it (#136). Worth knowing before profiling a node that feels slow under load.

Compressing what each tier holds

Both halves take a codec, spelled exactly as pace-kv spells it, and the two are independent:

Flag	Applies to	Default
--compression, --compression-level, --compression-min-bytes	the --cache-dir half	zstd, level 3, above 256 bytes
--memory-compression, --memory-compression-level, --memory-compression-min-bytes	the --cache-memory half	off, level 3, above 4096 bytes

The disk half has always compressed with zstd; these flags only give you the dial that was already turning. The memory half has never compressed, and still does not unless you say so — turning it on by default would change the CPU cost of every existing node on upgrade.

Naming a codec for the memory tier makes --cache-memory hold more, not less. The in-memory budget counts the bytes a value actually occupies, so compressing them is what lets a given budget hold more entries — compile-cache objects with debug information compress well. What it costs is a decompress on every read, paid on the hit path. That trade is worth making when the working set is larger than the budget and not when it fits comfortably inside it.

Both budgets count what a value occupies after the codec ran. --cache-memory bounds the compressed bytes the tier holds in RAM. --cache-disk bounds the store's on-disk footprint: the pages it has in use — tree, values, its free list's own pages and two meta pages — times the page size, so a compressed value costs its compressed size there too, and compression makes the same budget hold more objects. --cache-disk=36g with zstd is 36 GB of store, holding however many objects compress into it.

The file can briefly be longer than that footprint: pages freed inside it are reused by later writes rather than counted, and each group commit cuts the free pages off its end. pace_tier_bytes_used{tier="disk"} reports the footprint and pace_tier_file_bytes{tier="disk"} the file's length, so both are visible.

Changing a codec needs no migration and no --migrate-cache: every record carries the codec it was written under, so reads keep decoding correctly and only later writes follow the new setting. A store written by a mixed sequence of settings is readable throughout.

none is always available; lz4 and zstd depend on PACE_ENABLE_COMPRESSION, and which half of that rule you meet depends on whether you named the codec or inherited it. A codec you name is refused by name at startup:

--memory-compression=zstd: codec 'zstd' is not available in this build
(rebuild with PACE_ENABLE_COMPRESSION)

The disk half's default is zstd, and a default is typed by nobody and validated by nothing — so on a build without those codecs it is not refused. The tier falls back to storing plaintext, the startup line reports none rather than the zstd that was configured, and a warning says why. That is deliberate: refusing would stop a build that never asked for compression from running at all.

A codec configured for a half this node does not build is refused, because a setting that reaches nothing looks from every surface exactly like one that works: --memory-compression* with --cache-memory=0, and --compression* with no --cache-dir, each name their remedy and stop the node. A default you did not type never triggers this.

All six settings are read once at startup and are not reloadable: the tiers are built as the node starts and nothing can reach them afterwards, so a reload that appeared to change a codec would be a configuration claiming something about a live tier that is not true.

Which codec each tier actually holds is on the startup line, because nothing else reports it — and it is the effective codec, not the configured one, so a build without the codec reads none here rather than claiming a compression it is not doing:

local cache tier (memory 36G zstd, disk 36G zstd at /var/cache/pace-node, upstream none)

--upstream may be empty

That is the honest configuration for one developer's machine, not a broken one: the tier caches locally and never tries to reach a fleet. On a node that runs consensus, an empty --upstream is also what lets the fleet's shared-cache setting decide where the tier reads through to.

An unreachable --upstream

A pace-kv behind --upstream that does not answer -- a dial that does not connect, or a connection that stalls until the per-operation timeout or loses its peer -- is remembered as unreachable for ten seconds. Inside that window a local miss is answered as a miss and a store is not offered upstream, without dialling, so a build with that pace-kv down pays at most one timeout every ten seconds rather than one per miss. The first operation after the window tries again, and one that gets any answer ends the window at once. A store skipped this way counts in pace_node_cache_upstream_store_failures_total, exactly as a refused one does: the fleet did not get the object either way.

Reading it

Eight counters on /metrics, and the splits are the point:

Series	Says
pace_node_cache_hits_total	Served without touching the network.
pace_node_cache_misses_total	The local tier did not hold it.
pace_node_cache_upstream_hits_total	The pace-kv its --upstream names answered after a local miss.
pace_node_cache_fill_failures_total	The upstream supplied it and the local tier refused.
pace_node_cache_store_failures_total	A local write failed — this one is reported to the client.
pace_node_cache_upstream_stores_total	The fleet accepted an object this node offered.
pace_node_cache_upstream_store_failures_total	The fleet would not take it. Zero on a node with no --upstream — see below.
pace_node_cache_requests_refused_not_local_total	A caller that is not on this machine asked this tier for something. The node port faces the network on every node, so this counts other machines: ordinary on a node clients are pointed at for the scheduler — peers reaching the right host for the wrong verb — and, anywhere else, something off-box asking for this machine's build output, which #287 withdrew from peers — give them a shared pace-kv via --upstream.
pace_node_upstream_configured	1 when this node has a pace-kv to read through to (--upstream), 0 when it does not. Absent on a node running no cache at all.

The operator verbs

node-status and node-metrics are answered over the 0xFC port to fleet members, and pacectl node / pacectl node-metrics are what read them. They report what this process is — version, minted identity, uptime, the components it actually started, the ports it opened, and how far its worker has got in identifying the toolchains it will serve — and, through node-metrics, the reading /metrics renders: every counter this build carries, the cache tier's storage and per-tier figures, and the host figures beside them. It is one reading in the encoding a live-stats cache subscription streams, so a node with no --admin-listen still shows what its cache tier holds and how many drops it has served.

That last one is the answer to why is this node not taking any work, and it is the reason these verbs are worth reaching for on a default install: a node serves while it identifies its toolchains, so between start and the heartbeat thread's first completed round it runs a worker that can honour nothing. toolchains reports surveying, serving or nothing-to-serve with the counts beside it; the component mask cannot, because its worker bit is a constant on this binary.

Beside it they report what that worker is offering (compile-slots, compiles-in-flight), whether a scheduler knows about it (registrars-registered of registrars-total, and last-registration-seconds-ago, which is absent when none ever has), and this node's consensus role (scheduler-role, plus the leader it would redirect to). The last one closes the gap the dashboard already covers and the CLI did not: a leading scheduler and a following one are identical in the component mask, and a follower's registry is empty and reads exactly like an idle fleet.

Together that is the first ten seconds of diagnosing a node with no --admin-listen, over a port that is up by definition and gated on fleet membership.

They are gated on membership, and membership is a key: the node checks no password, so there is none to demand. Loopback is always a member; a remote caller is admitted by a key the roster holds — a proof, or a machine ticket — or by --fleet-open. What they hand over is no more than /metrics already serves unauthenticated.

Counter	What a rise means
pace_node_status_requests_refused_not_a_member_total	An operator verb was refused because the caller is not a fleet member: node-status, node-metrics, or explain-admission asked about a machine (asked about the caller's own connection, it is answered to anyone and moves nothing). Unlike the cache tier's not-local refusal this is not ordinary on any deployment: a steady rise is pacectl run from a machine the cluster has not admitted, or has forgotten, and a burst from one host is somebody scanning.
pace_node_status_requests_refused_payload_too_large_total	A header declared more payload than these verbs may carry. node-status and node-metrics are fieldless, so against either this came from no client of this tree at any version. explain-admission carries one subject -- a machine id or a 43-character key -- under its own 512-byte ceiling, and is reachable before admission, so against it this is an operand no roster could name or a stranger probing the port. Never sum it with the cache tier's row of the same name.
pace_node_admission_explanations_refused_malformed_total	An explain-admission arrived that was not exactly one field naming its subject. No shipped client can build one -- the CLI encodes it through EncodeExplainAdmissionRequest -- so a rise is a client of another build or somebody probing the port by hand, and the two are told apart by whether anything else on this surface refuses at the same time. Kept apart from the node-status refusals, which are fieldless verbs and cannot arise from the same mistake.
pace_node_status_requests_refused_endpoint_busy_total	The surface had no bytes left in flight. These are the verbs somebody reaches for when a node is in trouble, so this is the node saying it is too busy to say what it is. Read it beside pace_node_cache_requests_refused_endpoint_busy_total, never summed: this says the diagnosis failed, that says why.

A host the cluster has forgotten

One counter for the whole node rather than one per surface, because the answer does not depend on which door the caller knocked at:

Counter	What a rise means

Never sum it with a ..._refused_not_a_member_total row, and it does not double-count into one: a forgotten host is refused through this counter instead, so the not_a_member rows keep meaning what they always did -- a host nobody ever listed. The two are opposite diagnoses. A stranger is something to go and investigate; a forgotten host is something an operator already decided, and a rise means the other end has not been told.

Zero is the ordinary reading, including on a node with no cluster at all, which never classifies anybody as forgotten. It is an honest zero rather than an absence: the series is rendered by every node.

Live stats

pacectl live-stats subscribes over 0xFC and this node pushes what the dashboard draws, instead of the dashboard polling /metrics and /fleet.txt (#1399).

Counter	What a rise means
pace_live_subscriptions_opened_total	A pacectl live-stats session subscribed and was granted a stream. One per dashboard opened against this node; a climb nobody explains is a client re-subscribing in a loop rather than holding its stream.
pace_live_snapshots_rendered_total	A snapshot was rendered for a subject. Once per subject per tick, whatever the number of watchers -- read it against the opened count: a rate that grows with the number of dashboards rather than with time is the render being paid per watcher again.
pace_live_snapshots_skipped_total	A subscriber was still writing a previous snapshot when the next was due, so it was sent the newest and told how many it missed. The node never waits for a slow watcher; a rise is a slow link or a stalled terminal on the watching side.
pace_live_subscriptions_revoked_total	A stream ended because its peer stopped passing the gate -- a reload or a replicated removal revoked a host that was still watching. Removal fails open unless something re-checks live connections; this is that re-check acting.
pace_live_subscriptions_ended_not_leader_total	A fleet stream ended because this node stopped leading; the watcher was told where the new leader is and follows it. A rise with no election you know of is leadership flapping.
pace_live_subscriptions_refused_at_capacity_total	A subscription was refused because the node already streams to its maximum number of watchers. Long before a team reaches it, dashboards left open everywhere do.
pace_live_subscriptions_refused_unauthenticated_total	A fleet subscription was refused: a wrong or missing dashboard credential, or a remote peer while no --dashboard-token-file is configured. The fleet map is behind the same credential here as on /fleet; a burst from one host is somebody guessing.
pace_live_subscriptions_stalled_total	A stream ended because a single push stayed unwritten past its bound -- the watcher stopped reading altogether, so its buffers were released rather than held.
pace_live_subscriptions_ended_by_client_total	A watching client closed its stream -- the ordinary way a dashboard ends. Opened minus this, minus the ended rows above, is the streams still open.
pace_live_subscriptions_ended_by_reset_total	A watching client reset its connection instead of closing it -- a dashboard killed while pushes were still unread does this. Counted apart from the orderly close, because only a reset says the watcher went away abruptly.
pace_live_subscriptions_refused_not_a_member_total	A subscription was refused because its peer is not a fleet member. Live stats stream to the same peers NodeStatus answers; a burst from one host is a stranger probing the port.
pace_live_subscriptions_refused_malformed_total	A SUBSCRIBE did not decode, or named a subject this build does not serve. No client of this tree sends one; a rise is a client of another build, or not a client at all.
pace_live_subscriptions_refused_payload_too_large_total	A SUBSCRIBE header declared more than the control payload the verb is bounded to, and was refused before a byte of it was read. No client of this tree at any version sends one.
pace_live_subscriptions_refused_endpoint_busy_total	A subscription was refused because the 0xFC listener's in-flight byte budget was full of other requests. The dashboard retries; a rise says the view went missing exactly when the node was busiest.

The fleet document over 0xFC

A fleet-text request reads the fleet document once, one section or all of them, over 0xFC rather than /fleet.txt over HTTP (#1391) -- so a fleet table is readable from a leader that serves no admin surface at all. pacectl fleet <section> is its client, and follows a follower's not-leader to the leader. The text is the route's to the byte: both answer from one function, which parses the section and the range and renders the document, so neither door has a renderer of its own.

It is admitted as the fleet subject of a subscription is, by the same decision: a fleet member, then the dashboard credential (or, with no --dashboard-token-file, this machine only), then leadership. A follower refuses not-leader naming the leader, and the client follows it; a node running no scheduler says the fleet is served elsewhere; a section or a range this build does not serve is unknown-fleet-selector, listing the ones it does. None of those three is counted -- the first two are what a healthy fleet answers a client pointed at the wrong node, and the third is a typo its typist already sees.

Counter	What a rise means
pace_fleet_text_requests_refused_not_a_member_total	A fleet read was refused because its peer is not a fleet member. The fleet is read by the same peers a subscription to it streams to; a burst from one host is a stranger probing the port.
pace_fleet_text_requests_refused_unauthenticated_total	A fleet read was refused: a wrong or missing dashboard credential, or a remote peer while no --dashboard-token-file is configured. The fleet map is behind the same credential here as on /fleet; a burst from one host is somebody guessing.
pace_fleet_text_requests_refused_malformed_total	A fleet-text request did not decode. No client of this tree sends one; a rise is a client of another build, or not a client at all.
pace_fleet_text_requests_refused_payload_too_large_total	A fleet-text header declared more than the control payload the verb is bounded to, and was refused before a byte of it was read. No client of this tree at any version sends one.
pace_fleet_text_requests_refused_endpoint_busy_total	A fleet read was refused because the 0xFC listener's in-flight byte budget was full of other requests. A rise says an operator asked for the fleet exactly when the leader was busiest.

Read the two upstream counters beside the gauge, never on their own. They are cumulative, so a node with no shared cache and a node with one it has not yet written to both report zero — the counters cannot tell those apart and the gauge is what does. Until #214 the failure counter answered the question the wrong way round: a node with no upstream counted every local store as an upstream failure, so a single-machine install reported a 100 % failure rate against a shared cache it never had.

The alert worth writing is pace_node_upstream_configured == 1 and a rising failure counter. That is a fleet whose shared cache is unreachable. Without the first clause it fires on every laptop.

A high upstream-hit rate against a low local-hit rate means the tier is too small for this machine's working set — a different problem from a fleet that is missing a lot, and a different fix. An upstream store failure says the fleet is unreachable; a local store failure says this node is broken.

Beside them, what the tier is holding. pace_items, pace_bytes_used and pace_bytes_limit describe the cache as a whole, and a per-tier set carries the split a merged view cannot:

Series	Says
pace_tier_items{tier="memory"\|"disk"}	Live entries in that tier.
pace_tier_bytes_used{tier=…}	What its budget counts: the stored (compressed) value bytes for memory, the on-disk footprint — pages in use times the page size — for disk.
pace_tier_bytes_limit{tier=…}	Its budget; 0 means unbounded.
pace_tier_file_bytes{tier="disk"}	The length of the disk tier's file, free pages included. Runs ahead of bytes_used by its free pages: those at the end go at the next commit, those inside the file only once later writes reuse them. Never below it. No line for a tier with no file.
pace_tier_evictions_total{tier=…}	Entries it dropped to stay inside that budget.
pace_tier_index_bytes{tier=…}	Resident memory its key index costs. Always RAM, even for a disk tier, so it is not comparable with bytes_limit and must not be added to it.

Do not sum across tiers. The memory tier mirrors what it reads out of the disk tier, so adding the two item counts counts the mirrored entries twice — and the unlabelled pace_* series above are already the cache's own totals. What each label answers is "how is this tier doing": whether the mirror is populated, which tier is evicting, how close the disk half is to --cache-disk.

A tier the node does not run emits no line at all rather than a zero. A memory-only node has no tier="disk" series, which is a different claim from a disk tier standing empty.

It answers where pace-cc already looks

--listen-node defaults to port 6674 on loopback — the address the launcher uses when nobody sets PACE_ADDR, and the one cmake/portable/CompileCache.cmake passes. So the whole thing works with no configuration: start a node, build, and the launcher finds it.

It is one port for every verb family this node answers, and it is the only one. The cache verbs are answered here always; the scheduler verbs are answered here too wherever the node's mode serves them, which a first start's does; and COMPILE is answered here as well, by the same worker, against the same slot count and the same member list. A bare port binds the wildcard, because a scheduler or a worker no peer can dial does nothing. There is no second listen flag to set, and no way for two to end up on addresses that disagree.

A worker used to open a dedicated compile port beside this one, configured by flags of its own. It does not any more: --listen-node is what a worker advertises and what a dispatched compile arrives on, so there is one address to open in a firewall, one address in a lease, and one address to get wrong.

That port is also pace-kv's default, and a node that cannot bind it refuses to start, naming the address — whether you typed it or not. A node opens exactly one 0xFC port; without it, it would still register and advertise that address, and every client leased to it would meet a failed connection and compile locally, in silence. Do not run a node and a pace-kv on one machine: the node answers every verb the daemon does. If you must, give one of them a port of its own.

Whether you typed --listen-node still matters to --install-service: the registration records it when you typed it, whatever its value, and leaves a port you never named out, so the service picks up a changed default rather than one frozen at install time. Until #286 that was decided by comparing your value against the default, so pinning the default port was indistinguishable from never mentioning it.

Who may use it

The cache is this machine's. The fleet and compile surfaces are this machine's and your fleet's, and the fleet's shared cache is your fleet's alone.

Caller	Cache (--listen-node)	Fleet (the scheduler)	Compile (--listen-node)	Shared cache (--listen-node, on the named machine)
A process on this machine	always	always	always	refused — its builds read the tier in process
A machine the roster admits — by its proven key, or a machine ticket it minted	refused	yes	yes	yes
Any caller, on a --fleet-open node	refused	yes	yes	refused
A machine the cluster forgot — its key revoked, from any address	refused	refused	refused	refused
Anyone else	refused	refused	refused	refused

The shared-cache column applies only on the machine the fleet's shared-cache setting names; every other node answers those verbs not-shared-cache (see the named machine).

"Fleet" here is what the scheduler serves -- a lease, a status. What decides the fleet -- --cluster-admit in every form, --cluster-forget, --cluster-set, and the enrollment decisions (--enroll-approve, --enroll-reject, auto-approval, the list) -- is answered only to a caller with an operator's standing: a process on this machine, or a voter of the cluster, by its proven key or the machine ticket its node mints. A caller that only --fleet-open admits is refused identified-caller-required, counted on pace_scheduler_requests_refused_identified_caller_required_total or pace_enrollment_control_refused_identified_caller_required_total; otherwise, on an open node, anybody could approve their own enrollment. A machine the roster admits as a learner is refused operator-standing-required, counted on pace_scheduler_requests_refused_operator_standing_required_total or pace_enrollment_control_refused_operator_standing_required_total: a ticket proves a fleet machine, never an operator, and any process on that machine can have its node mint one. Run the verb on a voter -- the office PC, or any machine promoted to one -- or promote the machine.

The cache column changed in #287, and it is the one breaking change on this page: a fleet peer used to be served this tier and no longer is. The two questions were never the same one. Admission names a machine that may spend this node's CPU; the cache tier is this machine's entire build output, and nothing about contributing capacity makes another machine entitled to read it. A ticket opens it no more than a proof does.

The rule is a property of the verb, not of the bind: a FETCH or STORE whose peer address is not one of this host's own addresses is refused whatever --listen-node was widened to. That is what keeps it true now that the surfaces share one listener, where "it is only bound to loopback" has stopped being available as an argument — on a node that serves the fleet's scheduler the port faces the network by design, and the cache verbs are closed by this rule alone. "This host's own addresses" is loopback plus every address on its interfaces, so a local client dialling the node at its routable address is still local; the set is re-read every 30 seconds, so an address the machine has just been given is refused for at most that long and then works.

The compile column is on ONE port, which is what #290 stage 3 finished: the dedicated compile listener is gone, COMPILE arrives on --listen-node beside the cache and scheduler verbs, and it is answered through the same membership check the dedicated port applied. A caller with no claim on this machine is refused before a byte of its preprocessed source is read.

A non-member now reaches that refusal a step later than it used to. The dedicated listener classified the peer at accept, from the kernel's address, before any byte was read; the merged surface asks per FRAME, at the first point the verb is known — and it has to, because membership is the policy of the compile verbs while the same socket answers cache verbs on locality, so a gate at accept would decide both and make the listener the policy again. The widening is that a non-member holds a connection until it sends a header, bounded by the header timeout and by the surface's maximum open connections. That is the exposure the cache verbs have carried on this listener since #416.

Whether this node verifies the lease a client presents is decided once, at startup, from whether a machine that is not this one could reach the compile verbs at all. --listen-node binds the wildcard on any node that serves the fleet's scheduler, so such a node needs a roster to check leases against, and runs consensus -- whose applied state IS that roster. For one release the question had TWO answers to combine, and asking either alone let an open surface pass: a scheduler with --bind 127.0.0.1 --fleet-open looked local and served unauthenticated compiles on a wildcard-bound port. There is one surface now, so there is one answer again.

Refusals are counted, because this withdrew access somebody may have been relying on:

pace_node_cache_requests_refused_not_local_total

The node port faces the network on every node, so this counts every other machine that asks. If your peers stopped getting cache hits after an upgrade, that counter is where it says so — give them a shared pace-kv via --upstream, which is what a cache several machines read is for.

The policy is the node's, not the scheduler's. The key routes and --fleet-open are read on any node, by all three columns above, so a plain worker admits exactly as a scheduler does. Admitting other machines was once refused on a node that served no scheduler, which left every worker's compile port on the first row of that table and nothing else (#235).

A machine that only asks: tickets

A laptop or a CI runner that runs pace-cc against the fleet never joins its consensus and needs no scheduler of its own, but it is admitted the way every machine is: by its key. It runs a node of its own — the one PACE_ADDR already points at, serving this machine's cache tier — and that node's identity key is admitted to the cluster, as a learner so its absence costs no quorum. A machine that joins by enrollment is one already; one admitted by hand is named with its key:

pace-node --scheduler=10.0.0.1:6675 --cluster-admit-learner=laptop=10.0.0.9:6680@<key>

From then on the launcher asks its own node, over loopback, for a machine ticket for each exchange with another machine — the scheduler, a worker, a remote cache — and presents it in an AUTH pipelined ahead of the command, so it costs no round trip. Every node checks the ticket against the roster it holds, whatever address the laptop dials from. A ticket:

• is signed by the machine's own identity key and names one endpoint, the one it is presented to — a ticket seen on the way to one node is refused at every other;
• lives a minute and is spent once at the node that accepts it, so one captured on the wire cannot be replayed;
• is minted for this machine's processes only: a node answers MINT-TICKET over loopback and refuses it from any other address.

Whoever asks — the launcher, pacectl, or this binary's own operator verbs (--cluster-*, --enroll-*) — gives up connecting to its node after 50 ms. A loopback handshake takes well under a millisecond, while Windows answers a connect to a closed loopback port only after about 2 s, which a machine with no node would otherwise wait out before the verb went anywhere.

pacectl explain-admission says which route admitted a connection, and explain-admission <machine> where a machine stands in this node's roster. A ticket refused is counted by its reason (the node_tickets_refused_* series below).

The compile verbs matter most here. A node that widens --listen-node so peers can dial it would, without a check, let anybody who can route to that port have this machine run their compiler on source they chose. It is refused before the request payload is read — a caller with no claim on this machine must not be able to make it buffer a multi-megabyte translation unit first, which would be a memory-exhaustion hole opened by the check meant to close one.

Two mechanisms, and only one of them is a policy:

• The locality check is the policy, and it is the whole of it for the cache. Every caller that is not on this machine gets a typed not-a-member refusal rather than a dropped connection — member or not, and whatever the surface is bound to. A refusal, so a misconfigured client learns which it is instead of seeing a connection it cannot tell from a dead host.
• The bind is defence in depth and nothing more — and by default it is not even that. A bare --listen-node port binds the wildcard on every node, because the same listener answers the fleet: the socket contributes nothing and the locality check is the whole defence. Narrowing it — --listen-node 127.0.0.1:6674 — keeps a packet from another machine out of the process altogether, on a node no other machine needs to reach, and does not narrow who is served on the machine itself.

Until #287 the bind carried more than that: the policy admitted members, so widening the address really did hand the tier to your peers. It no longer does, and the flag is now a reachability decision rather than a trust one.

That ordering mattered: #290 put the cache and scheduler verbs on one listener, and could only do so once the tier stopped depending on its socket to stay private. On a scheduling node pace_node_cache_requests_refused_not_local_total therefore rises in normal operation — it counts peers reaching the right host for the wrong verb — where on a node nobody points clients at it stays at zero.

This machine is always a member of its own fleet, with no key and nothing to present. Anti-leeching exists to stop other machines spending capacity they do not contribute; a process here already has this machine's CPU. Without that rule a node whose operator had listed their peers would refuse their own builds — a fleet that looks configured and serves nobody locally.

The cache tier is deliberately stricter than pace-kv's own cache, which serves non-members on purpose. That one is shared infrastructure somebody operates; this is a developer's private tier. The two are different things that happen to speak one protocol, and --upstream is how a node reaches the first one.

On a shared multi-user machine, "local" means every account on it. That is the same trust level the daemon assumes, and there is currently no way to narrow it: a node's AUTH verifies machine tickets, which name a MACHINE and never an account on it, so there is no inbound credential that could tell two local accounts apart (#198). If that is not the trust level you want, do not serve the tier — --cache-memory=0 with no --cache-dir turns it off.

A cluster, and who leads it

Every node is a cluster from its first start. It mints a formation record into its state directory — a cluster of one, under a cluster id it draws itself — leads itself, and serves the fleet's scheduler; consensus is what it runs even alone (#178). Every lease it grants is signed with its own identity key, and every worker checks that signature against a roster — the cluster's voters and their keys — that a strict majority of those voters endorse. The roster is replicated state, so even a lone node keeps it through consensus. A machine that joins a fleet joins it as a member too -- a learner, which applies the fleet's state and checks every grant against it -- so there is no other kind of machine in a fleet and no key to type anywhere.

Run several and exactly one of them must schedule at a time. Without consensus every node believes it does — and two nodes handing out the same machine's slots is not a degraded fleet, it is the one thing the architecture says only one node may do. So a fleet is one cluster: one machine founds it and every other machine joins it, and no command line says which. The formation record does. It holds the node's mode, which --print-surfaces prints on its first line, and the mode decides whether the node bootstraps a cluster, whether its consensus port opens and whether it serves the scheduler:

Mode	What the node is	Consensus port	Scheduler
solitary	the cluster of one it minted	open	serves it
pending	still its own cluster, asking to join a fleet	open	serves it
learner	a member of the fleet it joined, counted by no quorum	closed; it dials every voter	none
voter	a member counted by every quorum; a fleet's founder is its first	open	answers while it leads

None of that is a flag. --raft-peer, --raft-join, --cluster-id and --serve-scheduler, which once carried a cluster's shape on every command line, are gone: each would be a second author that could disagree with the record. A command line naming one is refused as a flag this node does not have, and a configuration file naming raft_peer, raft_join, cluster_id or serve_scheduler is refused by name.

A node's identity is its own

You do not invent a name per machine. On its first start a node with a consensus port -- or a worker given --cluster-dir -- mints an identity and writes it into its state directory, beside its Raft log if it runs one; every later start reads it back. That is what the cluster admits, what every vote is counted against, and what survives a rename, a re-image and a restart.

It says which it did, once, at startup:

node identity 3f1c…8a02 (newly minted; this node has not been admitted to any cluster yet)
node identity 3f1c…8a02 (recorded)
node identity n1 (from --node-id, recorded)

Those three are worth telling apart. Newly minted after a restart means the state directory was lost — this node is no longer the member the cluster is counting.

--node-id still works and is an override: give it once and it is recorded, so you need not give it again. It is the right answer when you already run a fleet named by hand.

A minted identity is typed nowhere, and a node must name the endpoint its peers dial — so --raft-self=<host> says it, and the port comes from --listen-raft. Without it (auto, the default) the node is dialled at the address this machine routes from, re-derived when the network changes, and at this machine's fully qualified name until a route is known. --raft-self takes a HOST, auto, or nothing -- never host:port, and never auto:<port>: its port is always --listen-raft's. Both are reloadable.

# The whole of a first node
pace-node --raft-self=10.0.0.1 --cluster-dir=/var/lib/pace-node/cluster ...

An admission has to name a node by the id it actually has, because every Raft message is addressed by member id: a --cluster-admit under a name nobody answers to records a member that receives the leader's replication and has nowhere to send its refusal — admitted, dialled and permanently silent. Read it off the node's startup line, or out of its --cluster-dir:

grep 'node identity' /var/log/pace-node.log
cat /var/lib/pace-node/cluster/node-id

Nothing answers "what is your id" over a port today. If typing ids about is what your fleet does, --node-id on every node is still the shorter road.

The identity belongs to the state directory, not to the machine. Two nodes on one machine need two --cluster-dirs anyway — two Raft logs cannot share one — so they get two identities with nothing to invent. Copy a machine without its state directory and the copy mints its own, which is right. Copy the state directory and you have copied the node, which is what you asked for and is as dangerous as it sounds: two processes holding one identity and one vote record is two voters the cluster believes are one. Nothing refuses that today; see the note at the end of this section.

Deleting the identity file gives this node a new identity, and the cluster must then admit it — the old one stays in the configuration until you --cluster-forget it. That is the safe direction rather than an inconvenience: the vote record went with the file, and a node that came back under its old name having forgotten which term it voted in is how one term gets two leaders.

Its identity key

A node with a state directory — one that runs consensus, or names --cluster-dir — also holds an Ed25519 identity key, in a file called node-key beside node-id. It is minted on the first start from the operating system's random source and read back on every start after, and it says which, once:

identity key 11qYAYKxCrfVS_7TyWQHOg7hcvPapiMlrwIaaPcHURo (newly minted; no cluster has admitted this key yet)
identity key 11qYAYKxCrfVS_7TyWQHOg7hcvPapiMlrwIaaPcHURo (recorded)
no identity key: this node runs no consensus and names no --cluster-dir, so it has no state directory a key would survive a restart in; name --cluster-dir to give it one

The public half is always shown whole — 43 characters of unpadded base64url, never abbreviated — and it is the string to compare between machines: pacectl node reports it as public-key, and --cluster-status and pacectl cluster-members show the key the cluster has recorded for each member. The secret half never leaves the machine and is never logged.

A key file that is there and cannot be used is refused, never replaced. Unreadable, cut short by a crash, not a key file at all, written by a build that lays keys out differently, or damaged so its two halves disagree: each stops the node with a sentence naming the file and what is wrong with it. Replacing it would make this machine a stranger to a cluster that may already have admitted its key, with nothing anywhere saying why. Removing the file deliberately mints a new identity, which the cluster must then admit. Only a file that is absent is minted.

A node with no state directory holds no key rather than one minted afresh at every boot, which would be a new machine at every boot. Its working directory is no place to keep one: under the packaged unit it is a runtime directory emptied at every boot, and under the Windows SCM it is System32.

The file is readable by its owner and the administrators alone, whoever created the directory it is in: on POSIX mode 0600, on Windows a protected access list of SYSTEM, Administrators and the file's owner. It is created that way -- the list is part of the create, and on Windows nothing else can open the file while the key is written -- and the protection is read back before the key goes in; a file whose protection does not read back is removed and the node refuses to start, saying so.

The key is this node's only if nobody else could have put it there. A state directory other accounts can create or delete entries in is refused, with the commands that restrict it: on POSIX chmod go-w; on Windows TWO commands, run in order, icacls <dir> /inheritance:d and then icacls <dir> /remove:g over the broad groups. One command does not work on a directory that inherits its grants, as one under %ProgramData% does: it reports success and removes nothing. Restricting the directory also takes away any read an older key file there inherited, so when the key is readable by other accounts the refusal asks the key's question too (below), in the same message: answer it before running the commands, since afterwards nothing shows the key was ever exposed. The sticky bit is no exception: it stops other accounts removing an entry, not creating one that is not there yet. A directory the node creates itself is created its owner's alone. A key file owned by another account -- neither the one the node runs as nor an administrative one -- is refused, naming the owner, and so is any link in the directory: the node writes none, and a link's owner says nothing about the file it points at.

The same holds for every file the node keeps in its state directory: the id, the formation record, the consensus store (raft-state, raft-log, raft-snapshot), the remembered cluster endpoints (fleet-endpoints) and the roster. One owned by another account refuses the start, naming the file, what it holds and its owner, and is left as it is. Ownership is judged from the account asking. On Windows an elevated administrator running --print-surfaces, which writes nothing, counts the files and the directory of the node's own service account, NT SERVICE\<--service-name>, as the node's own, so --print-surfaces over a running service's directory judges the line as the service will run it. A start, foreground or as a service, --print-identity (which mints a key and an id where they are absent) and --install-service keep the strict rule: a foreground start by an administrator over the service's files is refused, as before. On POSIX nothing changes: root does not count a service user's files as the node's, so sudo pace-node --print-surfaces over a dedicated user's directory is still refused -- judge it as that user. A file of any other account is refused; judge it as the service it belongs to, and remove it, or move the consensus store aside, only when nobody but this node should have written it. A directory that cannot be read ends the command, or the start, once and with that reason, before any setting is judged against a mode the node could not read: a read that failed (a listing refused, an access list that would not answer) exits 1 and is retried by the service manager, a verdict on what was found exits 78. Any entry the node does not keep is refused too. The history files are the exception, because a history may never keep a node from starting: one owned by another account is set aside with a warning, not read and not written over, and the node keeps no history there until it is removed. The key is the only file there created readable by its owner and the administrators alone; every other file takes the directory's own list, which is its owner's alone (or the node refuses the directory) and carries the service account's grant, so a file an elevated command wrote stays readable by the service.

A key file that other accounts on the machine can read is refused, and left as it is. Whether the key was read while it was exposed is a question only you can answer: if nothing can have read it, restrict the file with the command the refusal prints and start again with the same identity. Otherwise treat the key as disclosed, and what that takes depends on the cluster. A node that is its cluster's only voter -- a node started with no cluster flags is one -- cannot be forgotten (--cluster-forget refuses to remove the only voter): remove the key and the consensus state the refusal names, and start it again as a new one-voter cluster. A member of a larger cluster is forgotten with --cluster-forget=<its id> against the leader, then the key is removed and the new one admitted. The file is also one of the secrets this node re-checks at every reload, with the same owner-only remedy. --install-service mints no key: the service mints its own at its first start, as the account it runs as.

@<key> states a member's key on --cluster-admit and --cluster-admit-learner, after the address: --cluster-admit=n2=10.0.0.2:6680@<key>. A key the grammar cannot read is refused where it is typed, with the sentence that says what a key looks like. Both verbs carry the key to the leader, which reads it once more and refuses one that is not a key, or one the cluster has revoked, before anything is proposed. The receipt prints the key the leader recorded. Without @<key> an admission keeps whatever key is already recorded, and a member's key also reaches the cluster from the member itself, which announces the key it holds when it leads.

Every consensus connection proves these keys: the node at each end signs the handshake with its own key, and the other checks the signature against the key the cluster records for the id it claims -- or, until the cluster has recorded any, the key the roster it started from names: its own alone on a node that founded its cluster, the approved enrollment roster on one that joined. A member admitted without a key cannot be verified. What that refuses, and how a refusal reads, is under Raft peer authentication. Every lease is signed with it too: a grant carries the id of the scheduler that issued it and that scheduler's signature, and a worker verifies it against the cluster's roster of voters, unrevoked (#178; how a worker that runs no consensus comes to hold one is under the lease token). Discovery and enrollment prove these keys too, and hand no secret to anybody. The cluster key is still what the node port uses (#178 moves it next).

--print-identity is how you learn a node's key before it is admitted. Run it with the flags the node runs with, as the account the node runs as -- it mints the id and the key into the state directory when it holds none yet, and a key file another account created is one the service cannot read -- and it prints the three things an operator admitting it needs.

On Windows a service's virtual account cannot be run as by hand, so start the service FIRST. It mints its own key, and an elevated --print-identity afterwards READS it -- the administrators may read every key file. The other order mints the key owned by Administrators, which the service's account cannot read; its start then refuses the file as unreadable and prints the command that hands it over, icacls "<key file>" /setowner "NT SERVICE\<service name>".

node-id n1
public-key 11qYAYKxCrfVS_7TyWQHOg7hcvPapiMlrwIaaPcHURo
cluster-admit n1=10.0.0.1:6680@11qYAYKxCrfVS_7TyWQHOg7hcvPapiMlrwIaaPcHURo
state-directory C:\ProgramData\pace-node (machine-wide: this process runs privileged, so it is the machine's own node)

The cluster-admit line is the value --cluster-admit takes to admit this node with its key, and the first start afterwards reads the same key back (recorded). A node that could name no address its peers dial yet prints no line rather than a guessed one. Without a state directory there is no identity to print, and it says so. The state-directory line says whose identity this is: one that reads per-user was printed from a prompt that is not elevated, kept under that account's own directory, and is not the identity the service runs as -- admitting its key admits a machine nobody runs.

Removing a machine is revoking its key. A revoked key is refused on every connection, the connections it proved close at their next message, and its redial is answered with a signed your key is revoked. Nothing on any other member changes -- no key is rotated anywhere, which is what a key per machine buys over a key shared by all of them.

Consensus is on unless an empty --listen-raft= turns it off -- which only a cache-only node (--slots=0) may do: a node with consensus closed never forms or joins a fleet, so a worker on it would have nowhere to register, and it is refused at startup naming both remedies. With consensus on, two things have to hold. Each is decided by the command line alone, so each is refused at startup and at --install-service, where you are watching, rather than at every boot into a log nobody reads:

What has to hold	Why
this node names where its peers dial it, by --raft-self or — with auto, the default — by the address it routes from, or this machine's resolved name until a route is known	The address its peers dial is the half only it knows: a node that could name none could never win a vote and could never be voted for. A name that resolves to nothing is refused; one that reaches only this machine (localhost) confines consensus to loopback unless --raft-self names it: the node runs as a fleet of its own, with its own scheduler and worker, and can neither form nor join a fleet.
--listen-raft names a usable port	That is where every peer dials it. A value that is not an address is refused with the text you typed.

The reverse holds too: --raft-self without consensus is refused rather than ignored, since there is no port to pair the host with and nothing would say so. Whether a node runs consensus is its mode, kept in its state directory, so the refusal names one of two causes: an empty --listen-raft= that closed the port its mode opens, or a state directory whose formation record could not be read -- the mode is then unknown, and the refusal carries the reading's own refusal, the same reason --print-surfaces prints on its mode: none line. (--node-id and --cluster-dir are not refused there — the node keeps its identity in that directory, and the dashboard its history file, so a node with no consensus still has a use for both.)

Two ports, and why a member records both

A member's record names its consensus port. A client that is redirected to the leader needs the scheduler port, which is a different number, so a member carries both — and that is a correctness matter rather than a convenience. A follower refusing a client answers NotLeader with the leader's endpoint, and while only one address was recorded that endpoint was the consensus one: the client took the advice and spoke the scheduler protocol at a socket that has never heard of it.

Every member's record carries its 0xFC endpoint, learners included, because anything resolving a machine reads it — the redirect reads the leader's, and a shared-cache resolver reads any member's. It is the member's own word, and only the node itself knows it: the endpoint it advertises (--advertise, by default its node port with a wildcard host replaced by the address this machine routes from). It is recorded when the member's enrollment is approved, from the endpoint its join request stated, and moved afterwards only by that machine's own announcement on its presence loop, made under the identity key it proved on that connection: the leader re-proposes the member's record with the new endpoint, keeping its seat and its key. A leader also asserts its own on every reconcile pass. So an accepted reload of --advertise, or a move of the address it routes from, reaches the record within one announcement interval, and nothing a machine merely claims without proving it moves any record.

The announcement moves the consensus endpoint too, for a voter whose two recorded endpoints are on one host — every voter that leaves both flags at auto. The leader keeps the recorded consensus port and takes the announced host, so a voter that changed networks is dialled at its new address rather than lost. A voter that pins --raft-self to a host other than its --advertise one is never moved this way: it said where each answers, and its consensus endpoint moves only by its own word while it leads, or with its discovery beacon. A beacon sent before a move cannot move a coupled voter back, and host names are compared as spelled, so Office.lan and office.lan count as two hosts.

A member that has announced none — a bootstrap peer typed with --raft-peer, before its first announcement — carries no scheduler endpoint, which is not a fault: a follower answering NotLeader with nothing is exactly the "an election is in progress" case a client already handles by compiling locally.

What the log carries

Cluster configuration and nothing else: who is a member, where they answer, and the handful of settings every member must agree on. Not the cache — a log is replicated to every member and kept until it is snapshotted, and multi-megabyte objects written constantly are the opposite of what belongs in one. Cached objects live in the pace-kv this state merely names.

Setting	Means
fleet-open	1 to admit every caller to the fleet, 0 for members only
lease-lifetime	how long a compile lease lives end to end, as a duration (20min)
shared-cache	the id of the member every node reads through to as the fleet's shared cache, empty for none — see the fleet's shared cache

A key the build does not know is refused when it is proposed, not stored. The alternative is a typo replicated to every node, snapshotted, carried across restarts — and doing nothing, with the only symptom being that the thing you configured did not happen.

upstream was in this table and is not any more, and the build refuses the key by name. A node reads through to the pace-kv its own --upstream names, and it presents its own --requirepass credential there on every fetch and every store — so a replicated address would decide where every member sends a secret that is configured per machine, and one committed entry would redirect all of them. The refusal says that and names the flag, rather than answering no such cluster setting, which reads as a typo or as a node too old (#1123). Nothing read the setting, so there is nothing to move: --upstream on the node that reads through is what has always decided this.

shared-cache is the replicated way to say the same thing, and it is safe where upstream was not:

• it names a member by id;
• a node sends nothing until that machine proves the key the roster holds for it;
• the leg carries no credential at all.

So one committed entry can move where the fleet's objects go, but never where anybody's secret goes. The refusal of upstream names it.

Membership at runtime

The formation record decides the bootstrap set: this node alone where it founded its cluster, the approved roster where it joined one. Once the cluster is running, membership is a replicated log entry, and that is what makes a node admitted at runtime survive a restart without anybody editing a config file on any machine.

The agreed keys join the fleet's admission policy directly, so a machine the cluster admitted is served by the surfaces membership governs — its compile port, the scheduler and, on the machine the shared-cache setting names, the fleet's shared cache — by the key it proves or the ticket it presents, whatever address it dials from. Not the cache tier: since #287 that one serves its own machine and nothing else, whatever the roster says.

Most of the machines that spend a fleet's capacity are not peers — a laptop, a CI runner, anything running pace-cc against the fleet — and they are admitted the same way, as learners that never vote: see a machine that only asks.

It reaches consensus too. The leader moves the quorum to match the member set one machine at a time, so a node the cluster admitted votes, is counted, and is dialled by the peers that admitted it. Growing a cluster never means restarting its existing members — only the new machine is started.

Adding a machine to a running cluster

A machine joins a fleet rather than founding one, and it is admitted rather than configured: nothing on its command line says which fleet. It starts as every node does, a cluster of one, and is admitted through enrollment: it asks a member, an operator there approves its key, and it dissolves its own cluster and becomes a learner of the fleet's, recorded so in its formation record — every later start comes back as that learner.

A member can also be recorded directly, from any machine, with the id and consensus endpoint the joining machine prints (--print-identity):

pace-node --scheduler=10.0.0.1:6675 --cluster-admit=n4=10.0.0.4:6680

It prints back the three things the leader wrote down:

recorded, as received:
  member id           n4
  consensus endpoint  10.0.0.4:6680
  identity key        none stated (a key already recorded stays)
  seat                voter (the verb this request was sent as)

Appended, not committed: a majority has to take it, and this leader cannot
see that yet. Ask for the cluster state again to see the result.

Compare the first three lines against the machine itself -- the id it minted
into --cluster-dir, the consensus endpoint its own --print-surfaces prints,
and the identity key `pacectl node` prints against it. Each is one
thing spelled on two machines, and nothing else
compares them.

--cluster-admit=n4=10.0.0.4:6680@<key> states the member's identity key as well, and the receipt then prints the key the leader recorded in place of none stated.

The seat is not an echo: the leader's receipt does not carry it, because it can only have answered the verb it was sent, so it is printed as what it is.

Read both lines against the machine you are bringing in, because that comparison is the whole reason they are printed. The address typed here and the one that node answers consensus on — --raft-self together with --listen-raft — are two spellings of one address, and nothing compares them for you. The id is the same story: the joiner mints its own into --cluster-dir, and the one typed here has to match it.

The machine prints its half under the same label. pace-node --print-surfaces, run with that machine's own flags, follows its table with a dialled at: block naming the consensus endpoint, and pacectl node against the running node reports it as consensus-endpoint:

dialled at:
  consensus endpoint  10.0.0.4:6680  -- what peers DIAL; the raft row above is what this node BINDS

Compare against that line, never against the raft row of the table. The row is the address the node BINDS, and a bare --listen-raft binds the wildcard, so that comparison fails on every correctly configured machine and teaches you to ignore it. A node running no consensus prints the line as absent, never as an empty address, and one running consensus that names itself neither way prints NOT STATED and the two flags that would state it.

When they disagree the result is a member that is in the cluster's configuration and contacts nobody. At three members or more that presents as an election storm which then settles, so the symptom points at consensus rather than at the character you mistyped — which is why one address can cost an afternoon, and why comparing two printed strings is worth the ten seconds.

Recorded is not in force, and the report says so. The leader knows what it wrote into the command the instant it writes it; whether a majority has taken it, it cannot know until one answers. So the wording stops at appended — ask --cluster-status again to see the result.

A node that founded a cluster of its own is never admitted to another as it stands. It has elected itself, taken a term and a log of its own, and afterwards refuses AppendEntries from every leader its own configuration does not name; a cluster that admitted it would count towards its quorum a machine that answers nobody, and two clusters cannot be merged by any local rule. So a joiner dissolves its cluster before it adopts the fleet's roster, and starts from an empty configuration, which it learns from the leader's first message.

That is also why it reaches the fleet's voters itself, and it is load-bearing rather than convenient. A leader admitting a new member starts replicating at its own last index; the joiner's log is empty and refuses that; and the leader only walks back to the beginning when the refusal reaches it. A joiner that cannot send one is admitted, dialled, and permanently silent.

Discovery finds the fleet's members and where they answer — see below. It does not supply the admission: that is still the enrollment's approval, or the --cluster-admit above.

Nothing about the existing members changes. They are not restarted, their command lines are not edited, and the new member survives their restarts as well as its own, because it is a log entry rather than a flag.

A machine that is usually away: admitting a learner

A member admitted with --cluster-admit is a voter: every quorum counts it — the one that commits an entry, the one that elects a leader, and the one a leader checks it still has contact with. (A machine that joins by enrollment is a learner until you promote it — see below.) That is right for a machine that is always on, and wrong for one that is not. In a cluster of an always-on node and a laptop, the laptop leaving the VPN costs the always-on node its majority, so it stops leading at its next check: the scheduler answers NotLeader, and the fleet page and history go dark until the laptop comes back (#178).

Admit such a machine as a learner instead — the same token:

pace-node --scheduler=10.0.0.1:6675 --cluster-admit-learner=laptop=10.0.0.9:6680

A learner is replicated to and counted by nothing (#1449):

• it receives the log and snapshots and applies them like any member, so it holds the same cluster state, and it serves whatever surfaces its other tiers serve;
• it never stands for election and never votes. A learner asked for a vote refuses it — an explicit refusal, not silence — and one whose election timer would have fired has no election timer at all;
• it counts towards no commitment and no leadership check, so its absence costs the cluster nothing: the always-on node above keeps leading while the laptop is away, and restarted on its own it becomes leader again with no one else present;
• it can never be the leader.

It answers as any follower does, and that includes writes. A learner follows the leader it hears from, so its scheduler asked for anything a leader must decide answers NotLeader naming the leader's scheduler endpoint, exactly as a following voter's does — clients and the one-shot verbs follow that redirect the same way. Before it has heard from any leader it is undecided, as every node waiting to be admitted is.

Promotion and demotion are re-admissions. --cluster-admit on a learner promotes it; --cluster-admit-learner on a voter demotes it. The cluster moves one member at a time, in a fixed order — additions, then promotions, then demotions, then removals — because a configuration change that moved two voters at once could give the old and the new configuration majorities with no voter in common. A demotion that would leave the cluster with no voter at all is never proposed.

A voter is counted only once it has caught up (#1537). Every member enters the configuration as a learner — an admitted voter too — and one recorded as a voter is promoted once its address can be dialled and it holds every entry the cluster has committed. Counted any earlier, a voter that is away makes every commit wait for it: in a one-voter cluster the promotion itself cannot commit, and nothing after it can either. So promoting a machine that is away costs the cluster nothing until it returns. --cluster-status shows seat=voter throughout, since that is the record; the machine's own consensus-standing says learner until it is counted, and the leader says why, once, and again at Warn if it is still waiting after thirty seconds:

cluster: n2 is recorded as a voter and counted as a learner until it has caught up: it holds entry 3 of the 17 committed

A learner is removed on exactly the terms any member is — --cluster-forget — and never for being absent: nothing here asks whether a member answers.

--cluster-status shows which seat each member was admitted into (seat=voter or seat=learner). That is the record the leader is moving towards, so for a moment after an admit it can run ahead of what consensus counts; pacectl node against the machine reports consensus-standing, which is what consensus counts that machine as now, and each node logs it whenever its configuration changes:

consensus: this node counts 1 member(s): n1; learners, counted by no quorum: laptop; it is a voter

A learner that should be promoted before the voter it replaces is retired is promoted first and forgotten second — the fixed order above does that for you if both are recorded at once. And the one thing a learner cannot do for you: if the only voters are gone for good, a learner cannot take over, because it was never part of the majority that decides. Promote it while a voter is still there to commit the change.

Enrolling a machine instead of typing it

The two commands above need the operator to know the joiner's id, its consensus address and its identity key, and to type all three correctly on a machine that is not the one being added. The enrollment window is the same expansion asked for from the other end: the joiner states who it is and which key it holds, an operator compares that key and approves it, and the cluster's roster travels back — every member's public key, and no secret at all (#178).

The leader records every request, and the approval is the gate. Nothing crosses but public keys and the roster, so there is no window to open first: a request is put on a bounded list, and nothing on it is admitted until an operator approves it.

The list holds 64 requests, and one address holds at most 4 of them that nobody has decided about — so one machine asking under ever-new ids cannot fill it and keep every real joiner out. A NAT or a VM host with more machines behind it than that enrolls them a few at a time: an approved or rejected row stops counting at once. Past its share an address is refused enrollment-host-full and counted in pace_enrollment_requests_refused_host_cap_total, apart from a full list. If many addresses fill the list anyway, drop everything nobody has decided about:

pace-node --scheduler=10.0.0.1:6675 --enroll-clear

Approved and rejected rows stay, the leader logs which ids went, and pace_enrollment_requests_cleared_total counts them. It bans nobody: a machine still asking is recorded again at its next poll.

The joiner asks by itself. A node whose formation finds a fleet it should join -- by the LAN beacon, or at --fleet-seed where no beacon reaches -- asks that fleet's leader to admit it under the identity key it minted into its state directory, and polls until somebody decides, serving its own cluster of one meanwhile:

pace-node --fleet-seed=10.0.0.1:6675 --cluster-dir=/var/lib/pace-node

It asks as a learner, the one role a machine joins as: approved, it applies the fleet's replicated state, counts towards no quorum, and registers its worker with the fleet's scheduler. Its --print-identity prints the key to compare.

On Windows, install and start the service FIRST, for the reason --print-identity gives: an elevated command run before the service's first start mints the identity key owned by Administrators, which the service's account cannot read. Its start then refuses the key as unreadable and prints the command that hands it over, icacls "<key file>" /setowner "NT SERVICE\<service name>". Every other state file takes the state directory's list, which carries the service's grant, so the service reads those whoever wrote them. Any state file the node cannot open is refused with the same command naming that file.

No --node-id, and it matters less than it did. The mode mints one into the state directory — a node is its state directory — as 128 bits of randomness in 32 hex characters. The id is a label; the key is the credential, so a short guessable id can no longer be answered to. It can still be squatted: whoever asks first under an id holds that row, and the key comparison below is what catches it.

While it polls, the window's holder reports what is waiting:

pace-node --scheduler=10.0.0.1:6675 --enroll-list

Each row names the id and the role the machine claims, the consensus address it claims, the host the kernel says the request came from, and its key, whole. Compare that key with the one the joiner printed before you approve: the comparison is the whole of what makes an approval safe. Nothing secret changes hands, so what somebody between the two ends can do is substitute a key of their own — and the key on the row is exactly the key an approval admits.

The row keeps the first key its id asked with. A later poll under that id with another key is another machine: it is counted on the row's "later poll" mark, answered as still pending, and never recorded — so a key cannot be swapped between --enroll-list and --enroll-approve. A joiner that genuinely minted a new key (a wiped state directory is a new machine) is enrolled again once the leader has forgotten the old row — a restart of the leader forgets every row.

Every request is signed by the key it asks with, over everything it states, and the leader checks that signature before it lists or refreshes anything. The id and the key are public — a beacon carries the key — so without it any host could poll under a joiner's id and key with an address of its own, and the address an approval recorded would be whoever polled last. A request that does not verify is refused and counted (pace_enrollment_requests_refused_forged_total), and the row does not move.

The claimed address and the observed host are shown side by side and never checked against each other — #242 settled that enforcing agreement refuses the documented setup and stops only a third host — so a disagreement is marked for a person to read rather than refused.

Each row also shows the host it first asked from (first from), which never changes, and marks a row whose machine has since asked from another address. One host holds at most four undecided rows, counted by that first address. So when a request is refused because its host is at its cap, the refusal names the host as first from shows it. The four rows are the ones carrying that host, wherever their machines ask from now.

Approving admits the machine under the key the approval NAMES, as a learner, from inside the cluster. --enroll-list prints this line, ready to paste, for every row nobody has decided about:

pace-node --scheduler=10.0.0.1:6675 --enroll-approve=<id>@<key>

The key is required, and it must be the one the row holds, or nothing is admitted and pace_enrollment_approvals_refused_key_mismatch_total counts it. An id alone names a row, and a row whose machine stopped asking is replaced by the next machine to ask under that id — which an approval by id would have admitted without anybody comparing its key.

An id the cluster already seats is refused by name — already a member as voter; an approval does not change a member's seat — rather than approved into a different seat. A machine the cluster already records under the key it asks with needs no approval at all: it is answered the roster straight away, whichever node leads.

pace-node --scheduler=10.0.0.1:6675 --enroll-reject=<id>

The list is held in memory on the leader and nowhere else, so a restart forgets everything pending, and so does a change of leader: a node that stops leading drops its list and lowers enrollment-requests-waiting, and every joiner still asking is sent to the new leader and recorded there.

Rolling out many machines at once is a deadline, not a mode. An armed auto-approve window admits every machine that asks before it ends, as a learner, under the key it asks with — with nobody comparing that key — including a machine already waiting when it is armed, at its next poll, so a row that must not be admitted is rejected first:

pace-node --scheduler=10.0.0.1:6675 --enroll-auto-approve=30min
pace-node --scheduler=10.0.0.1:6675 --enroll-auto-approve=off

It is at most 24h; running it again re-arms it from now, and =off ends it. It is held in the leader's memory alone, so a restart ends it, and so does a change of leader — a leader that loses leadership and wins it back does not resume admitting. While it is armed, enrollment-window-open is raised naming the deadline and when it was armed, and pacectl node reports auto-approve (N min left). Afterwards, --enroll-list marks every row the window admitted with when the window was armed, and pace_enrollment_approvals_auto_total counts them apart from the approvals a person made — the question after a window is who got in while nobody was looking. A later poll under an id with a different key is still never auto-approved: the row keeps its first key whether or not the window is armed.

--enroll-list shows the fingerprint of the roster each joiner was sent. The approved reply is answered only once the leader's own roster records the joiner, and the joiner refuses a roster that does not record it under its own key — either somebody approved a different key for this id, or something rewrote the reply. The joiner's row on the list shows the fingerprint, SHA256: and 43 characters, of the roster the leader SENT it. The fingerprint is per row, because the roster moves with every admission and a batch of approvals would otherwise make every joiner disagree with the list for a reason that is no attack at all.

A lost reply costs nothing. An approval is answered on every poll — a roster is no secret — so a joiner whose reply went missing simply asks again. There is no spend, no re-approval and nothing to re-arm; that whole mechanism existed because a key handed over could not be handed over twice, and it went with the key.

Enrollment hands over no secret at all. The cluster's pre-shared key it used to carry is gone (#178): every wire proves a node's own identity key, so an admitted joiner needs nothing placed by hand. A learner applies the fleet's state, so it checks the grants it is handed from its first round with nothing typed.

pacectl node carries the window's mode and the number waiting, and pace_enrollment_requests_refused_full_total counts the requests a full list turned away.

A joiner that already ran a cluster of its own

Every node has: its first start founds a cluster of one. So enrollment does not refuse consensus history, it archives it. Once a joiner is approved, its solitary store — the term, the vote and the log it wrote while it led itself — is moved out of --cluster-dir and kept beside it, and the node starts as the fleet's learner from an empty configuration. That move is the dissolve above, and it is what keeps the joiner from refusing AppendEntries from every leader its own configuration does not name — the silent failure a joiner that kept its store would have: enrolled, admitted, counted towards the quorum, and answering nobody. Nothing is wrong until the leader goes and the cluster cannot re-elect.

The store is archived rather than deleted because it is the only account of the cluster the node ran, and the identity is kept: the id and the key are what the operator approved, so the joiner that starts is the member the fleet recorded. Clearing only the log of a node that stays in the SAME cluster is the opposite case and the wrong fix — a machine the cluster believes it already knows, with the same id and no vote record — and enrollment never does it.

This is not a startup rule either. The startup table judges a configuration this node will serve with, and a directory holding consensus history is exactly what every healthy running member has.

Changing it while it runs

The log carries the cluster's configuration so it can be changed without editing a file on every machine and restarting them. Three flags ask a running cluster directly, and each exits when it has an answer:

pace-node --scheduler=10.0.0.1:6675 --cluster-status
pace-node --scheduler=10.0.0.1:6675 --cluster-set=fleet-open=1
pace-node --scheduler=10.0.0.1:6675 --cluster-admit=n4=10.0.0.4:6680
pace-node --scheduler=10.0.0.1:6675 --cluster-admit-learner=laptop=10.0.0.9:6680
pace-node --scheduler=10.0.0.1:6675 --cluster-forget=n3

--cluster-status prints the members — each with the seat it was admitted into, voter or learner (see admitting a learner) — the settings, and every key this build knows — because the question an operator usually has is "what can I set", and a report listing only what somebody had already set would answer it wrongly by omission.

A member with no scheduler endpoint says why: scheduler=- (never-announced) is a member that has announced none, and scheduler=- (cleared) is one whose record was re-proposed with none. A --cluster-admit or an enrollment re-approval keeps the endpoint already recorded, since the same machine at the same port has not moved; a cleared endpoint comes back when that member next announces. The fleet page's scheduler-endpoint-state column says the same.

lease-lifetime: telling the fleet your translation units are long

pace-node --scheduler=10.0.0.1:6675 --cluster-set=lease-lifetime=40min

A duration: a whole number and one of ms, s, min, h, d. The default is 10min and the ceiling is 1h. A bare number is refused when it is set; a value committed while this setting was a count of milliseconds (2400000) is no longer readable, so the scheduler grants the default and says so once in its log, naming the value — set it again in the new spelling.

It is the lifetime of a LEASE, end to end — not how long a compiler may run. The span it covers is the whole dispatched job: uploading the preprocessed translation unit, waiting for a slot on the worker, the compile itself, and the object coming back. Sizing it to your slowest compile sizes it too small, and the symptom is the one this setting exists to remove — a translation unit that is distributed, compiled, and then thrown away because everybody stopped waiting.

One number, because three machines have to agree on it. The scheduler reclaims the key at that bound, the worker stops serving at it, and the client stops waiting at it. There is deliberately no node-side flag: a worker told to serve longer than the fleet agreed produces an object for a key the scheduler has already re-granted, so the work is done twice and one result is discarded, with every counter reading normal. Being replicated is what makes two members disagreeing about the value impossible rather than merely unlikely — there is one value, in the state every member reads.

In-flight leases keep the bound they were granted under. Changing this does not move the expiry of a grant already issued, so a build running when you change it finishes under the old value at all three ends.

Two things stop being free as it grows, which is why there is a ceiling. A worker restart empties its record of which grants have already been spent, so a captured grant is replayable once afterwards for whatever is left of its lifetime — the expiry is what bounds that window, and a rolling upgrade is a fleet of restarts. And a member uploading a translation unit may hold a compile socket for up to the ceiling. Both are bounded by this number, so it is an hour rather than something rounder: six times the default covers "our translation units are long" with room, and a site whose single translation unit exceeds an hour has a build problem no lease lifetime fixes.

A value at or below the 30-second silence budget is refused, not clamped: below it a healthy worker's own scheduling jitter outlives the job, and the fleet reads as stopped. So is a value above the ceiling, and so is anything that is not a plain number of milliseconds — 600000ms and 600 000 are both refused rather than half-read. Refusals arrive from the leader before the change is replicated, so a rejected value is an error you see rather than a setting that quietly does nothing.

What tells you it is too short: pace_dispatch_leases_released_late_total on the scheduler — a client reporting back after its own lease had expired, which is a real compile that outran the bound — and pace_worker_jobs_refused_lease_expired_total on the workers. Both mean a job outlived its lease, and both are the signal to raise this number. Neither counts leases that merely expired: a client that never reports back reaches neither.

They go through the same gate as everything else on that port, which for a read is worth stating: a follower's copy of the state is perfectly valid and merely older, so --cluster-status could have been answered by any member. Refusing and naming the leader keeps one rule for the whole surface — a verb added without the gate is the regression the arrangement exists to make impossible — and it sends you to the node you would have needed anyway to change anything. A follower answers with where to ask instead:

pace-node: this node does not lead the cluster; ask --scheduler=10.0.0.2:6675 instead

A non-member is refused too, and here anti-leeching is not about capacity: a stranger who could set fleet-open would admit every caller on the network to the fleet. This paragraph named upstream until #1123 removed that row — the attack it described is closed at the table now rather than at the gate, and the gate is still what stands between a stranger and the rows that remain.

A node running no cluster says so rather than answering as though it had one. A node started without --listen-raft is a pure worker or cache and has no replicated state, which is a different fact from "ask somebody else" — being sent elsewhere would have you looking for a node that does not exist.

A change is reported as accepted, not as committed. The leader appends the entry and answers; whether a majority has taken it is not something it knows yet. Ask for the status again to see the result — which is the round trip you were going to make anyway.

--cluster-admit takes an id and an address in one token, because an id with no address is a node the cluster counts towards quorum and never reaches. One verb covers adding a member and recording that one has moved, because they are one intention — a node that moved has the same identity and a new address, and making an operator remove it first would leave a window in which the cluster has agreed it does not exist.

--cluster-forget is the one membership change nothing automatic makes. Discovery only ever adds, for the reason below, so removing a machine that has left for good is a decision somebody makes on purpose.

It forgets a machine, not only a record (#1555). The id leaves the cluster's members — a voter or a learner — and the identity key it was admitted under is revoked in the same committed entry. A revoked key is never admitted again, by any route. On the consensus wire it keeps its sessions only until the configuration stops counting it — a reconcile pass, since losing another voter before then must not leave a quorum nobody can reach — and then every connection it proved ends at its next frame and every redial is refused, even by a node whose bootstrap roster still names that key. Discovery reports its beacon as revoked. Enrollment refuses it at the door (pace_enrollment_requests_refused_revoked_key_total), and an approval or a --cluster-admit naming it is refused by name. No verb revokes a key without forgetting its machine, or forgets one without revoking: the first would leave a member the quorum goes on counting, whose revocation therefore never reaches the consensus wire, and the second a machine every node naming its key goes on accepting.

It takes the member out of the quorum as well as out of the fleet, whatever put it there. A leader never removes a member for being absent from the record, but a forget is not absence: a member still counted keeps its revoked key for itself, so one kept would go on voting, and whoever leads takes it out.

Bringing a forgotten machine back takes a new identity. Move its --cluster-dir aside so its next start mints a new key, and admit it under that — --enroll-approve once it asks, or --cluster-admit=n3=10.0.0.3:6680@<new key>. Its old key stays revoked for good.

It sticks while the machine is still running (#1528). A forgotten machine keeps running and keeps announcing itself, and the leader will not record the id again -- wherever it now dials from, since what was revoked is its key. It says so once, naming the revoked key:

cluster: not recording n3 at 10.0.9.3:6680: the cluster forgot it and revoked its key (<key>), and only --cluster-admit under a new key undoes a forget

Forgetting the leader removes it too (#1539). A forget means the same thing whoever currently leads, so the forgotten leader stops recording itself and proposes its own removal — last, after any other change it still has to make — and steps down once that commits; its revoked key stays live for it until then. The other voters elect a leader, and it never admits the forgotten machine again. Should the forgotten leader be lost before its removal commits, whoever leads next removes it. It says so:

cluster: the cluster forgot this node (n1), so it proposes its own removal and steps down once that commits

Forgetting the cluster's only voter is refused, by name, before anything is recorded: a configuration with nobody counted in it can commit nothing, including the change that would undo it. Admit or promote another voter first.

cannot forget n1: it is the cluster's only voter, and a configuration with no voter can commit nothing -- admit or promote another voter first

It revokes the machine's key, everywhere at once. A machine is admitted by its key and nothing else, so the forget reaches every node as it applies the entry — every surface, every connection already open, from any address, with nothing to edit on any machine — see who a node admits. That includes a --fleet-open node: a connection that presents the revoked key, as a proof or as a ticket, is refused there too. What such a node still serves is a caller that presents nothing, because --fleet-open admits anonymous callers by design; dropping the flag and reloading is what closes it to them.

Finding peers instead of typing them

A fleet's machines find one another by broadcast rather than by an address list on every command line. --discovery is on by default, beside consensus, and names where beacons are sent:

pace-node \
    --discovery=10.0.0.255:6681 \
    --raft-self=10.0.0.1 \
    --advertise=10.0.0.1:6675 \
    --listen-node=6675 --fleet-open --toolchain=/usr/bin/g++

Every node still names itself — --raft-self, or the address it routes from — because that is the address its peers dial and only it knows it. What it never names is anybody else.

Discovery finds members; it no longer admits anybody (#178). A beacon says what a node is — cluster, id, consensus endpoint — and the challenge that follows it is answered with a signature by that node's own identity key, over a nonce the challenger chose, its id, its endpoint and the key itself. A peer is then desired only when the key it proved is the key the cluster's roster holds for that id. A key the roster does not hold is reported — counted, and logged with the id, the address it came from, the key whole and the --cluster-admit that would admit it — and never desired; a key the roster has revoked is reported as revoked. So discovery can tell the cluster that a known member now answers at a new address, and cannot add a member: that is an operator's act, through --enroll-approve or --cluster-admit ...@<key>.

Under the shared key it could. A proof then showed possession of the fleet's key, and possession was membership, so any machine holding the file was desired and the leader admitted it. That is what ended: a copied key file no longer turns into a member by being on the right segment.

What the signature covers matters as much as who signs. It covers the (node, endpoint) pair and the key: signing the nonce alone would let anyone who observed one valid proof replay it with a different endpoint substituted, pointing a known id at an attacker's address. The datagram grammar changed with it — a key and a 64-byte signature where a 32-byte MAC was — so the discovery wire moved to version 2 (it is 3 since the beacon came to carry the fleet's signed summary), and a node on an older build is refused rather than misread; upgrade a segment's nodes together.

There is no cluster key any more. The pre-shared --cluster-key-file every member used to hold -- which signed lease grants, proved a node on the node port and, before that, admitted discovered peers -- is gone, and the flag with it (#178): a grant is signed by the voter that issued it, a node proves its own identity key, and removing one machine is revoking that one key rather than rotating a secret on every other. A command line naming --cluster-key-file is refused as a flag this node does not have.

A worker nothing else can dial runs without the lease check and warns once, loudly. A scheduler with no key hands out unsigned grants and says so at the first one. Provision the key everywhere before rolling the binary: a worker that has it and a scheduler that does not is a worker refusing every grant that scheduler issues.

The cluster id is routing, not authentication. A node draws it into its formation record at its first start, and it is plain text in every beacon, so treating it as a credential would be the mistake. What it buys is that two unrelated fleets on one segment ignore each other, even where one roster knows machines in both.

A node listens on the --discovery port and answers somewhere else. Every node on the segment binds that port — a beacon is a broadcast, so they have to — and only one of the sockets sharing a port is handed a unicast. Since the challenge and the proof are both unicast, a node answering there would be answering for its whole machine, which is why two nodes on one host used to see each other and never finish the handshake. Each one therefore also holds a port of its own, and that is where its peers reach it.

Two consequences worth knowing before you deploy it:

• A firewall rule scoped to udp/6681 alone is no longer enough. It passes the beacons and drops every challenge and proof, and the symptom is peers that are discovered and never admitted. A rule scoped to the program covers it. Where a site must name the port, --discovery-reply-port=6682 pins it — one port per node on the machine, since two nodes cannot share one, and naming the --discovery port there is refused rather than left to fail at bind.
• The startup line reports both, which is what to check:

discovery listening on 0.0.0.0:6681, answering from 0.0.0.0:52341, for cluster 7d0e…2e63, announcing 10.0.0.1:6680, beaconing to 10.0.0.255:6681

Running several nodes on one machine works, and each needs its own --cluster-dir, --listen-raft and — if you pin them — --discovery-reply-port. The identity comes with the directory: two Raft logs cannot share one, so there is no name to invent. They join one another only at an address other machines could dial: a fleet is never offered at a consensus address that reaches only this machine, so nodes bound to loopback each stay a fleet of their own, serving their own workers.

Discovery never changes membership by itself. It answers which known members proved their keys and where they answer; the leader proposes, and only the leader, because a membership change is a Raft decision. Every node on the segment sees the same peers and all but one of them do nothing about it.

A node joining a discovered fleet still needs an operator to admit its key — --enroll-approve, or --cluster-admit ...@<key>: discovery supplies the addresses, and never the admission. It still names itself — --raft-self, or the address it routes from — as every node in a cluster must. One machine founds the fleet and the rest join it — and only one stays a founder, because two clusters cannot be merged: a joiner dissolves the cluster of one it started as. A membership change proposed against such a node never commits, and the leader says so once the wait becomes unreasonable rather than leaving it to be inferred.

A discovered machine joins as a learner, and you decide which ones vote (#1535). It is replicated to from the moment it is recorded, holds the cluster state and serves whatever its other tiers serve, and it is counted by no quorum. Proving the key says a machine holds it now; a vote says it will go on answering, and every voter is one more machine the cluster needs a majority of — a laptop on a VPN admitted as a voter beside one always-on machine makes that machine unable to commit or re-elect alone. Only you know which machines stay, so promotion is yours, and it is not automatic when the learner has caught up: catching up says it can answer now, which the proof already said. Promote with the id and address --cluster-status shows:

pace-node --scheduler=10.0.0.1:6675 --cluster-admit=n2=10.0.0.2:6680

So a fleet formed by discovery alone has one voter — the machine that founded it — until you promote more, and a voter lost is a cluster that can neither commit nor elect. Promote two for three voters, which survive losing one. A promotion takes effect once the learner has caught up (#1537), so promoting one that is away costs the cluster nothing until it returns. A machine already recorded or counted keeps its seat when it is discovered again: a promoted learner stays a voter, and a demoted voter stays demoted.

It never proposes a removal either. A peer vanishes from a broadcast for reasons that are almost never "it left" — a lost datagram, a switch rebooting, a laptop closed for an hour — and a cluster that re-computed its membership from reachability could shrink itself below a majority and never come back. Raft already tolerates a member that does not answer. Removing one stays an operator decision.

Pinning a node to one fleet

Zero-config formation is trust-on-first-use, and --fleet-id is how an operator closes it. A solitary node yields to the fleet discovery, a typed seed, DNS SRV or its remembered endpoints prove older or established -- and a proof binds a key, never the truth of the summary it signs. A key costs nothing to mint, so anybody on the segment can prove "established, created at 0", and every solitary node that hears it would ask to join, and on its approval take on its roster: its launchers would dispatch source to that fleet's workers, and it would compile that fleet's jobs.

pace-node --fleet-id=<cluster-id>@<voter-key>[,<voter-key>...] ...

The pin is the cluster AND its voters' identity keys, because a cluster id is a name: every beacon carries it, so a pin by name alone would stop nobody who can hear the fleet it names. Do not compose the value by hand: on any machine of the fleet, pacectl node prints it as fleet-id -- the cluster id, @, and the key of every voter its state records, comma-separated -- ready to paste into --fleet-id, the fleet_id key of the configuration file, or the installer's PACE_FLEET_ID. An office has one or two voters, so the list is short and no chain of trust is needed. The cluster id is held to the spelling a node mints (32 lowercase hex digits), every key to the one key format, and an id with no key is refused where it is typed rather than taken as a pin by name. Pinned, a node:

• yields only to its cluster as a pinned voter SIGNS it, whichever route proved it -- a beacon, a typed seed, DNS SRV, a remembered endpoint. A fleet it would otherwise have joined, and an impostor claiming the pinned id under a key of its own, are counted (pace_formation_yields_refused_pin_total, per proof) and raised as foreign-fleet-visible; the impostor's detail names its key;
• takes no answer to its Enroll that a pinned voter did not sign -- an approval, a refusal or a not-yet -- and asks no leader whose key it does not pin: a NotLeader that redirects it to one is refused, naming that leader's key and the --fleet-id to add it to, because a voter promoted since the pin was written is the honest cause;
• follows no dissolve into another cluster, and takes no approval from one: counted (pace_formation_admissions_refused_pin_total), logged, nothing changed;
• wins every tiebreak against the pinned fleet: a node whose own cluster happens to be the older still asks the fleet it is pinned to, rather than waiting to be joined;
• records nobody while it could not answer as a pinned voter: a node pinned to another fleet, or to its own under a key that is not its own, serves no enrollment (pacectl node shows no enrollment), and a machine asking it to join is told which of the two, and where to ask instead;
• refuses to start on a formation record that commits it to a cluster its pin does not admit -- a pending ask, a fleet it joined, a cluster it founded, each judged by a key this node PROVED: the one that proved the fleet it asked, the one that SIGNED the admission it acted on (never the voters a roster lists), or its own -- naming both and the remedy: reset the state directory to join the pinned fleet, or change the pin. A founder whose own key file cannot be read is refused in that key file's own words and ends as that file would, never with the "reset the state directory" remedy, which would discard the key the pin names.

Pin the machine that founds the fleet too, to its own fleet-id: it then yields to nobody, so a stranger proving an older fleet cannot take the founder -- and the fleet with it -- either. When you promote another voter, its key belongs in two kinds of pin, for two reasons. The pins of machines that have not joined yet, because a join is redirected to whichever voter leads, and a pin without that voter's key refuses the redirect (naming the key to add) and the join waits. The promoted voter's own pin, without which it serves no enrollment: it could not answer as a pinned voter. Machines already in the fleet are unaffected, for the reason below. pacectl node prints the new fleet-id. --fleet-id is Reloadable::No: a new pin is judged against the record at the next start, by name. --print-surfaces and pacectl node show the pin this node trusts by, and say none when there is none.

A key pin stops a LAN impostor; an unpinned node trusts on first use. What it does not stop is a machine holding a pinned voter's identity KEY -- the same exposure as that voter's consensus connections, ended by revoking the key and re-pinning.

The pin anchors the JOIN; from then on the fleet's applied state is the authority. Every decision above is a way into a fleet. Once a node has joined, it follows its fleet's leaders, takes the roster the fleet commits and is granted work by the voters that roster names -- pinned or not -- exactly as any member does, and its start judges the admission its record kept, so a fleet that later forgets every pinned voter still starts its members. That is deliberate, since pinning every leader forever would make every promotion an outage for every pinned machine; and it is the limit of what a pin protects: an attacker who captures the fleet's quorum after a node joined -- its voters' keys, or an approval an operator should not have given -- gets everything a member's quorum gets, the pinned nodes included.

Where its state lives

--cluster-dir, defaulting to pace-cluster. Durable by necessity rather than by preference: a node that answered a vote and forgot it would vote twice in one term after a restart, which is two leaders in one term.

It holds this node's identity as well, in a file called node-id, which is why the default no longer ends in the id — a name read out of a directory cannot name the directory — and the key that proves it, in node-key. Losing this directory loses all of them, and losing them together is the safe pairing: a node that kept its identity across a lost vote record is the two-leaders case above, arriving automatically.

A state directory copied to a second machine copies the node, identity and all, and nothing refuses that. It cannot be refused where it would be noticed: --cluster-admit=<id>=<host>:<port> re-pointing an id at a new address is how you record a node that has moved, so the request is byte-identical to the honest one, and what separates them — whether the old address still answers — is wrong in both directions at the moment it is asked (a moved node's old address never answers, and a cloned one's answers only while both happen to be running). Copy the directory when you mean to move a node, not to make a second one.

The fleet's shared cache

A cluster can name one of its members as the fleet's shared cache. Every other node that runs consensus then reads through to that machine after a local miss, and offers it what it stores. The machine is named by its id, once, in the replicated configuration. No pace-kv is needed for this, and no address is typed on any other machine.

Setting it once

pace-node --scheduler=10.0.0.1:6675 --cluster-set=shared-cache=n2
pace-node --scheduler=10.0.0.1:6675 --cluster-set=shared-cache=

The first command names n2, and the second, with an empty value, unsets the setting.

The value must be a member's id and is never an address. It is refused when it is proposed if:

• it is shaped like an address;
• it names no member the cluster holds a live key for. A forgotten id is refused too, and the refusal says that its key was revoked.

A machine admitted only by its key, such as a roaming worker, is not a member and cannot be named. --cluster-status shows the setting beside the others.

What every node does

Every node that runs consensus, whether a voter or a learner, does the following:

• It resolves the id at every change the cluster applies. The result is the key the roster records for that member and the 0xFC endpoint the member announced about itself. Moving the machine, forgetting it or naming another one reaches every node that way, with nothing to edit and nothing to restart.
• It proves the key before it sends anything. A machine that answers at the announced address but proves another key has been sent a challenge and nothing else. The node counts it, raises shared-cache-unproven, and compiles locally.
• It keeps one proven session open. An idle session is hung up before the named machine would close it. A kept session found dead is proved again once, in the same operation. A failure on a fresh session is the answer: the build compiles locally.
• It speaks the fleet cache verbs, shared-fetch and shared-store. These are not the FETCH and STORE a launcher sends. A pace-kv refuses them by name.
• It presents no credential. The proven session identifies both ends, so this node's --requirepass never goes there. A node presents that secret to one machine only: the pace-kv its own --upstream names.

An unreachable or refusing shared cache is a miss and never an error. A node that runs no consensus holds no cluster state, so the setting does not reach it. Its cache tier reads through to its --upstream, or to nothing.

Overriding it on one machine

--upstream=<host>:<port> on a node wins over the setting. That node reads through to the pace-kv it names, speaks that daemon's FETCH and STORE, and presents its --requirepass there. The override is fixed for the process. The startup line reports it as <host>:<port> (override, pace-kv verbs). pacectl node reports it as override, and its detail names the machine the setting names, if any.

The named machine

When the fleet's shared-cache setting names this machine, its store lives at <state-dir>/shared-cache/objects.cow — a directory of its own inside the node's state directory (--cluster-dir, or the default the start resolves), never --cache-dir: the private tier's store is already claimed exclusively by this process, and the two tiers answer to different verbs and different callers.

--shared-cache-disk caps it, defaulting to 64g; 0 grows it as needed, the same rule --cache-disk follows for the private tier.

The store is opened when the cluster applies a state naming this machine — on a thread of the node's own, never on the apply path — and closed within 30 seconds of the setting naming another machine and the last answer reading it finishing. Naming the machine again while the store is still open reuses it. If it will not open, the node raises shared-cache-unavailable (below) and answers not-shared-cache until it does.

This machine's own builds read the tier in process, never through its own socket.

Every node answers the fleet cache verbs on its 0xFC port, which is --listen-node. No port is added for them. The endpoint other nodes dial is the one this machine announces: its consensus host with the port --listen-node bound. So --listen-node must face the network on the named machine, as it already must on a scheduler.

A node serves the fleet cache verbs only while it is the named machine. Any other node answers not-shared-cache. A caller is served only when its connection proved a key the fleet holds or presented a ticket the node verifies. This machine's own address and --fleet-open admit nobody here, and a revoked key is refused from any address.

When it does not work

Start with pacectl node on the node whose builds are missing. Its shared-cache line says where the shared cache comes from: none, setting, override or this-machine. shared-cache-state says how the last attempt went: not-tried, proven, unresolved, wrong-key, unreachable, proof-refused, or serving or unavailable on the named machine. shared-cache-detail says why. The fields are listed on the CLI page.

Two conditions name the cases an operator must act on:

• shared-cache-unproven, on a node reading through. The node is not reaching the shared cache, for one of these reasons:
• a machine at the announced address proved another key;
• the named machine refused this node's key;
• the named machine did not answer;
• the setting names a machine this cluster cannot reach by key.
• shared-cache-unavailable, on the named machine. Its tier will not open.

Both appear in the conditions table with their remedies.

Five counters on the node that reads through tell the story over time:

• proofs_refused_wrong_key is an impostor or a reassigned address.
• proofs_failed is the network.
• unresolved is the setting.
• stale_hints is a remembered address that went away.
• sessions_opened says whether the kept session holds: about one per burst of misses is healthy, one per miss is not.

Reading the shared cache's counters

Fifteen counters, on whichever end of the fleet cache verbs this node is: ten on the machine the shared-cache setting names, which serves them; five on every other node, reading through to it.

Series	Says
pace_node_shared_cache_hits_total	Objects the fleet's shared tier on this machine answered.
pace_node_shared_cache_misses_total	Objects the shared tier on this machine did not hold.
pace_node_shared_cache_store_failures_total	Objects the shared tier could not keep. A sustained rate is this machine's disk.
pace_node_shared_cache_requests_refused_not_a_member_total	A caller that proved no key and presented no ticket the fleet admits.
pace_node_shared_cache_requests_refused_not_serving_total	Answered not-shared-cache: the setting names another machine, or this one and its tier is unavailable.
pace_node_shared_cache_requests_refused_payload_too_large_total	A request declaring more than one object's ceiling.
pace_node_shared_cache_requests_refused_endpoint_busy_total	Refused because the surface's in-flight byte budget was spent.
pace_node_shared_cache_requests_refused_unsupported_version_total	A request from a build of another wire version.
pace_node_shared_cache_requests_refused_malformed_payload_total	A request whose payload would not decode.
pace_node_shared_cache_requests_refused_foreign_generation_total	A store of a value generation this build does not implement.
pace_node_shared_cache_proofs_refused_wrong_key_total	The machine answering at the shared cache's announced address proved a key that is not the named machine's; nothing was sent.
pace_node_shared_cache_proofs_failed_total	The shared cache could not be reached, or did not complete the handshake; the build compiled locally.
pace_node_shared_cache_unresolved_total	Operations skipped because the shared-cache setting names no machine this node can reach by key; pacectl node says which reason.
pace_node_shared_cache_stale_hints_total	The address this node's last proven session to the shared cache connected to failed, and the announced name was dialled instead.
pace_node_shared_cache_sessions_opened_total	Proven sessions this node opened to the shared cache. One per burst of misses is healthy; one per miss means the kept session is being lost.

Running it as a service

Linux

The package ships a socket-activated unit. Enable the socket, not the service:

sudoedit /etc/pace/pace-node.yaml   # scheduler, advertise and
                                                       # cluster_dir; the compilers
                                                       # are discovered
sudo systemctl enable --now pace-node.socket

cluster_dir: /var/lib/pace-node is the one to know about: the unit creates that directory for the worker (StateDirectory=), it is where the worker keeps the identity key it proves to its scheduler, and a worker naming a scheduler without one refuses to start. Its first start mints the key; admit it as the node proof section says.

A disk tier goes in cache_dir: /var/cache/pace-node, which the unit creates for the worker too (CacheDirectory=). It cannot go under the state directory: the unit runs with ProtectSystem=strict, so those two are the only persistent directories it can write, and the node refuses to start beside an entry in its state directory that it did not write — /var/lib/pace-node/cache is refused with this build keeps no entry by that name.

The unit's ExecStart names that file, and the shipped copy is every setting commented out — so an untouched install behaves exactly like running the worker with no flags, and anything it does that you did not want is something written there. Every key is one flag with underscores instead of dashes, a flag on the command line wins over the same key, and there is no setting the file can express that a command line cannot. It is a dpkg conffile and an rpm %config(noreplace), so an upgrade leaves your edits alone.

Its mode is not checked: anyone who can write it decides what this worker runs and which compilers it serves. The package installs it 0644 root:root, so keep it writable only by root (#384) — and tighten it to 0640 root:pace-node if you put a requirepass: in it, since the default is readable by every local account.

Socket activation means systemd owns the port: it answers from boot, so a client that leases this worker never races its startup, and an idle worker costs nothing — which suits a compile fleet, where misses on a warm shared cache are bursty and rare.

The port is 6674, the node's own default and where every local client looks — pace-cc, CompileCache.cmake and pacectl all default to 127.0.0.1:6674 — so this machine's builds use the node's cache tier with no PACE_ADDR at all. The plain pace-kv the package also installs listens on 6674 too, and a fresh install enables and starts it, so the node supersedes it: the socket declares Conflicts=pace-kv.service, and enabling the socket stops the daemon and takes the port; with both enabled, a boot starts the node. Disable the daemon as well so systemctl status does not show an enabled unit that never runs:

sudo systemctl disable --now pace-kv

Starting pace-kv by hand does the reverse and stops the node's socket. Up to 0.5.0 the socket listened on 6676, which no local client dials (#1676); a drop-in that moved it by hand can go.

The worker needs no advertise: for it. It asks the socket it is handed where it is bound: the shipped ListenStream=6674 binds every interface, so it advertises the address this machine routes from on port 6674 and follows the network when that changes; a ListenStream=10.0.0.5:6674 is advertised as exactly that. An advertise: in the configuration file still wins. Coming from 0.4.0, which refused to start under activation without one: if you added a literal address only to get past that refusal, remove it, or the node stays pinned to it and does not follow the network.

The service runs as its own pace-node account, deliberately not pace-kv's: a worker runs a compiler on input that arrived over the network, while pace-kv owns the cache storage, and sharing an account would let a compromised compile rewrite every cached object.

systemctl edit pace-node for local overrides; the shipped unit is replaced on upgrade.

Stopping one, and what a stop waits for

A stopping worker has to wait for something: a compile legitimately holds its slot for seconds, and abandoning one loses work a client is still waiting on. So a stop closes the port first, then waits for the compiles already running.

That wait is bounded by --drain-timeout, 30s by default, and the node says what it is waiting for while it waits:

[INFO] worker: waiting for 3 compile(s) to finish before stopping
[INFO] worker: waiting for 1 compile(s) to finish before stopping

If the bound is spent, it names what it is abandoning and ends the process itself, exiting 75:

[ERROR] worker: giving up after 30s with 1 compile(s) still running; ending now
        rather than waiting for the supervisor to kill this process without
        saying why (#239)

That is a deliberate ending, not a crash. Left unbounded, the wait does not avoid that ending — it only hands the choice to systemd or the Windows SCM, which answer it with a SIGKILL and no diagnostic at all. On Windows that surfaces as an SCM stop timeout, which reads as "the service is hung" rather than "a compile is still running". Exiting on our own terms puts the count and the bound in the log instead.

--drain-timeout=0s waits forever, which is what the node did before the bound existed. Use it if you would rather your supervisor's own timeout be the one that decides.

A wedged compiler is a separate gap

Nothing yet bounds an individual compile (#239 is only half closed). A compiler that never exits holds its slot for the life of the process, so the machine's advertised capacity drifts above its real capacity and the scheduler keeps routing there — free slots is exactly what it ranks on. Until that lands, a drain bound converts the resulting hang into a stated abandonment; it does not prevent the wedge.

Taking a machine out before a reboot: the cordon

A bounded stop abandons whatever outlives --drain-timeout, and a translation unit longer than the bound is exactly the compile that was about to succeed. So before a planned stop, cordon the worker first, wait for it to drain, and stop it then:

pacectl cordon          # or: pace-node --cordon
pacectl node            # poll until the cordon field reads drained
systemctl stop pace-node

A cordoned worker refuses every new compile and lets the running ones finish. It stays registered and on the fleet page, where its limited-by cell reads cordoned and its in-flight count falls; the scheduler stops leasing it within a second, because the cordon wakes the heartbeat rather than waiting out the 20-second interval. The node says when the last compile has been delivered, once:

[INFO] worker: cordoned; refusing new compiles and letting 2 running compile(s) finish
[INFO] worker: cordoned and drained; no compile is running, so stopping this node now abandons nothing

drained means delivered, not merely compiled: a compile holds its slot until its object has been written to the client, so a stop taken on that line cuts nothing off.

Three properties are deliberate:

• It is asked of this machine. The node answers a cordon from its own machine only — --cordon dials this node's own --listen-node, and pacectl cordon must be pointed at the node on the machine it runs on — and refuses one from anywhere else, counted in pace_worker_cordons_refused_not_local_total. Whether a machine serves the fleet is decided on that machine.
• It is not persisted, and a restart lifts it. The cordon lives in the running worker's memory and nowhere else: not in the configuration, not in the cluster's replicated state. A cordon that survived a restart would be a machine that silently never came back to the fleet. pacectl uncordon (or --uncordon) lifts it without one.
• It is not a withdrawal. A withdrawn registration disappears from every surface; a cordoned worker is visible while it drains, which is the point.

A compile that reaches a cordoned worker anyway — leased in the second before the scheduler heard, or dialled directly — is refused no-capacity and compiled locally by its client, counted in pace_worker_jobs_refused_cordoned_total. A steady rise there says the scheduler is not hearing this worker's heartbeat.

macOS and Windows

pace-node --install-service \
    --fleet-seed=cache.internal:6675 \
    --advertise=worker-01.internal:6674 \
    --service-scope=user            # macOS: registers a launchd agent for you

No --toolchain is needed: the registered service surveys the machine at every start, which is also why a toolchain upgrade no longer means re-registering.

Name the fleet seed by something that outlives one machine

A service carries no --scheduler -- a node that serves is refused one, and registers where its formation record says -- so retiring a scheduler re-registers nothing: every member follows the fleet to its leader. What a registration may carry is --fleet-seed, for a machine no beacon reaches, and it is decided before the rollout: it is replayed at every start of every such machine, so point it at a DNS name or a VIP you control -- cache.internal above, never 10.0.0.1 -- and retiring the machine behind it is a change in one place. Once a machine has joined, it remembers its fleet's endpoints in its state directory and asks the seed again only when none of them answers.

The operator commands (--cluster-*, --enroll-*) are not part of any registration. They ask this machine's own node unless --scheduler names another -- the one place that flag is read -- take the first of several values that connects, and never try another once a connection was made: the request may already have been applied where it landed.

Every other flag on that command line is baked into the registration and reused at every start, so this is also where a wrong one is expensive. An install is therefore judged by every rule a start is judged by, plus the ones below that only a registration can break — a command line that would be refused at startup is refused here instead, where you are watching, rather than at every boot into a log nobody reads.

These are specific to registering:

Missing	Why it is refused here
--toolchain (only with --no-toolchain-discovery)	With both, the worker has nothing to serve: it would register and then refuse every job sent to it. Without the flag the machine answers at boot, so a registration needs no toolchain at all.

Neither --advertise nor --cluster-dir is required. A worker that names no --advertise advertises the address this machine routes from, which the service re-derives whenever the network changes rather than baking it in here. And the state directory defaults to the platform's machine-wide one, resolved by the service as the account it runs as, not relative to a working directory a service does not inherit.

Everything else the worker refuses at startup — --tls-cert without --tls-key, a worker that admits other machines while its --advertise is still the wildcard, a --scheduler on a node that serves, --dashboard without --admin-listen, and the rest — is refused here too. Each is decided by the command line alone, and a registration replays that command line forever, so there is nothing to gain by waiting for the first boot to say so.

That includes a value that is not an address. --listen-node, --admin-listen, --listen-raft and --discovery each name one, and a typo in any of them is refused where you typed it rather than when the surface is opened — the message names the flag and echoes what you wrote. A bare port is fine for the three that are bound — it takes that surface's own default host. A port with a bare colon in front of it is not the same thing and is refused: an empty host binds the wildcard, so --listen-node=:6674 would serve this node's private cache to the whole network rather than to loopback. --discovery is sent to an address, so it takes <address>:<port> and nothing shorter.

Addresses this node dials rather than opens — --advertise, --scheduler, --upstream — are checked for shape at install and at startup: each must be <host>:<port>, since a bare port names no machine to dial, and every --scheduler value is checked, not only the first. Whether an address resolves genuinely cannot be settled at install: a host that is down on the day you install may be the right one by the time the worker boots.

--requirepass is refused too, for the reason it is on the daemon: a supervisor records launch arguments where every local account can read them, and on a worker it is the secret of the pace-kv its --upstream names. It is not what the scheduler authenticates a worker by — that is the worker's proven identity key — but a secret on a readable command line is exposed all the same.

Where it goes instead is the configuration file: requirepass: in /etc/pace/pace-node.yaml, which the worker reads at every start and which is not a world-readable command line — mode 0640 root:pace-node for a file that holds one. Where --install-service is the registration mechanism, pass --config=<path> alongside it: what gets baked into the launch arguments is then the path, not the secret.

Every package ships that file, on every platform. Neither a .pkg nor an MSI has a conffile mechanism, so their equivalent is a .default template plus a seed-once step that copies it the first time and never again — which is what lets your edits survive an upgrade. The worker seeds its own: the destination comes from the same lookup table its startup reads, so the path the installer writes and the path the worker reads cannot drift apart.

macOS scope. --service-scope=user registers a LaunchAgent that runs as you, which is the per-developer case. --service-scope=system registers a LaunchDaemon that runs as the unprivileged pace-node account — the same one the Linux unit uses — because a system job with no account named runs as root, and this process compiles input that arrived over the network.

The .pkg creates that account, from its Runtime component, so it is there whichever launchd choice you made for pace-kv itself. Installing from a tarball or a source build does not create it, and the registration is then refused with a message saying so rather than registering a job launchd would accept and never spawn.

Neither scope bakes a --config or --storage into the registration: this worker takes neither flag, and a registration carrying one is a job that answers its own command line with unrecognised argument at every start. Everything the worker needs is on the --install-service command line itself.

Windows registers an SCM service and leaves it stopped (sc start pace-node). It starts with Windows from then on; --service-start=manual registers it to wait for somebody to start it instead. The start mode is decided by the install and is not part of the command line the service runs with, so changing it means running --install-service again. The default service name is pace-node, not the daemon's pace-kv, so a machine can run both without one install displacing the other.

It logs on as the virtual account NT SERVICE\pace-node, for the reason the macOS job runs as pace-node: told no account, the SCM would use LocalSystem, and a process that compiles input arriving over the network should not have the machine. The SCM derives that account from the service name and creates it itself — there is nothing to create and no password to keep.

Because it is no longer LocalSystem, a --cache-dir or --cluster-dir you name is granted to that account at install time; the grant is reported if it fails and the registration is kept, so you can repair it with icacls rather than being left with nothing. If you rename the service with --service-name, the account follows the new name.

The registration also opens the Windows Firewall for every surface this worker binds beyond loopback — --listen-node, --listen-raft and --admin-listen when they face the network, and, with --discovery, its UDP beacon port and its reply socket — that UDP port when --discovery-reply-port pins one, and otherwise a rule admitting any local UDP port (discovery-reply udp/any), since the kernel chooses the port and no port-scoped rule can name it. That rule exposes only the UDP sockets this program opens, which is discovery alone. One inbound rule each, admitting this program running as this service, on every network profile (a VPN adapter is usually Public). They sit in the group pace-kv: pace-node, and the install line lists them. Narrow the remote side with --firewall-allow=10.0.0.0/8 (IPv4 or IPv6, repeatable; /0 is refused — leave the flag out to allow any address). Running --install-service again replaces the group, so a surface you have since moved to loopback loses its rule. A rule the firewall will not create is reported as a warning and the service stays registered; run the install again once the cause is fixed.

The MSI does that registration for you, with no property at all. A node registers its worker where its formation record says (its own scheduler on a first start, its fleet's once it has joined one), so there is no scheduler to name, and a node that serves is refused --scheduler. What an installer cannot guess is a machine of the fleet to ask when no beacon reaches this one, and the one fleet this machine may join; both are optional:

msiexec /i pace.msi PACE_FLEET_SEED=office-a.vpn.example PACE_FLEET_ID=<cluster-id>@<key>

Select the pace-node feature (silently: ADDLOCAL=CM_C_Cli,CM_C_Node on a first install, ADDLOCAL=CM_C_Node to add it to one that is there). On a machine that also runs pace-kv, the MSI disables pace-kv and stops it, because both would answer on 6674. Every transaction that keeps the node -- a repair, a feature change, an upgrade -- registers it again, and the optional properties are remembered for it: PACE_FIREWALL_ALLOW, PACE_FLEET_SEED and PACE_FLEET_ID are kept under HKLM\SOFTWARE\Pace\Installer and read back unless the transaction states a new value, so a repair that leaves them out keeps the firewall scope rather than opening the rules to any address. Registering again is also what clears the --scheduler an earlier package registered, which a node that serves now refuses, and the --advertise an earlier package of this installer registered from the advertised-endpoint property it remembered.

There is no such property any more. The registration carries no --advertise, and the node advertises the address this machine routes from on its --listen-node port, re-derived when the network changes, so a renamed machine or a new VPN address needs no reinstall or restart -- where a remembered IP literal on a roaming laptop pinned it and vetoed every dial hint at every upgrade. An address that must be typed goes under advertise: in the configuration file. PACE_FIREWALL_ALLOW is optional: it is passed as --firewall-allow (one address with an optional /prefix) to this registration and to pace-kv's, and left out the rules admit any address. PACE_FLEET_SEED is optional as well: one name or name:port, registered as --fleet-seed and replayed at every start, so a node across a VPN asks that machine while it is alone; more than one goes under fleet_seed: in the configuration file. PACE_FLEET_ID is optional as well: the pin pacectl node prints on a machine of the fleet, registered VERBATIM as --fleet-id and replayed at every start, so the node joins that fleet and no other. A pin is security material: one the node cannot parse fails the WHOLE transaction before anything is remembered or registered -- the MSI runs --check-arguments over the node's arguments as its first step -- so a repair or upgrade keeps the registration and the remembered pin it had, rather than starting a node that trusts on first use. A malformed seed fails it the same way. PACE_DISCOVERY_REPLY_PORT defaults to 6682 and is passed as --discovery-reply-port, so the registration's firewall rule is discovery-reply udp/6682 rather than the any-port rule above; pass another port to move it, or pass it empty to leave the port to the kernel. The package pins it and a node run by hand does not, for the multi-instance rule: the reply socket is each node's OWN (a unicast to a shared port reaches only one of the sockets sharing it), so two nodes on one machine need two ports, which a kernel-chosen default gives them with no configuration -- and the package installs one node per machine. The state directory is not a property and not an argument either: the registration names no --cluster-dir, which would outrank a cluster_dir: in the configuration file for the life of the service, and the node takes its service default, %ProgramData%\pace-node, where the cluster admits the identity key the worker mints on its first start.

That key is how the machine proves itself to the fleet, so the install gives the state directory an access list of its own: SYSTEM, Administrators and the service's account, with nothing inherited from %ProgramData%, whose list lets every local account read. An upgrade covers a key already there the same way. An install that cannot set that list is refused, and says why, rather than leaving the key readable. --print-identity against that directory therefore runs from an elevated prompt.

A directory that is already there is checked before it is trusted, because any local account can create one under %ProgramData% before the installer runs. The install refuses, naming the entry, a directory that is, or holds anywhere in it, a junction or a symbolic link, an entry owned by anybody but SYSTEM, Administrators or the service, a file with a second hard link, or an entry that keeps an explicit grant to a broad group of its own; it makes Administrators the directory's owner. An identity key other accounts could already read is refused with a remedy to delete it: the node then mints a fresh identity at its next start, which the cluster has to admit again, because a key that may have been copied must not stay in service. A registration this install created is removed again on any of these refusals, and one it was re-applying is left, and the message says which. One gap remains: a program that opened a file in that directory before the install set the list keeps the access it opened it with, until it closes it.

Remove a registration with --uninstall-service (and the same --service-scope, on macOS: which domain a job lives in is decided at install time and re-probing would boot out one that was never there). On Windows it stops the service, waiting up to a minute, deletes it, and then removes its firewall rules. A service that has not stopped by then is only marked for deletion and goes when it exits; its rules are removed at once all the same. If Windows refuses the delete, the rules are left in place — the service is still registered and may be running — and the next uninstall that succeeds removes them.

When the machine sleeps, wakes, or changes network

A worker registered as a Windows service hears the machine's power events, and every node hears its network changes: on Windows from the system's interface and address notifications, on Linux from a netlink routing socket, on macOS from a routing socket. It works without either: each only lets it act sooner.

• Before the machine sleeps the worker withdraws its registrations, so no client is leased a machine that is about to stop answering. It makes one connection to the scheduler its last heartbeat round ended at — normally the one that accepted it — and holds the machine for at most 1.5 s in all. A withdrawal the worker had not started by then is dropped rather than made once the machine is awake again; whatever did not get through, the scheduler's heartbeat timeout retires as it always has.
• When the machine wakes, or an interface or address changes (reported once nothing new arrived for 2 s, or 10 s into a burst), the worker announces itself at once rather than at the end of its 20-second interval, and so does the node's presence announcement. Each runs on its own thread, never on the one that delivered the event. A suspend cancels any such wake still pending from before it.
• When the address it routes from changes, a node whose --advertise and --raft-self are left at auto re-derives both: the worker withdraws its registrations under the old endpoint and registers under the new one, the presence announcement tells the leader, and a voter closes its consensus connections so they redial from the new address, while the leader records the move (see two ports, and why a member records both). A voter that no longer hears its leader -- which is every voter whose old address is gone -- reaches it through the other voters it knows, so its own scheduler not knowing who leads does not strand it. Each move is an Info line naming the old and the new endpoint, and counts on the two series above. Without any event the node re-checks every 30 seconds, so a missed change costs half a minute at most. A pinned --advertise or --raft-self is not re-derived.
• A move that leaves the voters that did not move without a quorum does not heal by itself (#1644). The leader records a voter's new address by a commit, and that needs a quorum of the voters that did NOT move: a two-voter fleet where either one moves, or a majority of voters renumbered at once (a router replacement, a DHCP scope change), has none, and nothing else re-addresses a recorded member. Run three or more voters and let them move one at a time, or pin --raft-self and --advertise to DNS names on always-on voters, which every peer re-resolves when it dials. Once it has happened, give enough of the moved voters their old addresses back (a DHCP reservation, a static address) for a quorum to re-form, then let them move one at a time; where a quorum survives and one record is stuck, pace-node --cluster-admit=<id>=<new-host>:6680 on that side re-records it.
• A machine that sleeps without saying so — Modern Standby can sleep and wake without reporting either — recovers on its own schedule. The next ordinary round registers it again, at most one announcement interval (20 s) after it wakes. Until then a worker whose registrations were withdrawn, or expired while it slept, is absent from the fleet: nothing is leased to it, and clients compile elsewhere or locally.
• A machine that slept past the isolation bound -- 65 minutes with no word from a leader its fleet counts -- refuses every grant until that leader speaks to it again, which its first consensus session after waking brings, with no event needed. It raises consensus-leader-silent meanwhile.

Only a Windows service hears power events: a node run in the foreground, and every node on Linux and macOS, hears network changes alone and relies on its ordinary rounds for a sleep. A node whose network watcher cannot start says so once in its log (network changes will not be reported), and one whose watcher stops later says so once too (network changes will no longer be reported); either keeps working on those rounds and the 30-second re-check.

Reloading it

SIGHUP — or systemctl reload — makes the worker re-read its --config file without restarting. It needs a file: a worker started with flags alone says so and changes nothing.

A reload is all-or-nothing. The file is applied to a fresh configuration and then your command line is applied over it, exactly as at startup, so "the command line wins" stays a question of which pass ran second. If the file will not parse, or changes a setting that cannot change at runtime, nothing is applied and the refusal names every offending setting. You saved once; you get one answer.

A key written twice is refused the same way, at startup and at a reload, naming both lines. It used to keep the second silently — two listen_node: lines served the second address — so a list is written as one key with every value under it.

Reloadable	Requires a restart
log_level, allow_compile_arg, requirepass, fleet_open, toolchain, no_toolchain_discovery, advertise, raft_self	slots, node_class, reserve_cores, and every listen, cache, cluster and TLS setting

log_level, allow_compile_arg, requirepass and fleet_open take effect immediately and tell the fleet nothing; toolchain and no_toolchain_discovery re-register this worker, which is the section after next; advertise re-registers it too, at a new address, and retires the entry under the old one -- with the cost that section states. raft_self moves the address this node's peers dial for consensus.

Both default to auto: the address this machine routes from, on the bound port while the listener binds the wildcard, re-derived when the network changes (this machine's fully qualified name stands in until a route is known). auto:<port> derives the host and states the port. A literal IP pins the address and turns that roaming off; a name pins it too, and peers resolve it themselves.

Revoking a machine

fleet_open is the admission setting a reload can move, and its two directions are not alike. Opening fails closed: until the reload lands a stranger is refused, which is annoying, self-healing, and obvious from the machine being refused. Closing fails open: a caller you have just shut out keeps being served, and nothing anywhere reports it, because admission succeeding is what normally happens. A machine is admitted by the key it proves or the ticket it presents, never by its address, so there is no list of hosts to edit.

Dropping fleet_open: from the file and reloading closes the node again. Every caller the roster does not admit is refused from its next connection onward — on the compile port, on the cache tier and on the scheduler alike, since all three ask one oracle. The worker logs the change at WARN and says in words that it closed; this machine is still admitted, always, because a process on this host already has this host's compiler.

A reload will not widen a worker that verifies no lease. Every worker that starts checks its leases against the state its consensus applies, since a worker running no consensus is refused at startup. The reload asks what the running worker actually BUILT anyway, rather than trusting that: if its lease check is the one that verifies nothing, a reload that would newly admit a remote host is refused by name and nothing is applied. Restart it with the admission you want, or leave the policy as it is. Narrowing is always allowed, since that is the direction that closes it.

Rotating requirepass

On this worker the token is presented and never required — it is what this node shows the pace-kv its --upstream names, and nothing else. No scheduler, and not the fleet's shared cache, is ever shown it: a scheduler admits this machine by its node proof and checks no password, and the shared cache is reached over a proof and carries no credential at all, so a registration, a heartbeat, a presence announcement and a shared-cache exchange present none. Nothing authenticates against it here. That asymmetry is what makes it rotatable one machine at a time: an inbound credential could not be, because every client would have to move with it.

Edit requirepass: and reload, and the next exchange with the upstream presents the new secret. Nothing in flight is retried, and there is no handshake to renegotiate: each cache fetch and each store presents whatever is in force at that moment.

Rotate the peers first, or at the same time. A worker presenting the new secret to a pace-kv that has not moved is refused, visibly, and its compiles fall back to building locally; a worker still presenting the old one after the daemon has moved fails the same way. Neither silently serves a wrong object, which is the direction to fail in.

It cannot be rotated this way on a worker whose command line names --requirepass: a reload applies the file and then the command line over it, exactly as a start does, so the file's value would never be in force. That is one more reason the secret belongs in the file — see running it as a service.

Changing what this worker serves

toolchain and no_toolchain_discovery are not local settings — they are claims this worker made to the scheduler. So changing either does more than update a snapshot: on the next heartbeat the worker re-derives what it can serve, updates its compile port, and re-registers with the fleet under the new set. That takes one heartbeat, plus however long identifying the toolchains takes on the machine — which on a cold host with large include trees is minutes, not seconds. The startup log says when it begins and when it finishes.

The order is deliberate and worth knowing, because it is what makes this safe to do on a busy worker: the compile port is updated first, the registration second. Between the two, a job arriving for a toolchain you just removed is refused rather than served by a compiler nobody keyed against.

Three consequences, in decreasing order of how likely they are to surprise you:

• A toolchain you remove keeps being dispatched to this worker for a short while. The scheduler's entry for it expires on its own after the heartbeat timeout (90 seconds by default); until then, clients are leased this worker, it refuses them, and they compile locally. You lose some round trips, never correctness — a removed toolchain is never served by the wrong compiler.
• Compiles already running are not disturbed, and leases already granted stay valid. A client holding a lease resolves it as it always does, over a fresh connection when its job ends.
• Removing the toolchain: key entirely returns the worker to discovery. A reload builds a fresh configuration from the file, so a key that is gone from the file is a setting that is gone — not one that persists from the previous run.

advertise takes effect on reload, and what that costs

A node does not always know its own address when it starts: one behind a NAT or a load balancer learns its external address later, and one waiting on an interface may have none worth advertising yet. So advertise is reloadable, and a reload does two things rather than one — the worker starts telling clients the new address, and it retires its registration under the old one instead of leaving the scheduler to expire it. With advertise left at auto the node does the same by itself whenever the address it routes from changes, with no reload at all; a reload that changes nothing keeps the address it has moved to. raft_self is reloadable for the same reason, and moves the address peers dial for consensus.

The cost is stated because it is real and it is bounded. advertise is inside the signature of every lease the scheduler has handed out naming this worker, so grants already in clients' hands name the address you have just left. They are honoured until the worker has registered under the new address — at once, not at its next interval — and refused after that, each costing that client one local compile, until they expire. In the deployment this exists for that loses nothing: the address changed because the old one stopped working, so those grants named something nobody could reach anyway. What it replaces is worse — a worker that can never advertise the reachable address without being restarted.

Two things keep it honest. A reload is judged by the startup rules as well, so it cannot advertise something the process would have refused to start with — the wildcard, or a dialable address on a worker whose listen_node binds loopback. And the change is announced in the log, naming both addresses, which is what explains a burst of endpoint-mismatch refusals in the minutes after it.

Why the capacity flags still need a restart

slots, node_class and reserve_cores are resolved against what the cache tier actually holds, which is decided when that tier starts. compile_request_max and compile_inflight_max are fixed when the worker starts, because the compiles already running hold reservations against them. Re-deriving them safely means re-establishing that ordering on a running node, which is a larger change than it looks.

Raising log_level is always safe and takes effect immediately, which is the one you want mid-incident.

Capacity

Say nothing and the worker sizes itself. It takes its hardware threads, clamps that by what its memory supports, and subtracts what its node class reserves:

--node-class	Cores held back	For
workstation (default)	2	a machine somebody is sitting at
dedicated	0	a machine nobody is sitting at

workstation is the default because it is the safe answer, not the common one. A node whose class nobody set is somebody's desktop until proven otherwise, and getting that backwards is a failure the person experiences as "my editor stutters" and never connects to a build fleet. Two cores rather than one: a modern editor, its language server and a browser will each want one, and the point of the reserve is that the machine stays usable while it contributes.

# A build server. Nobody is at it, so drive it to its limit.
pace-node --node-class dedicated ...

# A workstation whose owner wants four cores kept free, not two.
pace-node --reserve-cores 4 ...

# A workstation whose owner wants none kept free. This is NOT the same as
# omitting the flag -- see below.
pace-node --reserve-cores 0 ...

--reserve-cores 0 and omitting --reserve-cores are different instructions. Omitting it means "reserve whatever the class reserves"; typing zero means "reserve nothing". A worker that could not tell them apart would have to pick one, and one of the two answers is somebody's desktop becoming unusable.

The memory clamp

One job per core is wrong on a machine whose cores outrun its RAM. A C++ translation unit with heavy template instantiation routinely peaks in the hundreds of megabytes, so a 128-thread box with 32 GiB asked for 128 concurrent compiles swaps, or the OOM killer takes them — and those come back as refusals the client retries locally, so distribution appears to work while making the build slower than not distributing at all. The worker therefore also caps itself at one job per gigabyte of physical memory. It is deliberately generous enough not to bind on any machine with a gigabyte per thread, which is every ordinary build host.

--slots overrides all of it

A number given to --slots is the answer, not a hint: it is neither capped at the core count nor reduced by the class reserve nor clamped by the memory heuristic. You are the person whose machine this is. Capping it would silently refuse the deliberate oversubscription an I/O-heavy build wants, and subtracting the reserve on top of it would make --slots 4 on a workstation quietly offer two, which is not what the flag says.

Whatever the number ends up being, it is advertised to the scheduler and enforced locally, from one calculation — a worker running to one number while the scheduler leases against another is exactly the overload the cap exists to prevent. A job over the cap is refused rather than queued, because the client has a local compile waiting either way and queueing only hides the overload from the scheduler trying to route around it.

It is also the number this worker actually runs at once. Each admitted compile is handed to a pool of that many threads, so a 30-slot machine serves thirty; the accept loop stays free to answer the thirty-first with a refusal rather than making it wait. Until #213 the loop served each connection inline, which meant a worker advertising thirty ran exactly one at a time — the cap could never be reached, the pace_worker_jobs_refused_no_slot_total counter could never move, and a saturated fleet reported 1 / 30 compiling.

--slots=0 is not a number of compiles: it is no worker at all. Zero used to be refused, because it was how the node spelled "derive this from the machine" — which left no way to offer the fleet nothing, and made the obvious spelling the one value that would have produced a full worker. Deriving is now what omitting the flag does, so zero means what it says. Such a node surveys no compilers, claims no scratch directory, registers with no scheduler and is never leased; pacectl node reports it with no worker component and no slot figures, and a --cordon sent to it is refused as a node that runs no worker rather than as a verb its build does not know. It refuses to start with any setting only a worker reads — --toolchain, --allow-compile-arg or --drain-timeout, say — and names the setting, and it refuses when it would run nothing else either. It announces its own presence where its formation record says it registers, and is refused --scheduler as every node that serves is.

It does appear on the fleet page. A machine announces itself with NodeAnnounce whatever components it runs, so a scheduler-only node is one of the Machines rows and hands its own history to whoever leads -- which is what makes a leader's series survive the election that moves leadership away from it (#1440). Its worker cells on that row are absent rather than zero: it offers no slots because it has no worker, and a zero there would read as a worker that offers nothing and would enter the fleet's own busy/free arithmetic. Its pace_node_slots_configured gauge does read 0, which is a different question with a different right answer -- that one is this node's configured capacity, and zero is what it is.

Memory: what a compile may hold

Slots bound CPU; they do not bound memory, and the two are separate questions now that compiles run side by side. Two ceilings bound memory, and both are options:

Option	Default	What it bounds
--compile-request-max (compile_request_max)	256m, below 4g	One compile request: the size its compressed source declares it expands to. Raising it also raises the frame-length cap the session cap governs on this node's 0xFC port — the listener takes the largest of its components' caps — which moves exactly COMPILE, STORE, FETCH, SHARED-STORE and SHARED-FETCH; every other verb keeps its own fixed bound. Lowering it leaves that cap at the shared cache's 256m, present on every node, and bounds only the declared expansion
--compile-inflight-max (compile_inflight_max)	slots × 64m, never below 256m nor below --compile-request-max	Every compile running on this worker at once, each charged its whole request for the whole compile — from the moment the compile is admitted until it answers, not only while it is being read. (The read itself is charged to the listener's pool below; only the slot, not the bytes, is held until the answer is written.)

The budget is derived from the slot count the worker actually runs — the one --slots names, or the one it derives when --slots is omitted — so a 1-slot worker keeps 256m, an 8-slot one gets 512m and a 30-slot one 1920m. The figure is sized from a measurement: preprocessed with cl /EP, the translation units of a large MFC-heavy Windows codebase run 12.5 MiB at the median, 18.5 MiB at p90 and 21.6 MiB at the largest, so a 30-slot worker needs roughly 375 MiB (median) to 555 MiB (p90), and 648 MiB at the largest, in flight just to keep its slots busy. What a worker is actually sent is preprocessed again with /E, line markers kept, which is larger by an amount that was not measured; the headroom of 64m per slot is what absorbs it. At the flat 256 MiB this budget used to be, one such worker refused 2,246 of the 4,274 compiles it was granted in a single build (#1667). 64m per slot is about three times the largest of those units, and a sixteenth of the gigabyte per slot the memory clamp above already assumes a compile may cost.

# Translation units larger than 256 MiB once preprocessed: raise the request
# ceiling. The derived budget follows it, so one such unit is always admissible.
pace-node --compile-request-max=512m ...

# A worker that should hold more than 64 MiB per slot in flight.
pace-node --compile-inflight-max=4g ...

Both take k/m/g; zero is refused, since a zero ceiling would admit no compile at all, and so is a --compile-request-max of 4g or more, which no frame's 32-bit length could ever reach. A --compile-inflight-max below the larger of --compile-request-max and 256m is refused at startup — and at --install-service — because one request the worker would otherwise take could then never be admitted. The 256m is the listener's frame cap: every node carries the shared cache, whose 256m cap the listener takes whatever --compile-request-max says, so a compile frame that large is read and charged even under a lowered ceiling. Both are restart-only: the request ceiling and the budget are fixed when the worker tier starts, and compiles already running hold reservations against them. The worker states both at startup:

[INFO] worker: 30 slot(s), in-flight compile budget 1920M (derived from the slots), largest request 256M

A request over --compile-request-max is refused payload-too-large and compiled on the client. A compile refused by the budget is told endpoint-busy rather than no-capacity, and counted as pace_worker_jobs_refused_endpoint_busy_total: slots were free and memory was not, so more machines would not have helped. pace-cc --show-stats tallies it as a node had no room for another request (endpoint-busy), apart from withdrawn slots — a tally that also covers a full connection cap, so read the node's own counter: a rising pace_worker_jobs_refused_endpoint_busy_total is the signal to raise --compile-inflight-max.

The node's one 0xFC listener holds its own pool of bytes for frames still being read, sized to the largest budget any of its components declares — so it follows the compile budget and never undercuts it. It is ONE pool: the cache and shared-cache surfaces share it too, so wherever the compile budget exceeds 256m — five or more slots, a raised --compile-request-max, or a typed --compile-inflight-max — a STORE or FETCH being read may hold up to that budget rather than the cache's own 256m, and a large typed budget loosens that bound with it.

Because the compiles now outlive the accept loop, stopping the node waits for them. A stop closes the listener first, so nothing new is admitted, and then waits for every compile still running to finish and answer its client — for at most --drain-timeout, 30s by default, after which it names what it abandons and ends itself (Stopping one, and what a stop waits for). A node stopping while it is full therefore takes as long as its longest running translation unit, up to that bound.

Withdrawing while the machine is busy

The class reserve is static — two cores held back permanently. What happens when the machine's owner starts using six more of them is the other half, and it rides on the heartbeat: every 20 seconds a worker reports its host CPU, its available memory and the free space where it compiles, and the scheduler caps the slots it may be given at what those leave.

Four things about it are worth knowing:

• Somebody else's CPU costs a slot only once it reaches past the headroom the slots leave. The slots are the share of the machine the fleet may have, so the cores it was never offered absorb other work first: --slots=4 on a 32-core machine keeps all four while its owner uses anything up to 28 cores, and a workstation's two-core reserve absorbs the first two cores its owner uses rather than being spent a second time. Oversubscription is kept too: --slots=64 on 16 cores has no headroom, so it offers all 64 while the machine is idle and gives up one slot for each core somebody else is using.
• The fleet's own jobs are subtracted first. Without that, giving a machine work raises its CPU, which withdraws the capacity that let it take the work, which frees the CPU — a fleet that oscillates for reasons nobody can see from either end. So only load that is not this fleet's counts against it.
• A worker can withdraw to zero, and come back. Unlike the registered slot count, which never reaches zero, the live figure may: a machine whose scratch filesystem has filled cannot compile anything, and continuing to send it jobs would only produce refusals. It is picked again as soon as it says so.
• Absent is not zero. A worker whose platform will not report its CPU is scheduled on everything else, not treated as idle or as saturated.

The refusal an operator sees distinguishes the two cases, because the fixes are opposite:

Refusal	Counter	What to do
no-worker	pace_dispatch_leases_no_worker_total	Nothing serves that toolchain — a fingerprint mismatch.
no-capacity	pace_dispatch_leases_no_capacity_total	The fleet is full of your own build. Add machines -- or, where a worker reads limited-by: compile-budget, its compiles hold its --compile-inflight-max instead: raise that on it.
withdrawn	pace_dispatch_leases_withdrawn_total	The machines are there and unavailable — somebody is using them, or a disk is full.
all-excluded	pace_dispatch_leases_all_excluded_total	The machines are there and the clients cannot reach them — a network problem.

Never sum them. withdrawn folded into no-capacity reads as "the fleet is too small", so a fleet whose build hosts have all filled their scratch disks would send you shopping for hardware you already own.

How the scheduler picks

Among workers with a byte-identical toolchain fingerprint, the one with the most free slots wins — not the one running the fewest jobs. Absolute counts treat every machine as an identical box, so a 64-slot server running 8 jobs looks busier than a 4-slot laptop running 2, when the server has 56 slots free and the laptop has none. Across a fleet of mixed machines, which is the ordinary case, that sends work to the smallest machines first and leaves the big ones idle. Equal headroom is broken by utilization, so between two workers with four slots free the one with proportionally more of itself left takes the job.

What it logs, and when

Two flags, one concern. --log-level decides how much — trace, debug, info, warn, error, fatal, default info. --log-timestamps decides whether each line carries when, as an ISO 8601 UTC instant, and is off by default except under macOS. In YAML they are log_level: and log_timestamps:, plus no_log_timestamps: for --no-log-timestamps, which is how to say off where the platform default is on: log_timestamps: false passes nothing and leaves that default.

pace-node --log-level=debug --log-timestamps
2026-09-01T23:10:24.135816Z [ERROR] --no-toolchain-discovery was given and no --toolchain

The timestamp is a prefix, so anything already grepping for [ERROR] keeps working.

Turn it on whenever this node's log is going somewhere that does not stamp it for you. Of the three deployments whose lines come from this logger, only systemd adds a time — its journal stamps every entry, which is why the default is off. macOS's launchd sends them to a plain file that nothing stamps, and the Windows service does not use this logger at all. So turn it on for a foreground run during fleet bring-up, for anything you redirect to a file, for CI artefacts, and on a launchd-installed node until #496 closes.

A completed run cannot be asked afterwards what time anything happened: a leader elected at second 59 and one elected at second 3 that never affirms are the same bytes without times, which is #485 and cost a real diagnosis.

--install-service carries the setting into the registration, so a node installed with timestamps on comes back with them on — they are most wanted exactly when something is being diagnosed, which is the worst time to lose them to a restart.

Conditions

A node detects things an operator has to act on — at startup and while it runs — and a log line is the weakest carrier there is for any of them: it scrolls away, and across forty machines nobody reads forty logs. So each of them is also a condition: a row the node keeps and every surface can ask for (#1364). The log lines are still written; the row is what is still there an hour later.

Every row says two things before anything else:

• latched or live. A latched condition was decided once, for the life of the process, and nothing short of a restart on a different build or configuration clears it — so an operator waiting for it to clear is waiting for nothing. A live one can clear while the process runs, and watching it clear is watching the fix land. The two are drawn differently everywhere, because still broken and was broken and is fixed must not look alike.
• its state: raised (it holds now), clear (checked and benign), not-evaluated (this node runs nothing that could raise it — or, for a fleet-wide row, is not the leader that decides it — and the detail says which), or undecided — nothing evaluated it at all, which is a node wired wrongly and is itself worth reporting. Checked and benign and nobody decided are different claims, so they are different words.

Condition	Persistence	Severity	Raised when	What to do
counter-table-skew	latched	warning	this binary's metrics catalogue carries counters its sink has no slot for — a build mixed from two versions of the counter list (#1362)	rebuild from one clean build tree and redeploy; restarting the same binary will not clear it
scratch-root-unmappable	latched	warning	the worker's scratch root cannot be spelled inside a -fdebug-prefix-map rule, so debug names in objects it builds for other machines record its own path	point TMPDIR (TEMP on Windows) at a path with no whitespace, no = and no control character, and restart
generated-tls-certificate	latched	notice	the admin surface serves a certificate made at startup by --tls-self-signed; the detail carries its SHA-256 fingerprint	compare the fingerprint with your browser's, or name a trusted certificate with --tls-cert and --tls-key
enrollment-window-open	live	alert	an --enroll-auto-approve window is armed, so any machine that asks is admitted under the key it asks with, with nobody comparing it; names the deadline and when it was armed. Not evaluated on a node that does not lead, naming the leader: the window and the list live in the leader's memory	--enroll-list to see who got in (each auto-approved row is marked), comparing each key with the one its machine printed; --enroll-auto-approve=off ends it, and so does a restart or a change of leader
enrollment-requests-waiting	live	notice	machines have asked to join and nobody has decided about them; names them. Not evaluated on a node that does not lead, naming the leader: the list lives in the leader's memory	--enroll-list, comparing each key with the one its machine printed, then the --enroll-approve=<id>@<key> line it prints, or --enroll-reject=<id>; a machine that stops asking for ten minutes is forgotten
unreadable-leader-snapshot	live	alert	this node's build cannot read the snapshot its leader offers, so it refuses it and stays behind — following no change the cluster makes, forgets included, until it can (#1552)	run the build the leader runs; the node catches up by itself once it reads the leader's snapshot, with nothing to move aside
unqualified-host-name	live	warning	peers are told to dial this node at a host name with no domain, which a peer whose DNS search list does not complete it cannot reach	set --advertise and --raft-self (a reload applies both) to a name every peer resolves, or to an address; or give the machine a DNS domain and restart
host-name-reaches-only-this-machine	live	warning	this machine's name reaches only itself (localhost, a name under .localhost, or a loopback address), so nothing offers it to a peer: the node runs as a fleet of its own on loopback (its own consensus, scheduler and worker, so local dispatch works), discovery stands down, it can neither form nor join a fleet, and the worker is announced to no scheduler elsewhere; the detail says what was confined	set --raft-self and, to be announced to a scheduler, --advertise to an address or name other machines resolve (a reload applies both to what the node advertises; the consensus port confined to loopback is bound again only by a restart); or give the machine a real host name and restart
foreign-fleet-visible	live	warning	this node's fleet is established and discovery proves another established fleet on the segment that neither yields to, because no key this fleet holds proves the two are one fleet split in two; or --fleet-id pins this node to another cluster and discovery proves a fleet it would otherwise have joined or healed into. The detail names both cluster ids, and for each other fleet either "no machine in common" -- among the machines it listed, with the cut named, when its summary carried fewer than it records -- the machine of this fleet it CLAIMS to record, unproven, or the pin that keeps this node out. Not evaluated until discovery has listened one beacon interval, nor while no discovery reply has been heard for five minutes: an empty segment and a firewalled one look alike	decide which fleet each machine belongs to and --cluster-forget it from the other; for a fleet the pin keeps this node out of, change --fleet-id if it names the wrong fleet, and otherwise the pin is doing its job. It clears a few minutes after the other fleet stops being heard
shared-cache-unavailable	live	alert	the fleet's shared-cache setting names this machine and its shared tier will not open, so every other node's builds miss and compile locally; the detail says why	fix what the detail names — usually another process holding <state-dir>/shared-cache, or a full disk — and it opens at the next change the cluster applies or within 30 seconds; or name another machine with --cluster-set shared-cache=<id>
shared-cache-unproven	live	warning	the fleet's shared-cache setting names another machine and this node's builds are not reaching it, so they compile locally; the detail says why — a machine at the announced address that proved another key (nothing was sent to it), the named machine refusing this node's key, one that did not answer, or a setting naming a machine this cluster cannot reach by key	check --cluster-status and the named machine's own pacectl node; it clears by itself at the next operation that proves the named machine's key, and at the apply that stops the setting naming another machine; an apply that names a different machine, or resolves one this cluster could not reach by key, makes it not-evaluated (not tried) until an operation tries it, never clear; a setting naming a machine this cluster cannot reach by key raises it at the apply, before any build asks; an operation still running when an apply moved the setting says nothing about the machine it had dialled
scheduler-unreachable	live	warning	a --scheduler endpoint (or a leader it named) has not answered a dial; the detail names each, and one nobody has dialled for ten minutes is dropped from it	check the VPN or network between this machine and the schedulers named; the node keeps serving this machine meanwhile and rejoins by itself
unserved-toolchain	live	warning	clients asked the leader for a toolchain no live worker serves, so those compiles ran on the clients' own machines; the detail names each by driver and version as the client reported it (cl 19.44.35207), with how many leases were refused. Decided by the leader; any other scheduler answers not-evaluated, and so does a leader that has led for less than fifteen minutes, since nothing another leader saw carries over	put that compiler version on a worker, or move the clients to one the fleet serves; clears once a worker serves it, or after fifteen minutes with nobody asking
mixed-node-versions	live	warning	the leader sees more than one build serving one wire — nothing refuses that, so nothing else says so; the detail names each build and the machines on it. Decided by the leader; any other scheduler answers not-evaluated, and so does a leader that has led for less than ninety seconds, before every machine has announced to it	upgrade every node to one build (Upgrading a fleet); clears once the odd machine is upgraded or has been gone ninety seconds
own-record-awaited	live	warning	a consensus node that registers with a scheduler announces to nobody until its own cluster records its key, and it has waited longer than an election explains — or its cluster records its id under another key, its node-key replaced while the id survived, which is raised at once	bring back a majority of the cluster's voters, or admit a joining machine (--enroll-approve, or --cluster-admit with what --print-identity prints); for a replaced key, restore that node-key or --cluster-forget=<id> and admit the new one
refused-compile-arguments	live	warning	the worker refused compiles over arguments it will not pass to its compiler; the detail counts them and names each argument -- every argument a compile was refused over, not the first, while a compile refused over several still counts once and stays counted until all of them are admitted -- and the log says each one once	builds stay correct, each refused compile running on its own client; admit an argument that runs no program and names no path with --allow-compile-arg and reload; the reload re-judges the row, each admitted argument leaving it, and the row clears only once every argument it names is admitted. The list never overrides the built-in rules, so an argument they refuse stays named; clang-cl's -clang:<argument> is judged by the argument it passes
surface-not-accepting	latched	alert	a serving surface's accept loop has ended while the node was not shutting down: its port still listens and the kernel refuses every client. The detail names each surface and what its last accept answered	restart the node, and report the reason with the node's version — only a closed or vanished listener is meant to end a loop. /healthz answers 503 while it is raised
surface-accept-degraded	live	alert	a serving surface's accept loop has failed to accept for longer than any transient explains, on a failure this build does not classify, and backs off: it accepts little or nothing. The detail names each surface and what its last accept answered	check the host for exhausted file descriptors or memory, and report the reason with the node's version so the failure can be classified. The row clears by itself once an accept succeeds. /healthz answers 503 while it is raised
fleet-split-healing	live	warning	this fleet and another established one are one fleet split in two, by a key this fleet already held: its speaker is a VOTER recorded here under that key, which heals by itself -- the detail names which side yields and why -- or its speaker is a LEARNER here, or a machine of this fleet once asked it and it lists that machine, which are first-use trust and wait on an operator -- the detail names the machine the evidence rests on. Not evaluated, as foreign-fleet-visible is, until discovery has heard enough to say there is none	where it heals by itself, nothing: the yielding fleet dissolves and rejoins by itself, and a machine the survivor did not record waits on its --enroll-list. Where an operator decides, nothing moves until one does: ask the named machine which fleet it belongs to and check the other fleet with --cluster-status; if it is yours, --cluster-forget each machine of the fleet that does not stay and approve it on the survivor's --enroll-list. It clears a few minutes after the other fleet stops being heard
consensus-leader-silent	live	warning	no leader this node's applied configuration counts has spoken to it for longer than it may trust that state (65 minutes, LeaderSilenceBound), so every lease grant it is handed is refused -- a voter its fleet forgot meanwhile could still be in the state it holds. The start counts as contact, so a node starting cut off has the same 65 minutes. The detail says how long it has been	restore its Raft sessions to the fleet: check the network path to its voters and --cluster-status on one of them. Compiles sent to it fall back to their own machines meanwhile; it clears at the first leader contact
state-directory-unsynced	latched	warning	the filesystem holding the state directory answers a directory sync with "not supported here" (EINVAL, ENOTSUP, EBADF from fsync; ERROR_INVALID_FUNCTION, ERROR_NOT_SUPPORTED, ERROR_INVALID_PARAMETER from FlushFileBuffers), so a replaced state file is not known to survive a power loss: every replace still lands and is used. The detail names the directory and the answer; also counted in pace_state_directory_syncs_unsupported_total	stop the node, move the state directory whole to a local volume (it holds the node's identity, so a new empty directory is a new machine), point --cluster-dir at it and start; restarting on the same volume does not clear it
formation-move-refused	live	alert	a move of this node's formation -- to the mode the detail names -- was not taken, because the startup rules refuse the shape it would give this node: a restart into it would be refused, so the node keeps the mode it is in. Every move is judged this way before its record is written, whether or not it rebuilds the node; the detail names the rule	fix the rule the detail names and restart this node; until then it keeps the mode it is in rather than serve a shape its next restart would refuse

The remedy each row carries is longer than this column, and it is the node's text: an older client or leader prints a newer node's row exactly as that node wrote it, rather than looking it up in a table of its own.

A node with nothing raised says so — none raised — and a node too old to carry conditions says nothing, which every surface draws as absent. The two are opposite readings: the first has been checked, the second cannot vouch for anything.

Three places answer:

• pacectl node carries a conditions field naming each raised condition with its persistence, and pacectl node-conditions lists every row with its detail and remedy, exiting no when none is raised so a loop over machines can test it.
• The fleet page (below) opens with a Conditions panel, filed per machine: what each machine that has something raised reports, with its severity, persistence and remedy; how many report nothing raised; and, apart, which machines report no conditions at all. Every row every machine sent follows behind a disclosure, and /fleet.json, /fleet.txt and pacectl fleet conditions carry the same rows. Every machine sends its rows with the announcement it makes whatever it runs, so a machine with no worker is on it too.
• pacectl live-stats node carries a conditions line under the node's identity.

One candidate is not a condition yet. --fleet-seed naming a literal seed address rather than a stable name is invisible until the day that host is retired, but no part of this node detects it, and a row with no detection behind it would be a condition that can only ever read undecided.

Watching one

--admin-listen serves /metrics and /healthz, and is off unless you ask for it: a scrape surface reachable from the network is a decision, not a default. A bare port binds loopback, so --admin-listen 6677 is reachable from the machine and nowhere else; write --admin-listen 0.0.0.0:6677 when you mean the network.

pace-node --advertise worker-01.internal:6674 \
                       --cluster-dir /var/lib/pace-node \
                       --admin-listen 6677
curl -s localhost:6677/healthz     # 200 while every surface accepts; 503 naming any that stopped
curl -s localhost:6677/metrics     # Prometheus exposition

It is the same endpoint and the same renderer the daemon serves. A node that runs no cache tier at all reports the cache series as absent rather than present and zero, which a dashboard would otherwise read as an empty unbounded cache rather than as no cache at all.

/healthz is worth wiring even if you never scrape: without it a supervisor can tell that the process is alive but not that it is answering, which is the state a wedged worker is in. It is what systemd's and Kubernetes' probes want.

A listening port is not a serving one, and /healthz answers the second question. A surface whose accept loop has ended still shows LISTENING while the kernel refuses every connect -- the installed node sat in that state for nine hours answering 200, while every build on the machine fell back to compiling cold. So /healthz answers 503 Service Unavailable naming each surface that has stopped accepting and what its last accept answered, and the surface-not-accepting condition says the same on every surface that lists conditions. Only a closed or vanished listener ends a loop now; a client that reset its queued connection is logged at Warn (rate-limited) and accepted past, and an accept that ran out of descriptors or memory is backed off on. A failure this build does not classify is backed off on too, and once a run of them outlasts any transient the surface is degraded: /healthz answers 503 naming it as such, and surface-accept-degraded is raised until an accept succeeds.

A node that works for other machines and has no --admin-listen says so once, at startup. Nothing is wrong with such a node — it does exactly what it was configured to do — but nothing off its own machine can see any of that, so over a fleet this is opt-in monitoring whose failure mode is silence (#1304):

[INFO] this node works for machines other than this one and opens no admin surface:
/healthz, /metrics and the fleet dashboard are all served on --admin-listen, which is
off unless asked for. …

It is a remark rather than a refusal, and the default is deliberately not flipped: binding a port nobody asked for is the decision this binary refuses everywhere, and a default --admin-listen beside --dashboard would either publish the fleet page unauthenticated or make --dashboard-token-file mandatory on every install.

A node whose policy admits only its own machine — the single-machine install — is never told, since it has nobody else to be observable to. Registering with a scheduler is not what decides that, because every worker does.

Every other series a node exports

The tables below complete the set: every pace_* series a node renders that is not covered by the refusal table or the cache-tier discussion above. They were exported and documented nowhere until #553 — a counter an operator never learns exists, which costs the same as one they are told to scrape that never appears.

MetricsDocumentation_test now fails in both directions, so this page and the exposition cannot drift apart again without a red build.

What the worker did. The compile surface's throughput. ..._compile_milliseconds_total beside ..._jobs_completed_total is a duration as a _sum/_count pair — a rate over either window gives the mean for that window, which is what a gauge of "the last compile took N ms" cannot do.

Series	Says
pace_worker_jobs_started_total	Compiles this worker handed to its runner. NOT the running count when differenced with jobs_completed_total: a refused job increments this one only, so the difference drifts up and never returns. Use the pace_node_slots_busy gauge for what is running now.
pace_worker_jobs_completed_total	Compiles that finished, whatever the compiler concluded. Also the count half of the compile-time sum below.
pace_worker_compile_milliseconds_total	Total wall time spent compiling. Divide by jobs_completed_total, or take rate() of both, for the average compile.
pace_worker_jobs_abandoned_client_gone_total	Compiles whose client had disconnected before the object could be written back. The compile itself still counts in jobs_completed_total -- the compiler ran and this machine paid for it; only the delivery found nobody there. Never a refusal: nothing was declined and no reply was sent.
pace_worker_bytes_received_total	Request payload bytes read from clients.
pace_worker_bytes_returned_total	Reply payload bytes written back to clients.

Compiles this node would not run. Refusals decided after the request was understood. Each names a different thing to go and fix, which is why they are not one counter.

Series	Says
pace_worker_jobs_refused_rejected_argument_total	Jobs refused over an argument this worker will not pass to a compiler.
pace_worker_jobs_refused_scratch_unavailable_total	Jobs refused because the scratch directory could not be prepared: a full or read-only disk, not a client or fleet problem.
pace_worker_jobs_refused_spawn_failed_total	Jobs refused because the compiler could not be spawned: the toolchain this worker advertises is not usable here.
pace_worker_jobs_refused_compiler_unclassified_total	Jobs refused because this worker cannot classify the compiler its own --toolchain names: it ran, and this build does not recognise which driver it is. Not a path fault -- see pace_worker_jobs_refused_spawn_failed_total for that one.
pace_worker_jobs_refused_survey_in_flight_total	Jobs refused because this worker had not finished identifying its toolchains: it is still starting, not misconfigured. Rises only from clients dialling this port directly -- the scheduler is not offered this worker until the survey completes.
pace_worker_jobs_refused_not_a_member_total	Connections refused because the caller is neither on this machine nor a cluster member. A rise means something is trying to spend a machine it has no claim on.
pace_worker_jobs_refused_stopping_total	Jobs refused because this worker had begun stopping. Never sum with no_slot: that one says the fleet is too small, this one says a node is draining and a retry will land somewhere else.
pace_worker_jobs_refused_cordoned_total	Jobs refused because an operator cordoned this worker. Never sum with stopping: a stop ends by itself, a cordon lasts until somebody lifts it. A steady rise says the scheduler is not hearing this worker's heartbeat.
pace_worker_cordons_refused_not_local_total	Cordon requests refused because they came from another machine. A machine is cordoned from itself; a rise means somebody elsewhere is trying to take it out of the fleet.

A dispatched compile whose envelope or lease did not hold. The envelope rows are about the bytes; the lease rows are about the credential. A rise in a lease row on a healthy fleet names a clock, a roster or a rollout rather than a client.

Series	Says
pace_worker_jobs_refused_envelope_malformed_total	Jobs refused because the request's codec envelope could not be parsed, or an uncompressed one disagreed with the bytes beside it: a version skew, or a peer not speaking this protocol.
pace_worker_jobs_refused_envelope_unsupported_codec_total	Jobs refused because the payload is in a codec this build cannot decode: two honest processes packaged differently. Every one cost a local compile.
pace_worker_jobs_refused_envelope_declared_too_large_total	Jobs refused because the envelope declared it expands past this endpoint's ceiling, before a byte was decompressed. Nothing honest declares that by accident: read it as a probe or a mis-set client.
pace_worker_jobs_refused_envelope_corrupt_total	Jobs refused because the payload did not expand to its declared size. The only envelope refusal that implicates the transport: a codec version skew, or a link damaging payloads.
pace_worker_jobs_refused_lease_unauthorized_total	Jobs refused because the lease was not signed by any voter this worker's roster names. A security signal, not a capacity one -- or a launcher predating this lease format, which presents a token that cannot authenticate.
pace_worker_jobs_refused_lease_unregistered_total	Jobs refused because this worker has not registered and so knows no fleet. A few at startup are ordinary; a rise that does not stop means the scheduler is unreachable and this node is compiling nothing while looking alive.
pace_worker_jobs_refused_lease_wrong_cluster_total	Jobs refused because an authentic lease was issued by a different fleet. Every grant is signed by a voter's own identity key, so a rise means one key votes in two clusters -- a --cluster-dir copied to a second site, which copies the node and its key with it.
pace_worker_jobs_refused_lease_replayed_total	Jobs refused because an authentic, unexpired lease had already been spent at this worker. A lease authorizes exactly one compile, so nothing honest produces this and it should read zero forever; any rise is a captured grant presented a second time.
pace_worker_jobs_refused_lease_endpoint_mismatch_total	Jobs refused because an authentic lease named a different worker. Usually a registered endpoint that is not the one clients dial, not a replay.
pace_worker_jobs_refused_lease_expired_total	Jobs refused because an authentic lease had expired. A rise on one machine and nowhere else is that machine's clock, not the fleet's leases.
pace_worker_jobs_refused_lease_isolated_total	Grants refused because this worker has heard from no leader its fleet counts for longer than it may trust the state it applied (65 minutes), so a voter the fleet forgot meanwhile could still be in it. Should read zero; a rise means this worker is cut off from its fleet's consensus -- check its Raft sessions -- while something still hands it grants.
pace_worker_jobs_refused_lease_no_roster_total	Grants refused because the state this worker applied records no voter's key yet, so no grant from anybody could verify. A few while a node starts or joins are ordinary; a rise that does not stop means this node never applied its fleet's state.
pace_worker_jobs_refused_lease_signer_revoked_total	Grants refused because they verify under a key the cluster has revoked: the removed machine itself, still leasing out work. Should read zero forever; a rise names a machine somebody removed and nobody stopped. Shares its wire code with ..._unauthorized_total and nothing else.
pace_worker_scheduler_term_regressions_total	Times this worker adopted a scheduler term that went backwards. Not a refusal — the grant is served. Two causes look identical here and the rate separates them: a grant minted before a leadership change and delivered after one is ordinary and appears as occasional counts tracking elections; a scheduler that was reset repeats until somebody stops it.

Lease and roster series were retired: one by #614, because a worker now adopts a scheduler term that went backwards instead of refusing it, and five with the certified roster, because every node verifies grants against the state its own consensus applied, which nothing certifies and nothing lapses. They are named, with what to point their alerts at instead, under "Retired series" in Distributed compilation. They are deliberately not spelled here: every name on this page is a series you can scrape, and ctest -R metrics-documentation enforces that in both directions.

Frames the compile surface would not read. Decided before or during framing, so none of these reached a verb.

Series	Says
pace_worker_frames_refused_unsupported_version_total	Frames refused for naming a protocol version this build does not serve: a peer built against another release.
pace_worker_frames_refused_truncated_total	Frames shorter than the payload their own header declared: a framing or transport fault, or a peer sending nonsense. Never sum with malformed_payload -- they share a wire code and nothing else.
pace_worker_frames_refused_unknown_opcode_total	Frames naming an opcode this build has no row for.
pace_worker_frames_refused_unimplemented_verb_total	Frames naming a verb that exists and is not served here, such as AUTH on a worker that checks no credential.
pace_worker_frames_refused_not_permitted_total	Frames naming a verb this node serves on another surface: a client reached the compile port with a cache or scheduler request.
pace_worker_frames_refused_malformed_payload_total	Frames whose payload did not decode into the fields its verb requires: a version or encoding mismatch between two ends that agree on the framing.

Connections swept on a deadline. A sweep is not a refusal: the peer ran out of time rather than being told no. The two sweep rows are split by whether a verb had been named, because a peer that connected and never spoke is a different problem from one whose answer outran its window.

Series	Says
pace_frame_request_deadline_sweeps_total	Connections swept before the peer named a verb. A peer counted here connected and did not speak, so no honest client of this surface appears in it. Never sum with answer_deadline: that one is a request this node accepted outrunning its budget, this one is a knock at the door.
pace_frame_answer_deadline_sweeps_total	Connections swept after the peer named a verb, meaning the answer outran the window that verb allows. For a compile that is a translation unit outliving its lease grant, so a rise is a question about the lease timeout rather than about this worker.
pace_frame_deadline_refusals_sent_total	Swept connections whose peer was sent a frame saying why. A second event, not a restatement of answer_deadline_sweeps: only a connection parked inside the surface can be told, because a connection parked on the socket is ended by the close and the close is the write side gone. The gap between the two is how many swept peers were left to infer it.
pace_frame_peer_watch_departures_total	Peers the watch saw leave while the connection could still act on it: the observation, where jobs_abandoned_client_gone is the decision. Subtract the second from the first for what was suppressed on purpose -- an empty reply, or a socket this node closed itself. A client that vanished and was NOT noticed is this row flat while the object was written anyway. It does not rise for a client that hangs up after reading its reply, which is every honest one.
pace_frame_peer_watch_departures_observed_total	Every peer departure the watch reached, before either suppression -- the denominator the row above cannot supply for itself. That row flat is both the healthy reading and a watch that never ran; this one rising is what says the mechanism is live, and on a healthy surface it rises once per compile. Subtract for what was suppressed on purpose. Never below the row above. A watch that ended because the peer sent bytes is a pipelined request and appears in neither.
pace_frame_peer_watch_departures_abortive_total	Of the row two above, the departures where the peer RESET rather than closing gracefully. A subset under the same suppressions, so it is never above that row and subtracting gives the graceful half. This is the half worth alerting on: a graceful mid-answer departure is a cancelled build, a Ctrl-C or a reclaimed CI runner and its rate means nothing, while a rise here is crashing clients, a machine losing its route, or a middlebox resetting long-lived connections.

What this machine is, and how loaded it is. Rendered only by a process that has a capacity to report, so a daemon emits none of them — MetricsSnapshot::host is absent there rather than zeroed, because cores a daemon does not schedule against are not a fact about it. These are gauges, not counters, except the two CPU tick series.

Series	Says
pace_node_logical_cores	Schedulable hardware threads on this node.
pace_node_memory_total_bytes	Physical memory, or the container ceiling when that binds first.
pace_node_disk_capacity_bytes	Size of the filesystem this node compiles on.
pace_node_disk_free_bytes	Space on that filesystem an unprivileged process may still write.
pace_node_slots_configured	Concurrent compiles this node advertises to the scheduler.
pace_node_slots_busy	Compiles running right now — sampled, so it is a reading and not a difference of two counters.
pace_node_cordoned	1 while an operator has cordoned this node's worker, 0 otherwise. Read beside pace_node_slots_busy: cordoned with compiles running is draining, cordoned with none is safe to stop. A restart clears it, so == 1 for a day is a machine somebody forgot.
pace_node_cpu_busy_ticks_total	Host-wide CPU ticks spent doing anything but idling, this node's own compiles included. A counter in platform ticks, whose length differs per platform, so it means nothing alone: rate(pace_node_cpu_busy_ticks_total[1m]) / rate(pace_node_cpu_ticks_total[1m]) is the machine's busy share. Absent when the platform would not report its CPU.
pace_node_cpu_ticks_total	Host-wide CPU ticks accounted for at all: the denominator of the row above.
pace_node_memory_available_bytes	Memory a new process could actually obtain: available, not free, so the page cache the kernel hands back on demand counts. Absent when the platform would not say.

The CPU figures are raw counters rather than a utilization on purpose. A utilization is a difference between two readings, so the node would have to hold the earlier one, and the scrape, every pacectl live-stats subscriber and the node's own heartbeat would then each read whatever interval the last of them left. Every reader takes its own difference instead, which is also what live-stats does to name the limit a node's free slots are bound by.

What this node counts as its own cluster. Rendered only by a node that runs consensus — a node started without --listen-raft runs no scheduler, holds no configuration, and emits none of these. Gauges, all of them, and sampled per scrape.

This is a different question from --cluster-status, and confusing the two is the gap #435 records. --cluster-status reports the fleet's member record from the replicated state, and only the leader answers it — so the one node whose view you need when a cluster will not re-elect is the one that redirects you elsewhere. These series are the quorum, answered by whichever node you scrape, leader or not.

Series	Says
pace_node_consensus_members	How many members the configuration this node operates under names — voters and learners alike. 0 is a reading, not an absence: the node holds no configuration, so it stands for no election and grants no vote. That is the ordinary waiting state of a node that joined a fleet before it is admitted, and a fault for any other — see the alert below.
pace_node_consensus_term	The election term this node is operating in. A gauge and not a counter: wiping --cluster-dir legitimately resets it, and a counter that resets renders as a spike of its whole history.
pace_node_consensus_commit_index	How far this node's replicated log is committed. Far behind its peers means it is being caught up rather than taking part.
pace_node_consensus_role	One sample per role — follower, pre-candidate, candidate, leader — with exactly one of them 1. A node cycling between candidate and follower is a cluster that cannot settle.
pace_node_consensus_member	One sample per member of that configuration, carrying its id and its seat — voter or learner. The set rather than only its size, because "which members does this node count" is what you ask when an election will not resolve, and since learners exist the seat is half that answer: count by (seat) says how many a quorum counts. No samples at all when the configuration is empty.
pace_node_consensus_leader	The member this node believes leads. Absent when it believes none does, which is what an election in progress looks like — not an empty label, which a dashboard would draw as a member.

The alert worth writing is pace_node_consensus_members == 0 sustained on a node that is not currently being admitted. Such a node has been admitted to the fleet and never adopted the configuration: it answers cluster verbs, it names the leader correctly, and it is excused from every deadline, so it neither campaigns nor answers a pre-vote (#388). Nothing is wrong until the leader goes, and then the cluster cannot re-elect. The second one worth writing is the whole fleet disagreeing about pace_node_consensus_leader{leader=...} for longer than an election takes.

The enrollment window

Two counters, both of them events rather than readings, so they belong here and not in the gauge table above. What a window is — open or shut, and how many machines are waiting in it — is reported by pacectl node and by the window's own repeating warning, because that is a state and a counter cannot carry one.

Series	Says
pace_enrollment_rosters_served_total	An approved joiner was handed the roster. Per roster SENT, not per machine: an approval is answered on every poll, so a joiner whose reply was lost and asked again counts twice. It carries no secret, so a rise past the machines anybody approved is a retry rather than a leak -- and the pending list names who asked.
pace_enrollment_approvals_manual_total	A joiner an operator admitted by name with --enroll-approve, counted once the cluster agreed to record it under the key it asked with. A refused approval admitted nobody and is not counted.
pace_enrollment_approvals_auto_total	A joiner an armed --enroll-auto-approve deadline admitted on the leader's own authority, under the key it asked with first. Counted apart from the manual approvals, because the question after a window is who got in while nobody was looking; --enroll-list marks each such row with when the window was armed.
pace_enrollment_requests_refused_host_cap_total	A request refused because its address already had 4 requests nobody had decided about on the list. Apart from the full-list series because the cause is one address asking a lot — a NAT or a VM host rolling out more than a handful at once, or a flood — where a full list is many machines waiting.
pace_enrollment_requests_cleared_total	Requests --enroll-clear dropped: rows nobody had decided about, forgotten on an operator's word. The leader's log names the ids.
pace_enrollment_approvals_refused_key_mismatch_total	An approval refused because the key it named is not the key the row under that id holds, so nothing was admitted. The machine asking under the id is not the one the operator compared — most often because that one stopped asking, its row lapsed, and another machine asked under the same id.
pace_enrollment_requests_refused_id_too_long_total	A request refused because the id it named is longer than every id this fleet carries may be. Refused where it enters, so the list never shows a row --enroll-reject could not name; a machine that keeps sending one was not minted by this software.
pace_formation_yields_total	Times this node decided to ask another fleet to admit it: while solitary it proved a fleet it yields to — an established one, or an older solitary one — and recorded the join before asking. More than one on a machine that should have joined once is a fleet that keeps refusing it or stops answering.
pace_formation_joins_abandoned_total	Joins this node gave up because the fleet it asked gave no answer it signed for ten minutes: silence, or only what nobody signs -- a full list, a not-leader, a redirect. It stays in its own cluster, keeps serving, and asks again when it next proves a fleet it yields to.
pace_formation_admissions_refused_total	Admissions this node did not believe although they were signed by a key it proved for that fleet: the roster does not record it under its own key, or records no member under the key that proved the fleet. The fleet answered, wrongly — an approval of another key for this id, most often. A roster copied by somebody else is not counted here: it carries no signature the fleet made, and is admissions_unverified below. Nothing was archived; the node stays in its own cluster, and gives the join up if it goes on.
pace_formation_admissions_unverified_total	Answers to this node's join — an admission, a refusal or a not-yet — it refused because nothing bound them to the fleet it asked: no signature, one that does not verify over this node's own request and the outcome it states, or a genuine one by a key it never proved for that fleet. Such an answer counts as no answer: a refusal does not send the node away, and a not-yet does not keep it waiting. Nor does any other answer nobody signed -- a full list, a not-leader naming nobody, a redirect: those count towards giving the join up too, though they are not counted here. A roster is public — every member's id and key rides every beacon — so its content alone cannot say who answered; the signature, over a nonce this node chose, by a key it proved for that fleet, is what does. A rise is something answering at the endpoint this node polls that is not that fleet. Nothing was archived; the node stays in its own cluster, and gives the join up if it goes on.
pace_formation_yields_refused_pin_total	Proven fleets this node would have asked to admit it and did not, because --fleet-id pins it to another cluster. Counted per proof, so a fleet that keeps beaconing keeps counting. A steady rise is a fleet on this segment the pin keeps this node out of — a second office, or somebody proving an older fleet to be joined; foreign-fleet-visible names it.
pace_formation_admissions_refused_pin_total	Moves into another cluster this node refused because --fleet-id pins it elsewhere: an admission from a fleet the pin does not name, or its own fleet's order to dissolve into one. Nothing changed; the node stays where it is, and the log names both ids.
pace_state_file_replaces_fell_back_total	Serving bodies that found, as they started, that the state files in this node's directory are replaced by the classic rename because the POSIX-semantics one was refused — a filesystem without it, or a path form it will not take. Every replace still lands; on Windows a reader holding a state file open then makes its replace fail. The warning names the directory and the refusal.
pace_state_directory_syncs_unsupported_total	Serving bodies that found, as they started, that the filesystem holding this node's state directory cannot sync a directory at all, so a replaced state file is not known to survive a power loss there. Every replace still lands and is used. The warning names the directory and the answer; a local volume syncs.
pace_enrollment_requests_expired_total	A request the leader forgot because its machine stopped asking for ten minutes before anybody decided about it — switched off, or given up waiting for a person. A machine that asks again is recorded afresh; a row somebody decided about goes quietly.

Both are rendered by every node, consensus or not, and read zero on a machine that has no window at all. That is deliberate and is this project's rule rather than an oversight: a counter is a tally, so zero is the truth about events that never happened, and absence is modelled in the snapshot rather than by dropping a row. Which of the two a zero means is answered by pacectl node, whose enrollment field is absent on a node that serves no enrollment, manual on one that does, and auto-approve (N min left) while a deadline is armed — the distinction a counter cannot carry, kept where it can be.

Discovery

Three counters, each a discovery proof that answered a challenge this node issued and was not accepted (#178), one for beacons that reached a bound, and one for replies this node withheld. None of them is a membership change: discovery reports, and only an operator admits. They are rendered only by a node that runs discovery; anywhere else no writer exists, so the rows are absent rather than a zero that claims nobody tried.

Series	Says
pace_discovery_proofs_refused_unknown_key_total	A peer proved possession of a key the roster does not hold for the id it claimed. The ordinary cause is a new machine nobody has admitted yet: enrol it, or --cluster-admit it under the key the warning names. The other cause is a machine claiming a known member's id under its own key, and the log line -- id, the address it came from, the key whole -- is what tells them apart. Logged at most once a minute with how many it stands for; every one is counted.
pace_discovery_proofs_refused_revoked_key_total	A peer proved possession of a key the roster has REVOKED. The remedy is the opposite of the row above: that machine was removed and is never admitted again under that key, so a rise is a decommissioned machine still running, or one somebody restored from a backup of its state directory.
pace_discovery_proofs_refused_forged_total	A proof whose signature does not verify under the key it carries. An honest node cannot produce one, so it is somebody sending datagrams by hand, or a build that disagrees about the signed message -- which moves the discovery wire's version when it changes, so it should not happen between two builds of this project. Logged by the address it came from and nothing it claimed.
pace_discovery_beacons_over_bound_total	A beacon that reached a bound. At a bound the oldest entry nothing vouches for is displaced -- a peer of this cluster the roster holds no key for, another fleet that has proven nothing -- and a new fleet is dropped only when every remembered fleet has answered a challenge; what the roster or an answer vouches for is never displaced. A beacon is unauthenticated, so every table it grows is one anything on the segment can try to fill by inventing ids, and an overflow is counted rather than logged. One series for every bound: it says a flood is under way, not which table it reached. A healthy segment produces none, so a rise is somebody flooding the beacon port.
pace_discovery_replies_withheld_total	A challenge or a proof this node did not send. A reply goes to whatever address its request came from, and that address is whatever the sender typed, so no reply is larger than the datagram that provoked it -- a beacon is padded to its sender's proof, a challenge to the beacon, and a proof that would still exceed its challenge is withheld -- and answers, each a signature, are rate-limited, a burst and then a steady refill, so a flood buys this node few signings and its victim few proofs. Two builds of this project never trip the size rule against each other, save once and briefly when a node's summary grows between its beacon and its answer; a steady rise is somebody sending challenges by hand, or a flood of them.
pace_discovery_proof_checks_withheld_total	A proof whose signature this node did not check. It answered a challenge this node issued and had not yet spent, but the check budget was spent -- first the budget of the host it came from, then the one every proof shares -- or that challenge had already failed two signature checks. A forged proof spends no challenge, so without these one live challenge would buy a signature check per datagram; with them a flood costs this node a few percent of a core at most, and a challenge a forger exhausted is simply asked again at the next beacon. A healthy segment produces none; a rise is somebody sending proofs faster than this node checks them, most likely forgeries against one challenge, and a warning names the address they come from.

What a refused connection looks like

These are what a probe of that port looks like from outside the machine. They are separate series rather than one refused_total because an operator does a different thing about each; several of them share a wire code, and every such group is named below so a dashboard grouping by the code in a client log does not quietly merge two things you would act on differently.

Read the "counted for" column before alerting. The listener routes each refusal to the component that owns the verb, and the components do not all count the same things — a deliberate split, not an oversight, but one that decides what an alert can see. The frame ceiling and the byte budget have a row per surface rather than one row each, because a cache STORE that overran its ceiling counted against the compile surface names the wrong subsystem, and naming the subsystem is what these series are read for.

The scheduler surface is the one where they move nothing, and on purpose: its frame ceiling says the peer is confused about the framing rather than about the fleet, and its byte budget says the surface is momentarily full, which the peer sees and retries — summed into the scheduler's security series, either would make that series unreadable. Both state that reason in the code: the byte-budget row is held to it by a static_assert, and the frame ceiling is answered through RefuseWithoutCounter, which the worker-refusals scan holds to stating its reason. So a flat scheduler graph is not a claim that the surface is quiet. The cache surface was uncounted until #491, and it was the gap that mattered most: the listener's in-flight ceiling is the largest of the components present — the cache's 256 MiB, or a worker's compile budget wherever that is larger — and on a node holding a tier the byte-budget refusal that fires in practice is a cache STORE.

Series	Says	Counted for
pace_worker_frames_refused_payload_too_large_total	A header declared more payload than the surface will buffer, so nothing was read. The cheapest probe there is — it needs 24 bytes where the envelope series needs a whole frame sent and read — which is why it has its own counter rather than leaning on them.	compile verbs
pace_worker_jobs_refused_endpoint_busy_total	A request would not fit in the bytes already in flight. A slot was free and the memory was not, so more machines would not have helped.	compile verbs
pace_node_frame_connections_refused_at_capacity_total	The listener already holds every connection it will, so a new one was turned away before it sent anything.	every verb — it is decided before one is named
pace_node_cache_requests_refused_payload_too_large_total	The cache surface's half of the frame ceiling. On a node holding a tier this is the one that actually fires, and it needs 24 bytes and no body to move.	cache verbs
pace_node_cache_requests_refused_endpoint_busy_total	The cache surface's half of the byte budget: a STORE that would not fit in the bytes already in flight. The listener's ceiling folds to the largest component's — the cache's 256 MiB, or a worker's compile budget wherever that is larger — and a STORE is what runs into it.	cache verbs
pace_node_cache_requests_refused_unsupported_version_total	A cache request at a wire version this build cannot decode — a client from another release. Worth alerting on because the launcher steps over it and compiles locally, so the only other symptom is a cache that looks permanently cold.	cache verbs
pace_node_cache_requests_refused_malformed_payload_total	A FETCH or STORE body that would not decode, in a frame whose declared length arrived in full. Two ends that agree on the framing and disagree about what goes inside it.	cache verbs
pace_node_cache_requests_refused_foreign_generation_total	A STORE whose value names a canonicalization generation this build does not implement — the value-format twin of the unsupported-version row above, and the same operator action: find the machine that is out of step. Answered foreign-value-generation, never malformed-value: the value is well formed and the fleet is mid-upgrade, so reading it as a damaged cache is the one wrong move. Flat at zero unless the fleet spans a CompileValueVersion bump, so any rise is a real event. It is also the only view of what refusing costs, since the launcher reports a miss and compiles locally.	cache verbs
pace_enrollment_requests_refused_full_total	The pending list already held every entry it will. A rollout larger than the list is the honest cause, fixed by deciding in batches; many addresses each holding their share is the other, and --enroll-clear makes room. One address asking a lot is the host-cap row instead.	ENROLL
pace_enrollment_requests_refused_malformed_total	An ENROLL payload that would not decode, one naming no id or no address, or one asking under a small-order or non-canonical key, which no build mints. Flat at zero against this project's own client, so a rise is another implementation or a probe shaped like one.	ENROLL
pace_enrollment_requests_refused_forged_total	An ENROLL whose signature does not verify under the key it asks with: a request that key's holder did not make. A joiner's id and key are public, so anybody can poll under them, and only the holder can sign -- which is what keeps a stranger from setting the endpoint a member record keeps. Not ordinary on any deployment: a rise is somebody polling under another machine's identity, or a joiner whose key file and stated key disagree.	ENROLL
pace_enrollment_requests_refused_revoked_key_total	An ENROLL asked under a key the cluster has revoked: a machine an operator forgot with --cluster-forget, asking to come back as itself. Refused at the door rather than listed, because no approval could admit a revoked key, and the refusal tells the machine to mint a new identity. Expected once after forgetting a machine that is still running; a steady rate is a removed machine nobody stopped.	ENROLL
pace_enrollment_control_refused_not_a_member_total	An ENROLL-CONTROL from a host this node does not admit. The decision half of the family is the one that admits a key to the cluster, so it is gated twice — membership here, and AUTH in the row below — and this counter is the outer gate reporting.	ENROLL-CONTROL
pace_enrollment_control_refused_identified_caller_required_total	An ENROLL-CONTROL -- approve, reject, auto-approve, clear, list -- from a caller only --fleet-open admitted: an anonymous caller trying to decide who joins. Never summed with the not-a-member series, a caller nothing admitted.
pace_enrollment_control_refused_operator_standing_required_total	An ENROLL-CONTROL -- approve, reject, auto-approve, clear, list -- from a caller whose machine ticket or proven key names a machine that holds no voter's seat: a learner deciding who joins. Never summed with the identified-caller series, an anonymous caller.

A Raft peer that could not prove which member it is, or proved it and still could not be served. Every connection between consensus members opens with a handshake: the accepting node challenges, the dialling node signs that challenge with its own identity key and names the member it meant to dial, and the acceptor answers with a verdict signed with its own. Each end checks the other's signature against the key the cluster records for the id it claims. The connections and frames rows are counted by the node that ACCEPTED the connection, the dials rows by the node that DIALLED it — so one misconfigured machine shows on both, from opposite ends. See cluster communication.

Series	Says
pace_raft_peer_connections_refused_no_handshake_total	Raft peer connections closed because the first frame was not a handshake proof this build reads: a Raft message sent without one (a build from before the handshake), a proof at another wire version, one over its size ceiling, or bytes that are not this wire at all. The log line beside it names which and the address it came from. Nothing was read from the connection.
pace_raft_peer_connections_refused_handshake_timeout_total	Raft peer connections closed because no proof arrived within the handshake bound. Before the handshake existed such a connection held a slot for as long as its socket lived; now it is closed and counted. A few is a slow or stalled peer; a steady rate from one address is something holding connections open on purpose.
pace_raft_peer_connections_refused_proof_total	Raft peer connections refused because the proof's signature did not verify under the key this node holds for the id it claims: another machine claiming that member's id, which only the member's own private key can prove. No verdict is sent. On a healthy fleet this is flat at zero, so any rise is an impersonation attempt or a member whose key file was replaced without re-admitting it.
pace_raft_peer_connections_refused_unknown_key_total	Raft peer connections refused because this node holds no key for the id the proof claims, so nothing could be verified and nothing was answered. A machine that is not a member at all -- every member the roster records holds its key. The address is in the log line and the claimed id is not: nobody proved it.
pace_raft_peer_connections_refused_revoked_key_total	Raft peer connections refused because the proof verified under a key the cluster has REVOKED: the removed machine itself, still dialling. Answered with a signed verdict saying so, so the removed machine reports its own revocation rather than a key problem here. Expected briefly after a --cluster-forget of a key; a steady rate is a machine nobody stopped.
pace_raft_peer_connections_refused_wrong_target_total	Raft peer connections from a dialler that proved its id but dialled another member at this address: its record of where that member answers is stale, usually because a node moved or two swapped addresses. Refused with a signed verdict, so the dialler reports it by name rather than as a key problem. The log names both ids.
pace_raft_peer_connections_refused_own_id_total	Raft peer connections from a dialler that proved THIS node's own id, which only this node's private key can do: two machines hold one identity, which is a copied --cluster-dir. Refused with a signed verdict. Never ordinary; the address in the log is the second machine.
pace_raft_peer_frames_refused_tag_total	Raft connections closed because a frame's tag did not verify under the connection's own session key: a frame changed, injected, replayed, reordered or carried over from another connection. A correct peer never produces one, so a rise is the network path or something on it.
pace_raft_peer_frames_refused_unreadable_total	Raft connections closed on a frame whose tag verified and which this build cannot read: a wire version other than the one the handshake settled, or a message out of place. A steady count names a peer running a different build. The dialler counts its own direction as pace_raft_peer_dials_ended_frame_unreadable_total.
pace_raft_peer_frames_refused_over_cap_total	Raft connections closed on a frame declaring more payload than this node buffers, refused before any of it was read.
pace_raft_peer_frames_refused_bad_magic_total	Raft connections closed on a frame whose header did not begin with this wire's magic, after which nothing on the connection can be framed.
pace_raft_peer_frames_refused_sender_total	Raft connections closed because a frame whose tag verified carried a message naming a sender other than the id its connection proved. Only the proven member can produce one, so a rise is a defect in a member rather than an attacker.
pace_raft_peer_connections_ended_key_withdrawn_total	Proven Raft peer connections this node closed because the key the dialler proved them with stopped being that member's in the cluster's roster: revoked, or replaced by a re-admission. Checked on every frame, so a revocation reaches every open connection at the next message rather than when the connection happens to break.
pace_raft_peer_connections_refused_full_total	Raft peer connections closed on arrival because the listener already served as many as it holds. A cluster needs one per peer, so a rise is something opening connections it does not need -- the last thing a stranger can still do before proving an id, now that a silent connection is closed at the handshake bound.
pace_raft_peer_dials_refused_timeout_total	Raft dials abandoned because the acceptor sent no challenge, or no verdict, within the handshake bound. The ordinary cause is a peer running a build from before the handshake, which never sends one, or an address that is not a Raft port. Read beside the peer's own no_handshake series, which rises on the other machine for the same connection.
pace_raft_peer_dials_refused_no_challenge_total	Raft dials abandoned because the acceptor opened with something other than a challenge this build reads: another wire version, or a port that is not this protocol. The log names the version seen.
pace_raft_peer_dials_refused_acceptor_proof_total	Raft dials abandoned because the acceptor's verdict did not verify under the key this node holds for the member that answered: another machine answering under that id. Nothing was sent to it. On a healthy fleet flat at zero; a rise names an address that is not the member it claims to be.
pace_raft_peer_dials_refused_acceptor_key_unknown_total	Raft dials abandoned because this node holds no key for the member that answered, so its verdict could not be verified. Nothing was sent to it. Admit the member again with its key (--cluster-admit==:@), or wait for the cluster to replicate it.
pace_raft_peer_dials_refused_acceptor_key_revoked_total	Raft dials abandoned because the member that answered signed with a key the cluster has revoked: a removed machine still answering at an address this node dials. Nothing was sent to it.
pace_raft_peer_dials_refused_wrong_target_total	Raft dials refused, by a verified verdict, because the member answering at the address is not the one this node dialled: this node's record of that member's address is stale. The log names both. It clears when the replicated state or discovery re-addresses the member.
pace_raft_peer_dials_refused_own_id_total	Raft dials refused, by a verified verdict, because the acceptor proved this node's own id from this node: two machines hold one private key, a copied --cluster-dir.
pace_raft_peer_dials_refused_own_key_revoked_total	Raft dials refused, by a verified verdict, because the acceptor's roster has revoked THIS node's key: this machine was removed from the cluster. It never clears by itself; the machine must mint a new identity -- a fresh --cluster-dir -- and be admitted under it.
pace_raft_peer_dials_ended_by_acceptor_total	Raft dials the acceptor closed after this node sent its proof, without a signed verdict. The causes are the ones an acceptor cannot sign: it holds no key for this node's id, or a different one, or it refused the proof's shape or ran out of handshake time. Never a stale address, a shared identity or a revoked key, which arrive signed and have series of their own.
pace_raft_peer_dials_ended_key_withdrawn_total	Proven Raft sessions this node ended before sending a frame, because the key the acceptor proved the session with stopped being that member's in the cluster's roster: revoked, or replaced. The redial that follows is judged against the roster as it is now.
pace_raft_peer_dials_ended_frame_tag_total	Two-way Raft sessions this node dialled -- a learner's, which the acceptor writes back on -- that it ended because a frame the acceptor wrote failed its tag: changed, injected, replayed or reordered in flight. A correct peer never produces one. The acceptor counts its own direction as pace_raft_peer_frames_refused_tag_total.
pace_raft_peer_dials_ended_frame_sender_total	Two-way Raft sessions this node dialled that it ended because a message whose tag verified named a sender other than the member the acceptor proved. Nothing it said was delivered.
pace_raft_peer_dials_ended_frame_unreadable_total	Two-way Raft sessions this node dialled that it ended on a frame whose tag verified and which this build cannot read: a wire version other than the one the handshake settled, or a message out of place. A steady count names a peer running a different build.
pace_raft_peer_dials_ended_frame_over_cap_total	Two-way Raft sessions this node dialled that it ended on a frame declaring more payload than this node buffers, refused before any of it was read.
pace_raft_peer_dials_ended_frame_bad_magic_total	Two-way Raft sessions this node dialled that it ended on a frame whose header did not begin with this wire's magic, after which nothing on the connection can be framed.
pace_raft_peer_dials_ended_silent_total	Two-way Raft sessions this node dialled -- a learner's -- that carried nothing for their idle bound, a hundred of the leader's heartbeat intervals, so this node closed them and redials on the learner's backoff. A steady trickle is the sessions to voters that are not leading, which write a learner nothing; one after a sleep is a half-open session to the leader, which without the bound would never end, so the roster and every forget would stop arriving until a restart.
pace_raft_sends_dropped_no_session_total	Raft messages dropped for a peer that dials in -- a learner, which nobody dials -- while no session of its is attached: the learner is offline, or has not dialled yet. Raft retransmits, so a drop costs the leader nothing else.
pace_raft_sends_dropped_unknown_peer_total	Raft messages dropped for a peer this node can place nowhere: it neither dials it nor was told it dials in, so nothing here can reach it however long it waits -- a member whose recorded address this node cannot dial, or an id it was never given an address for.
pace_raft_inbound_sessions_superseded_total	Raft sessions a peer's newer session superseded: the same id proved a second session while its first was still open, and the first was closed -- a two-way session by the transport, a one-way session by the acceptor. One per reconnect is a roaming member whose old connection had not yet been seen to end; a steady rate from one peer names two machines holding one identity key -- a copied --cluster-dir -- taking the session from each other.

A member admitted with a key the leader could not read. --cluster-admit and pacectl cluster-admit may name the member's identity key. The leader reads it before it proposes anything, and refuses one that is not a key with invalid-cluster-change and the reason. This project's clients check the key where it is typed, so the leader's refusal is the last line of defence against a client that does not — which is why it is counted, while every other invalid-cluster-change is an operator's own typo read back to them and moves nothing.

Series	Says
pace_cluster_admissions_refused_malformed_key_total	cluster-admit requests the leader refused because the member's identity key was not one: not 43 base64url characters naming 32 bytes, or 32 bytes naming a small-order or non-canonical point, under which a signature proves nothing. Nothing was proposed. This project's clients check the key where it is typed, so a rise names a client that does not.

Deciding whether a new refusal gets a counter

The set above is not closed, so the rule that produced it is written out rather than left to be inferred from the rows. The test is not "is this a refusal" but "would a rise here mean something happened". A refusal gets a counter when a rise names something an operator would go and act on. It gets none when:

• a rise would be ordinary traffic — a node with no cache tier answers every local FETCH unimplemented-verb, once per exchange for a whole build, so a counter on that answer would be dominated by healthy builds and a port scan invisible inside it;
• the arm cannot fire — the router hands the cache only verbs whose family it owns, so that surface's unknown-opcode arm is closed by the definition of the family table rather than by a policy anybody chose;
• the event is already counted somewhere better placed to see it — a failed local write moves pace_node_cache_store_failures_total at the write, where every caller is visible and not only the ones that arrived over the wire.

A new arm nobody has applied the test to yet is neither counted nor deliberately uncounted, and saying so is the point: those are different facts, and a two-value choice forces a new arm to read as a decision somebody made. It is spelled Cc::RefuseUntriaged with the issue that will settle it, ctest -R worker-refusals-counted prints the outstanding total split by issue on every run, and it fails the build when a file refuses that way and names no issue the scan can resolve. So the state is reachable only by a deliberate act that records where the decision is tracked, and the printed count cannot be driven to zero by relabelling.

A verb this node runs no component for — a FETCH at a node with no cache tier — is answered unimplemented-verb and counted nowhere, which is the first case above: it is what a healthy build gets, once per exchange.

A scheduling verb is never answered that way, because unimplemented-verb tells a client this build is too old and the build is current. A node that runs consensus but no scheduler — a learner — refuses RELEASE dispatch-not-permitted, having granted no lease, and answers every other scheduling verb not-leader naming the leader's 0xFC endpoint, once the caller is admitted, so a launcher pointed at its own machine's learner follows it to the leader; it names nobody once the leader has been silent past the consensus tier's election timeout. A node running no consensus at all refuses the capacity verbs (REGISTER, HEARTBEAT, WITHDRAW, LEASE, RELEASE, NODE-ANNOUNCE) dispatch-not-permitted and the cluster verbs no-cluster, the codes pace-kv gives for the same verbs. None of these is counted.

The cache surface's other six arms are uncounted deliberately, and each for its own reason rather than one shared sentence. They are listed so the decision can be disagreed with rather than rediscovered:

Refusal	Answers	Why nothing rises
An AUTH at the cache tier	unimplemented-verb	Unreachable through the port: an AUTH is answered by the node's session component on every node, before any tier sees it. Kept for a direct call.
A scheduler or compile verb at the cache tier	dispatch-not-permitted	The listener routes by verb family, so a frame reaching the tier already names a cache verb. Unreachable through the port.
An opcode with no table row	unknown-opcode	Same routing, and stronger: an unrecognised opcode has no family, so it is answered at the door and never reaches this surface.
A payload that is not its declared length	malformed-frame	The listener reads exactly the declared length, so the two figures are one figure. Kept as defence in depth for a direct call.
A cache verb reached without a credential	unauthenticated	This surface requires none, by standing decision — so the pre-payload gate cannot produce this answer for it.
An AUTH payload that will not decode or verify	malformed-frame, unauthenticated	AUTH belongs to the scheduler, which owns the credential. No credential outcome is ever decided against the cache.

Why the cache and compile surfaces answer an unreachable arm differently. The compile surface mints counters for credential arms it cannot currently reach (..._malformed_credential_total and ..._rejected_credential_total, flat at zero by construction) and the cache surface does not, which looks inconsistent and is not. The compile surface's unreachability is a routing fact — AUTH belongs to the scheduler today, and a shape in which a compile surface checked a credential of its own is a plausible change — so the dead row buys a signal that would otherwise have to be remembered. The cache surface's is stronger in both of its arms: it requires no credential by standing decision (#287, #290), and its unknown-opcode arm is excluded by the definition of the verb-family lookup rather than by any routing choice. Minting a row that cannot rise costs something in a table whose whole value is that every row means something, so it is paid where it buys a future signal and not where it cannot. Both directions are asserted rather than argued: a test sweeps all 256 opcode values and pins that nothing routes an unknown verb to the cache and that no pre-payload decision there can be unauthenticated.

Several groups must never be summed, and each shares a wire code, so a dashboard grouping by the code an operator sees in a client log gets them wrong:

• endpoint-busy is answered by three refusals. Two are byte budgets — the compile surface's and the cache's — and an operator reads them differently: one says more machines would not have helped, the other says this node's own tier is being handed objects faster than it can hold them. The third is connection capacity, which says this surface has no room for another conversation and is fixed by raising a connection ceiling rather than by looking at request sizes.
• payload-too-large is answered by the frame ceiling on each surface. The cache's is the one that fires on a node holding a tier, so a dashboard that watches only the compile series there watches a graph that cannot move.
• unauthenticated is answered both by a wrong token and by never having presented one. The first is a rotated key or somebody trying; the second is a fleet member misconfigured. Summed, "is my scheduler port being probed" stops being answerable — and the rejection half is the half that means somebody is trying.
• malformed-frame is shared by a truncated compile frame, an undecodable compile payload, an undecodable cache payload and two AUTH payloads. An operator told only "a malformed frame arrived" cannot tell a client version skew from somebody malforming AUTH at the door, nor a launcher that is out of step with this node's cache from one that is out of step with its compile surface.

All of them were once answered correctly on the wire while moving nothing, on the merged listener that is now the only 0xFC port a node opens (#447). Two of them had counted on the dedicated compile port that #290 retired, so the series went flat at a migration rather than at a code change, and nothing failed. A refusal answered while nothing rises makes a port being hammered look, on /metrics, exactly like a port nobody is talking to.

Looking at the whole fleet

--dashboard adds to that same endpoint: /fleet, a page; /fleet.json, the same facts for anything that is not a browser; /fleet.txt, those same facts again for a reader with no JSON parser; /fleet/chart/<chart>.svg, one image per chart; and /fleet/series.json, the numbers those images are drawn from.

pace-node --advertise 10.0.0.1:6675 \
                       --listen-node 6675 \
                       --listen-raft 6680 --raft-self 10.0.0.1 \
                       --admin-listen 6677 \
                       --dashboard --dashboard-token-file /etc/pace/dashboard.token
curl -s -u ":$(cat /etc/pace/dashboard.token)" localhost:6677/fleet.json | jq .

The same tables, without a JSON parser

jq is not on a Windows build box, and pacectl has no JSON parser — it only emits — so while /fleet.json was the only door that was not a browser, every table below was reachable from a browser and from nowhere else. /fleet.txt is a third walk over the same column tables, emitting tab-separated text:

curl -s -u ":$(cat /etc/pace/dashboard.token)" localhost:6677/fleet.txt
curl -s -u ":$(cat /etc/pace/dashboard.token)" \
     "localhost:6677/fleet.txt?section=workers" | cut -f1,2

It is gated on the same credential and answered by the same leader. A follower replies 503 and renders no table at all — every line a # comment, one of them naming the leader's scheduler port, so a reader stripping comments is left with an empty document rather than a partial one. That matters more here than on the page: a page has room for a sentence, while a table holding a fraction of the fleet is shaped exactly like one holding all of it by the time it reaches cut.

The headline figures, computed once

The page's strip — Dispatched, Compiling now, Cache hit rate, Refused, Leases outstanding, Oldest heartbeat, Never picked — used to be drawn and nowhere else, so a consumer wanting any of the seven had to re-derive it from the rows. Two implementations of one headline figure that disagree discredit both surfaces, and Oldest heartbeat is the sharpest: a re-deriver reaching for a mean gets a plausible number answering a different question.

They are a kpi key on /fleet.json and a kpi section on /fleet.txt now, keyed by a name each carries rather than by its page label — so a tile can be reworded without breaking a scraper:

curl -s -u ":$TOKEN" localhost:6677/fleet.json | jq '.kpi["cache-hit-rate"]'
# { "value": 853, "unit": "permille", "of": null }
curl -s -u ":$TOKEN" "localhost:6677/fleet.txt?section=kpi" | cut -f1,2

What travels is the number and its scale, never the page's / 32 slots or its sub-line: a consumer handed those would have to parse the figure back out of a label. unit says which scale the integer is in, because the key alone cannot tell a count from thousandths — 853 is 85.3%. of is the denominator as its own number for the two figures that have one (compiling-now, never-picked) and null for the rest.

The history, as text

The series section is /fleet/series.json on its side: one row per bucket of the range asked for, oldest first. Its columns are the bucket's start in milliseconds, its coverage, whether it was backfilled, and then one column per series the charts draw, under the keys the JSON uses:

curl -s -u ":$TOKEN" "localhost:6677/fleet.txt?section=series&range=7d" | cut -f1,4

A bucket nobody sampled is - in every figure, and so is a rate that cannot be taken because the bucket before it was not sampled. It is never 0: a fleet that did nothing and a fleet nobody was watching are different facts, and a restart is a gap, not a spike. range is refused when it names nothing, exactly as for kpi.

It is the one section the every-section document leaves out. Its size is the range's rather than the fleet's (a day is 288 rows, whatever the fleet is), so it is asked for by name.

Three of the seven are derived from the history rather than the snapshot, so both surfaces take range exactly as the page does, and refuse an unknown one for the same reason. A figure the range cannot answer is null / - and never 0: a fleet nobody sampled has not dispatched nothing, it has not said.

Ask for no section and it is the whole document: each table behind a # <key> marker naming it, blank-line separated — which is also how the keys section accepts are discoverable without reading this page. Ask for one and it is that table alone, a header line and its rows with no marker, because that is the form that goes straight into cut or awk. A key naming no section is refused rather than quietly served as another, and the refusal names what it would accept: the same asymmetry range draws, and the opposite of theme, which has a safe default because no substitution there can mislead.

Where a cell differs from the page, it differs the way /fleet.json does. Numbers are raw — 68719476736, not 64.0 GiB — because a humanised figure has to be parsed back before it can be compared or summed. An absent cell is -: never blank, which would be indistinguishable from a value that genuinely is the empty string, and never 0, which is a claim about the world. And a tier no member runs contributes no column at all, rather than a column of dashes that would read as a tier standing empty.

The leader answers it, and nobody else can. A follower's registry holds whatever registered against it rather than the fleet, which is the same reason --cluster-status is refused by one. Ask a follower and it replies 503 naming the leader and its scheduler endpoint — deliberately not a redirect, and deliberately not a link: where the dashboard is served is configuration on that node, nothing replicates it, and a URL built by guessing is one your browser cannot use.

What it shows, and why each part is split the way it is:

Section	What it answers
The readouts	The figures across the top: compiles dispatched over the selected range (with a sparkline), compiling now, cache hit rate, the share of dispatch decisions refused, leases outstanding, the oldest heartbeat in the fleet, and how many toolchains have never been picked. The oldest heartbeat and not the mean — one machine that stopped answering an hour ago is the fact worth surfacing, and an average over a healthy fleet buries it. Never picked counts distinct toolchains rather than registry entries, so one compiler served by four machines and reached through any of them counts as reached; a fleet with nothing registered shows – rather than 0, because zero here means every toolchain is being reached and an empty fleet cannot claim it.
Fleet capacity	One meter over every registered slot, split three ways: compiling, free, and withheld by a ceiling. The third is the one to read first — slots a ceiling withdrew are not this fleet being busy, so buying machines does not return them. A fleet that has never been dispatched to says that instead, because the same three numbers mean something else there — see below.
Machines	One row per machine, not per toolchain: the software version it is running, cores, memory, free scratch, class and reserve, cache hit rate, heartbeat age.
Workers	One row per (toolchain, endpoint) registry entry: slots, in flight, available — and which limit withdrew the difference. The compiler column says what the toolchain is (cl 19.44.35207); the toolchain fingerprint beside it is what actually decides a match, and a row shows – when the node did not say, which a pinned --toolchain=<fingerprint>=<compiler> override never does. registered-age and last-picked-age are read together: the second is – when the scheduler has never chosen that entry, and that is a finding beside a registration age of forty minutes and says nothing beside one of a second.
Leases outstanding	One row per lease the scheduler has handed out and not yet seen resolved: the object key, the worker it went to, that worker's endpoint, and how long it has been held. Oldest first, and bounded — the header says the 50 oldest of 900 when there are more, so a truncated table is not read as the whole fleet's work. A client hands its lease back when the job ends however it ended, so a row that has been there for minutes is a client that died mid-build, and the endpoint is where its work was going. A row with no endpoint is a lease against a worker that is no longer registered.
Why requests were refused	Granted, and refused split four ways, each with what it tells you to do.
Cache tiers	Items, bytes, budget, evictions and index RAM per tier. A tier no member runs has no column at all, and a fleet where nobody runs one says so rather than showing an empty table. index-ram is what the tier's key index costs in memory: always RAM, even for a disk tier whose budget is bytes on a filesystem, so the two are not comparable and must not be added.
Over time	Four charts over 24 hours or 7 days: compiles dispatched, refusals stacked four ways, offerable capacity against jobs in flight, and cache hit rate per bucket.
Members	Who the cluster has agreed on, and where each answers. A member that has announced none shows no scheduler endpoint, because it has not said.

These distinctions cost real debugging time when they are collapsed:

• A machine is not a worker. A node started with two --toolchain flags is two registry entries carrying one machine's cores. The Machines table is the grain a fleet total is computed over; summing the Workers table reports a fleet twice the size of the one you own.
• limited-by is the whole diagnosis. A node offering 2 of its 16 slots is four different problems: external-cpu means somebody is using that machine, memory and scratch mean it is out of something, and compile-budget means the compiles it is running hold nearly all of --compile-inflight-max, priced at its own mean per job. Buying hardware fixes exactly one of them.
• Do not add the lease refusals together. no-worker is a misconfiguration, no-capacity says buy more machines (or raise a compile-budget-limited worker's --compile-inflight-max), withdrawn says your machines are busy with something else, all-excluded says your clients cannot reach them, and duplicate says it is already being built. A total hides all five.
• A worker that is never picked looks exactly like a healthy one. It registered, it heartbeats, and every refusal counter on both machines reads zero — because nothing ever arrives to be refused. That is what one compiler family fingerprinting differently from your clients' looks like from here, and last-picked-age is the only column that can see it. Read it beside registered-age, and note that in-flight cannot answer the question: a job occupies the machine, so a node serving two toolchains shows work against both the moment either one runs a compile.

Expect the never-picked readout to be non-zero for a while after a leadership change, and do not chase it. The record is the current leader's, so a scheduler that has just taken over has chosen nobody yet however long the fleet has been up; the same goes for a machine that dropped out of the fleet long enough to be expired and has just come back. Both drain as soon as one compile goes to each toolchain. A count that persists while the fleet is building is the finding.

An ordinary re-registration is not one of those cases, deliberately: a node falls through to registering again after any refused heartbeat — a busy endpoint, or an election — without having gone anywhere, so neither its registration age nor its last-picked age restarts. Otherwise a transient would erase the forty minutes of evidence that make a never-picked row worth reading.

A value nobody reported renders as – on the page and null in the JSON, never as 0 — a zero is a claim, and "this cache holds nothing" is a different fact from "this node never told us".

An unused fleet is not an idle one

Dispatch is opt-in. A client asks for a lease only when PACE_SCHEDULER names a scheduler; PACE_ADDR alone points the launcher at a cache. A node deployed the common way — as a shared cache for a build that compiles locally — therefore registers its slots, is never asked for a lease, and reports 0 compiling for as long as it runs.

That zero is honest and it is not idleness, so the capacity panel says which it is rather than leaving the three numbers to be read the wrong way. It matters because the reading underneath is otherwise actively misleading: withheld is derived from the host's CPU, memory and scratch minus the jobs this fleet handed out, so on a node that was handed none, every core your own build is using is attributed to somebody else. The panel would tell you your machines were busy with a third party's work while the third party was you.

Once one lease has been granted, the ordinary readings return — from then on, host load this fleet cannot account for genuinely is somebody else's.

Which build each machine is running

The version column is what a node's own binary reports at registration — the same string pace-node --version prints. It is compiled in and not configurable: the column exists to answer which binary is actually on that box, most often part-way through a rolling upgrade, and a version a node could be told to report is one that can be wrong exactly when somebody is relying on it.

It rides inside the REGISTER message's nested capacity record rather than as a field of its own, because that message's top-level arity is exact and fixed forever — a sixth field there would make two builds of a fleet unable to speak at all. The nested record is read with the variable-arity split, so compatibility runs both ways: a node built before this field registers with a new leader and simply reports nothing, and a new node registering with an old leader has the extra field skipped.

A node that cannot report one renders as –, not as a blank. That node is exactly the one an operator is hunting for mid-upgrade, so it must not look like the least interesting row in the table. The version is also refreshed when a machine re-registers, which is the path a restart takes — a value held over from the first registration would leave the page reporting the old binary for as long as the new process stayed up.

The charts, and what they are sampled from

The leader samples the fleet once a minute, and only while it leads. A follower's registry holds whatever registered against it, so sampling there would record a fraction of the fleet as though it were the whole — and the chart would then show the fleet shrinking every time leadership moved. Losing leadership stops sampling and leaves a gap.

A bucket nobody sampled draws a gap, never a zero. Zero says the fleet did nothing; a gap says nobody was watching. The same distinction the tables make at the cell, made here at the point. It falls out of storing each counter's raw cumulative value and taking the difference at render time: a restart returns the counter to zero, the difference goes negative, and that bucket is a gap rather than an enormous spike.

The cache hit rate is per bucket and never cumulative — a running total stops moving once it is large, so an afternoon of misses barely bends it. A bucket that served no reads has no hit rate at all and is absent, because 0% is the claim that the cache missed everything.

Eight windows, and what each one is folded from

The range control offers 1 h, 2 h, 8 h, 24 h, 7 d, 1 month, 6 months and 12 months. Three rings are stored — one bucket a minute for a day, one an hour for a month, one a day for four hundred days — and every window is a fold of one of them, so a longer view is a wider bucket rather than a longer file. Every sample is written into all three as it is taken, rather than a coarse ring being filled by buckets ageing out of the one below: both give the same numbers, and this way there is no second code path that first runs twenty-four hours in.

Folding sixty readings into one bucket would throw away the part worth looking at, so each bucket also keeps the low, the high and the total per slot. A refusal spike averaged over a day is invisible; a gauge's floor — the moment the fleet had nothing left — is the end that matters. Neither can be recovered afterwards, so both are computed while folding.

Every node records itself, and a leader keeps what the others send

A node samples its own figures — its cache, its offerable slots, its compiles — once a minute whether or not it leads, and hands its closed buckets to the scheduler on the heartbeat it already sends. Nothing extra is dialled and nothing is acknowledged: the leader keeps a high-water mark per machine, so a heartbeat redelivered after a reply the node never saw is ignored rather than counted twice.

The fleet-wide figures — the dispatch outcomes — stay leader-only, because only a scheduler produces them and a follower's registry holds whatever registered against it. A leader therefore has a complete record of the windows it was elected for, and fills the rest from what the machines handed over. Those windows are marked, and their scheduler-scoped series read null rather than zero: no machine can answer for a dispatch outcome, and a zero drawn there would be a refusal count nobody measured.

That is why the fleet's year survives an election. A machine decommissioned last month is still in the twelve-month view, and a leader elected this morning does not show a chart that starts at breakfast.

Partly observed windows

A bucket carries how many samples actually landed in it. On the 24 h view a full bucket holds five; a node that was down for four of those five minutes contributes one. The reading is still true — a gauge's last sample, a rate over the span actually seen — so it is drawn like any other point, and the page says in words how many settled windows were only partly observed rather than implying the number itself is suspect. /fleet/series.json carries coverage per bucket beside covers, which is what a fully observed one holds.

The newest window is never counted there. It is still filling, and is partly covered by definition.

What it costs

Fixed, and reported rather than estimated. The rings do not grow: 1440 + 720 + 400 buckets are allocated in full at construction, so this is the steady state rather than a ceiling to watch.

	measured
one series, in memory and on disk	800 KiB (819,253 bytes)
a node's own two series	1.6 MiB
a leader, per machine reporting to it	+ 800 KiB

A leader of a twenty-machine fleet therefore holds about 18 MiB of history, for twelve months of it. The node logs the same figures at startup, so the number an operator sizes against comes from the build they are running rather than from this page.

Where it is kept

Where the history is kept follows the directories the node already has: the --cluster-dir if there is one, otherwise the --cache-dir, otherwise memory only — and the page says which. There is no flag for it: a third place to say "put state here" is a third place to point at the wrong disk. Three files live there: this machine's own series, the fleet-wide series, and what the other machines handed over.

Any failure to read one — missing, short, wrong version, bad checksum — starts empty and logs one line. History is a convenience and must never keep a node from starting. One case is different and is called out at WARN: a file written by a newer build than the one running is kept and never written over, because replacing it would destroy readings the build it was rolled back from could still read.

Each chart is its own resource rather than being inlined, so a browser caches it:

curl -s -u ":$(cat /etc/pace/dashboard.token)" \
     "localhost:6677/fleet/chart/refusals.svg?range=7d" > refusals.svg
curl -s -u ":$(cat /etc/pace/dashboard.token)" \
     "localhost:6677/fleet/series.json?range=24h" | jq .

range is one of 1h, 2h, 8h, 24h, 7d, 1mo, 6mo or 12mo, and an unrecognised one is refused with 400 that names the ones that are served — a substituted range puts a reader on a different axis with nothing on the page saying so. theme is auto (the default), light or dark, and an unrecognised one is silently auto, because that one renders correctly under either setting and costs a reader nothing.

Each answer carries an ETag and a Cache-Control that runs only to the end of the bucket it drew, so If-None-Match gets a 304 until there is something new — not a fixed lifetime, which would leave a viewer a whole bucket behind for the rest of it.

The chart routes need the credential too. An image URL that answered without one would leak the fleet's whole history while /fleet itself stayed locked. Browsers replay Basic on same-origin subresources, so a credential typed once at the page covers the images; a Bearer client sets the header per request.

Getting at it safely

The page is a map of every member's hostname, endpoint and capacity, so:

• A bare port binds loopback, as --admin-listen always has.
• --dashboard-token-file is required when it is not on loopback. The node refuses to start otherwise. A file rather than a flag, because a command line is readable through ps — and its own secret rather than --requirepass, which every member of the fleet already holds and which points the other way.
• Present it as Authorization: Bearer <token> or as HTTP Basic with any username (curl -u :$TOKEN). Basic is there because browsers prompt for it and do not prompt for Bearer.

/metrics and /healthz are not behind the credential, so turning the dashboard on changes nothing for a scraper or a probe already pointed at them. And /metrics stays the source of truth for anything you alert on: the dashboard reads the same counters and computes no number of its own.

Plain HTTP, HTTPS, or HTTPS with nothing to obtain

HTTP is the default and is a supported way to run this. The admin surface is plaintext unless you ask for TLS, so the example above — loopback, no certificate — is a complete configuration. Reaching loopback already means being on the machine, which is why it needs no credential either.

There are three ways to run the surface, and they differ only in what you had to obtain first:

	Flags	What you get
Plain HTTP	(none)	No encryption. Fine on loopback, or behind something that terminates TLS for you.
HTTPS, generated certificate	--tls-self-signed	Encryption with nothing to obtain. Does not prove which node answered.
HTTPS, your certificate	--tls-cert + --tls-key	Encryption, and an identity a client can actually verify.

# An encrypted dashboard on an internal network, with no certificate to obtain:
pace-node ... --admin-listen 0.0.0.0:6677 \
                       --dashboard --dashboard-token-file /etc/pace/dashboard.token \
                       --tls-self-signed

--tls-self-signed generates a P-256 key and a certificate at startup, valid for localhost, 127.0.0.1, ::1, this machine's own hostname, and the address --admin-listen names when it is a particular interface rather than a wildcard. Those names matter: every modern client ignores a certificate's common name, and a name mismatch is a second browser warning on top of the unknown issuer — a much harder one to click past.

Two things to know before you rely on it:

• It encrypts; it does not identify. Nothing signs it, so a client that has not been told its fingerprint out of band cannot tell your node from anything else answering on that address. The node logs the SHA-256 fingerprint at startup for exactly that reason — compare it with what your browser shows. This is also why the credential is still required off loopback: TLS authenticates the server to the browser and says nothing about who the browser is.
• It is held in memory and regenerated on every restart, so a browser exception pinned to it has to be granted again. Nothing is written to disk, which means no private key to leak and no permissions to get wrong. If you want a stable identity, name a real certificate.

There is deliberately no --tls boolean: TLS is on because you named material or asked for material to be made, so "TLS requested, nothing to serve it with" is not a state you can reach. --tls-self-signed and --tls-cert contradict each other and the node refuses both together, rather than silently serving an identity you did not choose.

What the counters mean is tabulated under Distributed compilation.

The scratch root, and running two nodes on one machine

A worker compiles into a scratch directory of its own, beneath a root under the system temporary directory. That root is claimed exclusively for the life of the process, so two compile nodes on one machine get different ones.

They used to get the same one. The root carried nothing per process and each node numbered its jobs from 1, so a second node derived the identical job-1 — and creating a directory that already exists succeeds, so it was told nothing. One node's cleanup then removed the directory out from under the other's compile, or the two shared an object file and one answered with the other's (#279).

TEMP (or TMPDIR) relocates the root, and that is the supported way to give a node its own — there is deliberately no separate flag, because the environment already says this and two ways to say one thing is how they come to disagree. The fixture that proves the isolation uses exactly this mechanism as its control.

A node that cannot claim a root refuses to start, by name, rather than sharing one:

Refusal	What it means	What to do
scratch-roots-exhausted	Every candidate root is held by another running node.	Stop one, or give this node its own TEMP.
scratch-unavailable	The directory could not be created, or the filesystem cannot lock.	Check the disk and its permissions. Point TEMP at a local filesystem if this one is a network mount.

There is no unclaimed fallback. Carrying on without the claim would restore the defect above on exactly the machines least able to diagnose it, and would do so while everything looked healthy.

A root left behind by a node that died — the abandoned-drain path exits without running its cleanup, by design — is reclaimed by the next node that takes it, and counted as pace_worker_scratch_roots_reclaimed_total. Reclaiming is safe without any staleness guess: the claim is an operating-system lock, so a root whose lock is free is one whose owner is gone, however it went.

What a worker will not do

• Run a program a client named. The compiler comes from --toolchain.
• Touch a path a client named. The object path and the directory are the worker's own, inside a per-job scratch directory it creates and removes. A command line carrying anything that could name a file is refused outright, on both ends — the client's check protects an honest client from dispatching something that would not work, and the worker's protects it from a client that is not honest.

The one thing a client does get to choose is what its translation unit is called, because a compiler records the name of the file it was handed and an object built under an invented name is gratuitously different from a locally built one. The name is reduced to a single component and an allow-listed shape before it becomes a path — no separators, no parent-directory segments, no drive letters, a bounded length, an extension from a fixed set, and never a Windows device name such as CON — and anything failing that is compiled as tu.cpp rather than refused. The language never rides on it: the client states the language explicitly (-x c++-cpp-output, /TP), so a name the worker had to invent cannot decide how the text is compiled. - Write to the cache. Workers get no cache credentials.

Adding a flag the built-in list does not know

The arguments a worker will pass to its compiler are an allowlist, keyed on the driver family, and it is deliberately broader than anything this project's own builds emit. It still cannot be complete forever, and the failure when it is short is the quiet one: the worker refuses the argument, the client compiles locally, and the build stays green while that translation unit silently stops being distributed.

--allow-compile-arg (allow_compile_arg: in the file) adds a spelling, repeatably:

pace-node --cluster-dir=/var/lib/pace-node \
    --allow-compile-arg=-fanalyzer \
    --allow-compile-arg=/Qvec-report:2

Five things are worth knowing before you use it.

clang-cl's pass-through is judged by what it passes. -clang:<arg> and /clang:<arg> hand <arg> to the clang driver inside clang-cl, so a worker judges <arg> as if it stood alone, by the clang driver's own (GNU) spellings: -clang:-std=c++23 is accepted because -std=c++23 is, and -clang:-fplugin=x is refused because -fplugin=x is. A refusal still names the whole argument, and an entry here still matches the whole argument, so an unrecognised -clang:-fsomething is admitted with --allow-compile-arg=-clang:-fsomething.

It extends and can never shrink. Entries are consulted only after the built-in table has failed to recognise an argument at all. Everything the table refuses — every plugin loader, every sub-tool pass-through, every path-valued option, every flag that would make the compile write a second file — is refused by a rule that returns before this list is reached. Naming one of them here changes nothing.

Matching is whole and exact. -fanalyzer allows -fanalyzer and not -fanalyzer=x, and there is no prefix or wildcard form: a -f* rule would re-admit -fplugin=, which is the hole the allowlist replaced a denylist to close. A value carrying a path separator is refused when you write it and again when it arrives.

It is reloadable. systemctl reload pace-node (or SIGHUP) applies a change without restarting, so a site that meets an unknown flag mid-build day does not wait for a release or for a window to drop the compiles in flight. It does not re-register the worker, because the set is local — a registration says which toolchains this node serves, not which arguments it accepts.

It is announced at WARN. Every start with a non-empty set, and every reload that moves it, logs the whole set at the level a credential change is logged at:

[WARN] compile-argument allowlist extended by configuration with 2 entry/entries: -fanalyzer, /Qvec-report:2

Removing the last entry says so too (… 0 entry/entries now in force: (none)). That is not noise — this is the one setting that widens what a client may make this worker's compiler do, and an incident is read against what was in force at the time.

Security

A node verifies machines, and holds no shared secret

A compile node's framed surfaces — scheduler, compile port, cache tier — take one inbound credential, and it identifies a machine, not a person: a machine ticket, signed by a machine's own identity key and verified against the roster the node holds. There is no password and no key shared across the fleet, so nothing a node could leak lets another machine speak for it. --requirepass on a node is only the secret it presents when it dials a pace-kv named by --upstream, which is the one surface that takes one.

A launcher sends PACE_TOKEN to the cache at PACE_ADDR and to nothing else; every exchange with another machine presents a ticket its own node minted for that exchange. A password AUTH that does reach a node is answered Ok and establishes nothing, so a client configured with a token is never broken by a node — the node's scheduler once answered it dispatch-not-permitted instead, which the launcher treats as fatal (#340).

A ticket travels in the clear, so it is bound to ONE endpoint, lives a minute and is spent once at the node that accepts it; a node proof is sealed from its first frame. A network where a ticket can be captured costs a replay at no other node and no later moment. The cache tier admits this machine only, whatever the caller presents.

The boundary of those framed surfaces is network reachability plus membership, and membership is a machine's key. The credentials: --dashboard-token-file for the fleet page, pace-kv's own --requirepass for the pace-kv a node's --upstream names, the machine ticket every client presents to another machine, and each node's own identity key, which every consensus connection proves before a message is read — so the Raft port is not open to whoever can reach it and one member cannot speak as another — which every connection a machine joins the fleet on proves before a joining verb is heard, and which every lease grant is signed with. Those handshakes authenticate; they do not encrypt. See Raft peer authentication and the node's own.

Keep a scheduling node's port off any network you would not run a compiler for. That is why it is a separate process from the cache: the cache may reasonably be reachable across a build LAN, while the surface that makes a compiler run on another machine should be firewalled separately. A scheduling verb arriving at a pace-kv listener is refused with a typed reply naming where the scheduler went.

Admission decides which machines may reach this node's compile port and its scheduler: this machine always, another machine only by a key its roster holds — a proof or a machine ticket — or any caller under --fleet-open. Its own cache tier admits this machine alone. So a node is useful to its owner with no configuration and closed to the network until a machine is admitted to the cluster.

Note where this differs from pace-kv. There, membership is a policy about contribution and a non-member still reads and writes the shared cache — that cache is shared infrastructure somebody operates. A node's tier is a developer's own build output, and its compile port is its own CPU, so both are closed by default. On a node, membership IS the credential check: a machine proves its key, or presents a ticket signed with it, and no source address admits anybody but this machine (#180) — so a spoofed address buys a stranger nothing. An AUTH travels in the clear, which is why a ticket names one endpoint, lives a minute and is spent once.

For anything beyond a trusted build network, put mTLS in front of every port.

A node proves which machine it is, and every frame after it is sealed

Every connection a machine makes to its scheduler opens by proving its identity key, and the scheduler admits it by that identity whatever address it dialled from (#178). There is no flag: a node keeping an identity -- a consensus member, or a worker given --cluster-dir -- proves it on every heartbeat round, and a node running consensus verifies the proofs presented to it against the cluster's roster.

The verbs a machine JOINS the fleet with require it. REGISTER, NODE-ANNOUNCE, HEARTBEAT and WITHDRAW are refused node-identity-required on a connection that proved no identity the cluster holds -- from any address, loopback included. A client is admitted without a proof: on this machine by loopback, and from another machine by the machine ticket its own node mints (a machine that only asks), which never satisfies a joining verb. That is why a worker needs --cluster-dir and a launcher needs only a node on its own machine.

This is what makes a machine on a VPN, a NAT or DHCP usable at all. Before it, admission was the peer's source address against the cluster's committed endpoints or against an operator's host list, so a worker that gets a different address each session had to be re-listed each session, on every node.

The exchange is two verbs on the port the node already serves:

1. The node sends a fresh nonce and an ephemeral X25519 key.
2. The scheduler answers with its node id, its identity key, a nonce and an ephemeral key of its own, and signs all of it. The node checks the signature and -- once it holds the cluster's roster -- that the key is a live voter's. A machine the cluster revoked, still named among a worker's recorded scheduler endpoints, is refused by the worker, which proves nothing to it.
3. The node signs the whole exchange with its identity key. The scheduler verifies the signature first and asks its roster second, so a caller that cannot sign learns nothing about which ids and keys the cluster holds.

Then every frame is sealed. Both ends derive one key per direction from the ephemeral exchange -- bound to both nonces and both ids -- and every frame after the proof, the scheduler's answer to it first, carries an HMAC under it. That is what defeats a machine on the path: something between a worker and its scheduler can relay a genuine handshake byte for byte, but it cannot compute the session key, so a verb it injects fails its tag and the connection closes. A frame replayed, reordered or dropped inside the session fails the same way. A connection proves once; asking again closes it.

Admitting a machine. A machine joins as a learner: it asks by itself once it finds the fleet (--fleet-seed where no beacon reaches), and is approved with --enroll-approve against the key its --print-identity prints. A voter is admitted, or a learner promoted, with --cluster-admit.

Removing one. --cluster-forget=<id> revokes the machine's key, and nothing is rotated on anybody else. A connection that proves a revoked key is refused node-key-revoked and marked: every later request on it is refused as the forgotten machine's -- including from this machine and on a --fleet-open node, and including a live-stats subscription already running, which ends on its next tick. The key outranks every other route.

Where it does not reach. A node's own cache tier still serves this machine only -- that is a property of the verb and not of any list, so an admitted identity does not open it. The fleet page and a live-stats subscription both need --dashboard-token-file on top of membership, and that credential is unchanged: a proof is not a substitute for the token. What a proof does reach is the membership half of both.

Reading the counters.

Series	What a rise means
pace_node_proofs_accepted_total	The route is live. Every other row below counts a refusal, so this is the only one that distinguishes working from never used.
pace_node_proofs_rejected_total	A signature that did not verify under the key the proof presented: somebody who does not hold that key, or a proof relayed onto another handshake. Not a machine waiting to be admitted -- that is the next row.
pace_node_proofs_refused_unknown_key_total	A genuine signature under a key the cluster does not hold for that id: a machine not yet admitted, or one admitted under another key. The remedy is --enroll-approve, never a hunt for an attacker.
pace_node_proofs_refused_revoked_key_total	The forgotten machine itself, still holding its key and still dialling.
pace_node_proofs_refused_roster_not_yet_applied_total	A proof this node could not judge yet: its consensus had not applied the log it recovered at start, so it answered roster-not-yet-applied and the prover asked again a moment later -- never node-key-unknown, which would have sent an operator to admit a machine the cluster already holds. A few at every start are the boot order; a count that keeps rising is a node that cannot elect, or cannot hear its leader.
pace_node_requests_refused_key_revoked_total	Requests refused on a connection a revoked key marked -- by a proof, or by a ticket signed with it -- at every surface that folds the proven identity: a compile, the fleet tables, live stats, node, an enrollment verb. It means a machine somebody forgot is still configured to use this fleet, or somebody holds one of its tickets, and the remedy is at that machine or at the cluster (admit it again under a new key), never on this node. Only a proof is told why; a ticket gets a stranger's words, so on a node that is not --fleet-open this counter is the only place the difference shows (under --fleet-open a stranger is served, so the refusal itself shows it).
pace_node_tickets_accepted_total	Machine tickets this node verified and spent: AUTH on that connection speaks for the machine the ticket names. The positive half of every node_tickets_refused row below.
pace_node_tickets_refused_malformed_total	Bytes that are not a machine ticket: a client of another version, or none of ours.
pace_node_tickets_refused_not_utf8_total	A genuine ticket whose machine id or audience is not UTF-8, refused before it is compared, logged or rendered. A forged one is counted as forged, whatever its claims say.
pace_node_tickets_refused_no_roster_total	This node holds no roster, or one past its certification, so nothing was checked. Never read it as unknown_machine: the remedy is this node reaching a leader, not an admission.
pace_node_tickets_refused_unknown_machine_total	A ticket naming a machine this node's roster holds no live key for, signed by no key it revoked: a machine the cluster has not admitted -- admit it as a learner.
pace_node_tickets_refused_forged_total	An admitted machine's id, not signed by its key. Reads zero on a healthy fleet.
pace_node_tickets_refused_revoked_total	Signed by a key the cluster revoked: the forgotten machine itself, still minting.
pace_node_tickets_refused_wrong_audience_total	A genuine ticket minted for another endpoint: a stale name or address, or a ticket presented somewhere it was not meant for.
pace_node_tickets_refused_expired_total	A genuine ticket past its expiry and the five-minute clock-skew slack, or further ahead than any node mints, or expiring no later than a spend this node has already let go of. A steady rise from one machine is its clock; a burst from every machine just after this node's clock was corrected is the last case, and it clears by itself within ten minutes, or, if this node accepted tickets while its clock was ahead, once real time reaches that reading; restarting the node clears it at once.
pace_node_tickets_refused_replayed_total	A genuine ticket this node had already spent. A ticket is presented once, so a rise is a replay.
pace_node_tickets_refused_spent_set_full_total	This node remembers its capacity of spent tickets, all still acceptable, and admits nothing more until some leave the window. A rise says the set is too small.
pace_node_tickets_minted_total	Machine tickets this node signed for a process on this machine. Every ticket another node accepts was minted by some node's row here.
pace_node_ticket_mints_refused_not_local_total	MINT-TICKET asked from anywhere but loopback, refused before anything was signed: a ticket is minted for this machine's own processes only, judged from the connection's peer address. A launcher on this machine that dials its node by a LAN address lands here too; point it at loopback.
pace_node_ticket_mints_refused_malformed_total	MINT-TICKET whose audience would not decode, was not UTF-8 text (which every node would refuse to read), or named no one machine -- loopback, a wildcard or no host -- so the ticket would be spendable at any node. A client configured with a loopback endpoint.
pace_node_ticket_mints_refused_no_key_total	MINT-TICKET on a node that holds no identity key. The remedy is this node's state directory, not the client.
pace_node_ticket_mints_refused_no_random_total	MINT-TICKET this node could not draw a nonce for: its own random source failed. Refused rather than signed with a weaker nonce.
pace_node_sealed_frames_refused_total	A frame whose seal did not verify on a proven connection: injected, altered, replayed or reordered by something between the two ends. On a healthy network this reads zero; a rise is the alarm.
pace_node_proofs_unchallenged_total	A client sent a proof with no challenge outstanding. A version or client-library mismatch, not a security signal.
pace_node_proofs_malformed_total	A payload that would not decode. The same kind of mismatch, kept apart so an old client cannot hide a key search.
pace_scheduler_requests_refused_node_identity_required_total	A joining verb sent on a connection that proved no identity: a node started without --cluster-dir, or an older build.
pace_scheduler_requests_refused_identified_caller_required_total	A cluster control verb -- admit, forget, set -- from a caller only --fleet-open admitted. --fleet-open admits a caller to what the fleet serves, never to what decides it: send the verb from this machine, or from one whose node presents a machine ticket.
pace_scheduler_requests_refused_operator_standing_required_total	A cluster control verb -- admit, forget, set -- from a caller whose machine ticket or proven key names a machine that holds no voter's seat. A ticket proves a fleet machine, never an operator: run the verb on a voter, or promote the machine.

A refused ticket is told less than these counters say. AUTH answers any address, and a ticket is checked under the roster's key for the id it claims -- so forged, unknown_machine and revoked would tell anybody who signs a ticket for some id with their own key whether that id is admitted here, and anybody holding a captured ticket whether its machine was forgotten. All three reach the client as one message, not admitted by this node, and on a node that is not --fleet-open only the counters above tell them apart. On a --fleet-open node the connection behind a revoked ticket is refused where the other two are served, and the self form of explain-admission answers it refused rather than admitted, by fleet-open -- so a captured ticket's holder learns there that its machine was forgotten; forged and unknown_machine stay indistinguishable, since both are served. The reason is read on the node, by its operator. A refusal the caller can check for itself -- malformed bytes, a wrong audience, an expiry -- or one about this node's own state still names itself.

A node whose proof is not accepted says so, naming the scheduler and the reason -- at warn when it starts, then at info every ten minutes while it lasts, as a scheduler that does not answer is --, and tries the next scheduler endpoint in the same round -- a connection that proved nothing is one on which no joining verb can be heard, so it counts as an endpoint that did not answer:

WARN  scheduler.internal:6675 did not accept this machine's identity: node-key-unknown: this cluster holds no such key for w-7 ...

A node that runs consensus is admitted by its OWN cluster's record of its key, and a member the cluster was started with is recorded only once the cluster has elected a leader -- a moment after its worker and presence loops start. So such a node does not dial any --scheduler until that record exists: it says so once at INFO ("not announcing to the fleet yet"), asks again every two seconds, says so again at WARN if the record has not arrived after 15 asks (a cluster that cannot elect, or a joining machine nobody admitted), and says when it has. A node that schedules for itself is therefore never refused by its own scheduler at start, and its own id never meets the admit it remedy: a proof under this node's own id is answered as this node's own identity, or -- under another key -- as a second machine running with a copy of its --cluster-dir.

A node running no consensus answers both verbs no-cluster rather than unimplemented verb — which a caller would read as this node's build is too old and act on by upgrading a machine that is already current — and a worker reads it as this is no scheduler of this fleet.

Known limitations

• Preprocessing does not distribute. The client must preprocess to compute the cache key before it knows there is a miss, so at roughly 45 ms against compiles of 300 ms–2 s the ceiling is about 10–40×, not linear.
• -g embeds the worker's scratch path in DWARF. Use -fdebug-prefix-map, which this launcher recognises and folds into the cache key, so two checkouts still share. -ffile-prefix-map and -fmacro-prefix-map are keyed the same way and share across checkouts too. -fmacro-prefix-map travels to the worker verbatim, which applies it to the client's paths; a line carrying -ffile-prefix-map compiles locally, since it also rewrites debug records a worker maps by its own rules. See the launcher's own account.
• Diagnostics from a failed remote compile are not shown. A worker that reports a non-zero exit is retried locally and the local result is what you see, which also regenerates diagnostics with correct line numbers.

• On MSVC a dispatched object is not byte-identical to a locally compiled one — the code in it is. Measured on MSVC 14.51 and clang-cl, three things differ and no more:

  • every MSVC-family driver stamps the clock into the COFF header (two compiles of one file to one path two seconds apart differ in exactly byte 4; /Brepro is what suppresses it);
  • cl records the absolute path of the object file in .debug$S, even without /Zi;
  • cl hashes the source file it opened into .chks64, and a worker opens its own scratch file.

  Everything carrying code or data is byte-identical: same compiler, same flags, same preprocessed input. What it affects is debugging, in the same way -fdebug-prefix-map addresses for GCC and clang — a debugger will need /PDBALTPATH or an equivalent source-path mapping to find your sources.

  So the Windows end-to-end fixture compares section by section against a per-driver table of what may differ, and clang-cl's table is empty: it records only the source's base name, which the worker is told, so its objects differ by the clock alone. The POSIX fixture asserts strict byte-identity and should — GCC and clang embed nothing path-dependent without -g. If your build compares object bytes across machines, compare sections.
